- Page 1 Installation Guide 10/100 Fast Ethernet Switch with 100FX Connectivity KS-105F-B Series DOC.111122-KS105FB...
- Page 2 (C) 2010 KTI Networks Inc. All rights reserved. No part of this documen- tation may be reproduced in any form or by any means or used to make any directive work (such as translation or transformation) without per- mission from KTI Networks Inc.
- Page 3 The information contained in this document is subject to change without prior notice. Copyright (C) All Rights Reserved. TRADEMARKS Ethernet is a registered trademark of Xerox Corp. FCC NOTICE This device complies with Class B Part 15 the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received including the interference that may cause.
-
Page 4: Table Of Contents
Table of Contents 1. Introduction ..............5 1.1 Features ................... 6 1.2 Specifications .................. 7 2. Installing the Switch ............. 9 2.1 Unpacking ..................9 2.2 Checking AC Power ................. 9 2.3 Installing the Switch ..............10 3. Making Network Connections ........11 3.1 Switched Ports ................ -
Page 5: Introduction
1. Introduction This 5-port Fast Ethernet switch series provides four 10/100 TP ports and one 100BASE-FX fiber port, each capable of transmitting or receiving information simultaneously at full wire speed to control and allocate the network bandwidth. The key features of the switch series are: •... -
Page 6: Features
1.1 Features Designed for resolving congestion problems caused by bandwidth-hun- gry devices and bandwidth-intensive applications as well as a high num- ber of users, the switches not only adhere to the IEEE 802.3 10BASE-T, 802.3u 100BASE-TX and 100BASE-FX standards, but also feature: •... -
Page 7: Specifications
1.2 Specifications 10/100 Ports IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX std. Shielded RJ-45 jacks with Auto MDI-X detection Auto-negotiation capable Speed for 10Mbps or 100Mbps Full-duplex or half-duplex mode support 100FX Port IEEE 802.3u 100BASE-FX compliant Fixed 100Mbps operation Duplex mode selector - full duplex or half duplex Flow control IEEE 802.3x pause packet for full duplex operation Back-pressure for half duplex operation... - Page 8 Consumption DC input power consumption 3W @+5V 100FX Port Fiber Specifications Model: KS-105FB Duplex Series Model Ext Fiber Wavelength Tx Power Sens. Ref.Distance MMF 1310nm -20 ~ -14dBm -32dBm MMF 1310nm -20 ~ -14dBm -31dBm MT-RJ MMF 1310nm -19 ~ -14dBm -31dBm VF-45 MMF 1310nm -20 ~ -14dBm -31dBm -SA2...
-
Page 9: Installing The Switch
2. Installing the Switch 2.1 Unpacking Check to see that you have everything before you start the installation. • Installation guide • The switch unit • One AC power adapter for the unit 2.2 Checking AC Power Before you begin the installation, check the AC voltage of your area. The AC power adapter which is used to supply the DC power for the unit should have the AC voltage matching the commercial power voltage in your area. -
Page 10: Installing The Switch
The DC power jack for the AC power adapter is located on the rear of the switch as shown below: 2.3 Installing the Switch 1. Install the switch with the AC power adapter provided. 2. Connect the power adapter cable to the switch before connecting the adapter to the AC outlet. -
Page 11: Making Network Connections
3. Making Network Connections 3.1 Switched Ports The following figure shows the locations of the switched ports: 3.2 Making UTP Connections 10/100 TP Port Configuration All 10/100 TP ports support configuration as follows: Auto-negotiation capable Highest capability : 100M Full duplex Speed : auto-sensing for 100Mbps or 10Mbps Duplex : Full duplex, Half duplex Auto MDI-X function... -
Page 12: Making Fiber Connection
Cables Depending on the connection speed, use the proper UTP cables: Speed Cables used Distance 100M Cat. 5, 5e, or higher grade 100 meters Cat. 3, 4, 5, 5e, or higher grade 100 meters Auto-MDI-X Function An Auto-MDI-X function will automatically detect if a crossover is re- quired and make the swap of Tx pair and Rx pair internally. - Page 13 100FX Duplex Selector This selector is used for 100FX port duplex mode selection as follows: The following table lists the maximum MM fiber cable length connecting to different devices: Connected Device Distance (MMF cable) Network card half-duplex fiber port 400 m Network card full-duplex fiber port 2 km Class I hub half-duplex fiber port...
-
Page 14: Led Indicators
4. LED Indicators 4.1 LED Panel The switch provides comprehensive LED indicators for diagnosing and monitoring the operation of the switch as illustrated below: 4.2 Interpretation LED Functions POWER LED : indicates the power status of the switch. LNK/SPD/ACT LED : indicates the link status, connection speed status, and traffic status of the switched port DUP/COL LED : indicates the duplex status and collision status...
