- Page 1 Industrial 3-Port Fast Ethernet Media Converter Switches KSD-103-A series KSD-103-B series Installation Guide DOC.081111 1/20...
- Page 2 (C) 2008 KTI Networks Inc. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any directive work (such as translation or transformation) without permission from KTI Networks Inc.
- Page 3 The information contained in this document is subject to change without prior notice. Copyright (C) All Rights Reserved. TRADEMARKS Ethernet is a registered trademark of Xerox Corp. FCC NOTICE This device complies with Class B Part 15 the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received including the interference that may cause.
-
Page 4: Table Of Contents
1. Introduction ...5 1.1 Features...6 1.2 Product Panels ...6 1.3 Specifications...7 2. Installation ...10 2.1 Unpacking...10 2.2 Safety Cautions ...10 2.3 DIN-Rail Mounting ...11 2.4 Panel Mounting...12 2.5 Applying Power...13 2.6 Failure Alarm Relay Output ...14 3. Making LAN Connections...16 3.1 Making Copper Port (RJ-45) Connections...16 3.2 Making Fiber Connections ...16 3.3 LED Indication ...17... -
Page 5: Introduction
The switches also provide auto MDI/MDI-X function, which can detect the connected cable and switch the transmission wire pair and receiving pair automatically. This auto-crossover function can simplify the type of network cables used. -
Page 6: Features
High and wide operating Temperature Power input interface: Industrial screw terminal block and DC power jack for external commercial power adapter as option Screw panel and DIN rail mounting support for industrial enclosure Industrial-rated Emission and Immunity performance 1.1 Features Provide 3 switching-base network segments Auto MDI/MDI-X crossover function on the TP copper port Support IEEE 802.3x flow control for full-duplex operation... -
Page 7: Specifications
Cat.5 UTP up to 100 meters Fiber Ports Connectors ST, SC, VF-45, Bi-Directional SC (model dependent) Configuration 100Mbps, Full duplex Network cables MMF 50/125 60/125μm, SMF 9/125μm Eye safety IEC 825 compliant Far end fault support Enabled Switch Functions MAC Addresses Table 1K entries 7/20... - Page 8 Forwarding & filtering Non-blocking, full wire speed Switching technology Store and forward Maximum packet length 1536 bytes max. Flow control IEEE 802.3x pause frame base for full duplex operation Back pressure for half duplex operation Broadcast Storm Protection design DC Power Interface Interface Screw-type terminal block 1.
- Page 9 Certificate Part 15 Class B CE/EMC EMI EN50081-1 Class B EMS EN55024 CE/LVD Safety EN 60950 EN 50081-1/1992 : EN55022:1994/A1:1995/A2:1997 EN61000-3-2:2000 EN61000-3-3:1995/A1:2001 EN 55024:1998/A1:2001 IEC 61000-4-2:1995 ESD Test IEC 61000-4-3:1995 RS Test IEC 61000-4-4:1995 EFT/BURST Test IEC 61000-4-5:1995 Surge Test IEC 61000-4-6:1996 CS Test IEC 61000-4-8:1993 Magnetic Field IEC 61000-4-11:1994 Voltage Int.
-
Page 10: Installation
C ~ 60 C, AC100-240V/50-60Hz DC12V 1A for USA and Germany The adapters are used for supplying DC power to the switch via DC power jack interface. 2.2 Safety Cautions To reduce the risk of bodily injury, electrical shock, fire, and damage to the product, observe the following precautions. -
Page 11: Din-Rail Mounting
label. If you are not sure of the type of power source required, consult your service provider or local power company. 2.3 DIN-Rail Mounting In the product package, a DIN-rail bracket is installed on the device for mounting the device in a industrial DIN-rail enclosure. -
Page 12: Panel Mounting
The final mechanical dimensions after installing DIN rail mounting bracket are: 2.4 Panel Mounting The product is provided with an optional bracket for panel mounting. The bracket supports mounting the device on a plane surface securely. The mounting steps are: 1. -
Page 13: Applying Power
2.5 Applying Power The power specifications of the device are: Operating Voltage +7 ~ +50VDC Power Consumption 4W max. @+50VDC Using Terminal Blocks Either DC1 interface or DC2 interface can be used to receive DC power from an external power system. -
Page 14: Failure Alarm Relay Output
If cascading the power to next device is needed, install the power wires and plug for another switch. Then, use DC2 contacts. Note: Only up to four device units can be cascaded to receive power from one main power input source. - Page 15 Use the provided 2P terminal plug for signal wiring and plug into the PF+/- contacts. Relay Output Indication Alarm Events: Input power failure Specific fiber port link down (To specify the fiber ports, use the DIP SW located on bottom.) KSD-103-A KSD-103-B Note: Be sure the voltage applied on PF+/- contacts is within the specification of 30VDC/1A max.
-
Page 16: Making Lan Connections
If the connected device is also auto-negotiation capable, both devices will come out the best configuration after negotiation process. If the connected device is incapable in auto-negotiation, the switch will sense the speed and use half duplex for the connection. -
Page 17: Led Indication
3.3 LED Indication KSD-103-A KSD-103-B Function Power status UTPx Copper port link status Fiber port link status Note: UTPx = UTP UTP1 UTP, FXx = FX FX1 FX2 State Interpretation The power is supplied to the device. The power is not supplied to the device. Port link is established. -
Page 18: Applications
4. Applications 4.1 Application in Industrial Networks The following figure illustrates an application example in an industrial network. Four devices are cascaded by fiber cables. 4.2 Copper to Fiber Bridging Media Converter Application 4.3 Bridging Multimode to Single Mode Fiber Converter Application 18/20... -
Page 19: Appendix
5. Appendix 5.1 Model Definition KSD-103-A Model Ext. FX Connector Duplex ST Duplex SC Duplex SC -SA2 Duplex SC -SL2 Duplex SC -SL3 Duplex SC -SL4 Duplex SC -SL6 Duplex SC -W3515 BiDi SC -W5315 BiDi SC KSD-103-B Model Ext. FX Ports FX1, FX2 FX1, FX2... -
Page 20: Optical Specifications
5.2 Optical Specifications KSD-103-A Model Ext. FX Port -SA2 -SL2 -SL3 -SL4 -SL6 -W3515 -W5315 KSD-103-B Model Ext. FX Ports FX1, FX2 FX1, FX2 FX1, FX2 -SA2 FX1, FX2 -SL2 FX1, FX2 -SL3 FX1, FX2 -SL4 FX1, FX2 -SL6 FX1, FX2 -W3515 -W5315 -C1Sl2...
