Summary of Contents for Campomatic FC420MS
- Page 1 Refrigerator User’s Manual MODEL:FC420MS...
-
Page 2: Table Of Contents
Please go through this manual before use. Thank you for purchasing our products. Attention: ● Please understand the safety instructions before use. ● Please keep this manual well after reading it for further reference. ● Notice will not be given if this manual is altered due to product improvement. Contents: Name of Parts and Components Preparations before Use... -
Page 3: Name Of Parts And Components
Name of Parts and Components The fridge purchased by you may be not absolutely in accord with this manual. The packing list in the fridge shall prevail. -
Page 4: Preparations Before Use
Preparations before Use Product Properties Warning WARNING – Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING – Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING –... - Page 5 shared with other appliances; ●Please connect the earth wire and the earth electrode of the socket shall have a reliable earth wire. Transportation and Placement Transportation ●Don’t turn over, keep horizontal, extrude or vibrate the fridge. Its inclination shall not exceed 45°when moving it. ●Please don’t hold the door or cap when moving the fridge to avoid any deformation.
-
Page 6: How To Use The Fridge Correctly
mains voltage. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. - Page 7 Freezer Chamber ●Usually, the temperature of the freezer chamber is below －18℃ . It is best to put the food, if stored for a long time, in this chamber. ●Quick frozen food shall be stored in this chamber as quickly as possible when it is not unfrozen.
-
Page 8: Attention
you chould turn the knob to the smaller digit. When the temperature in the fridge is high and the food in the fridge is not fresh in shorter time, you should turn the knob to the bigger digit. Normally, we suggest you turn the knob to the digit 3. -
Page 9: Maintenance
When the fridge runs abnormally or is damaged, please shut off the power supply and notify the local service center. Please splash water onto the top and rear of the fridge, which would lower the insulation. Note: This fridge is designed for household purpose, only suitable for storing food, not for other purposes, such as blood, medicine or biological product, etc. -
Page 10: Fault And Solution
parts); ●Please wipe away the edible oil or spice timely, if attached to the fridge. (which may crack the plastic parts) Lamp and replacement The lamp is 220V/2W(AC) and replaced after shutting off the power supply. Please detach the lampshade first, detach the 3 bolts and then replace LED lamp (detach 3 bolts). - Page 11 If the fridge can’t work soundly still after checkup as abovementioned, please contact our post-sale service office. If the soft cord of power supply is damaged, the replacement must be done by our personnel in order to avoid any danger. Non-fault problems The liquid refrigerant in the capillaries of the fridge flows very fast and sometimes contain a few bubbles, which, as a result, may produce irregular...
-
Page 12: Door Right-Left Change
Door Right-Left Change 1. Remove hinged cover on the top and detach top hinge (Detach) Top hinge cover 2. Detach the door of the cold chamber Remove the door upward 3. Remove the fixing middle-hinge bolts and detach the middle hinge Middle hinge Middle-hinge bolt 4. - Page 13 Remove the door of the freezer chamber upward 5. Remove the fixing lower-hinge bolts and detach the lower hinge Lower Hinge 6. Replace the parts Replace the lower-hinge bolt to the symmetrical position of lower hinge, and mount the lower-hinge module to the symmetrical position of the fridge. Replace the door handle to the symmetrical position of the door.
- Page 14 Bolt cover cap Replace the self-lock and dog on the freezer door to the symmetrical position of the door on the left side. Self-lock and dog Replace the relevant plastic parts to the symmetrical position of the cold-chamber door. Replace the self-lock and dog of the cold chamber to the symmetrical position on the left side.
- Page 15 8. Mount the middle hinge to the symmetrical position with bolts Middle hinge 9. Mount the cold-chamber door remodeled as above to the middle hinge. 10. Mount the left hinge to the left side of the fridge. 11. Put the upper hinge cover in place. (Mount) Top Hinge Cover 12.
- Page 16 Door opened on the right Door opened on the left Correct Disposal of this product Correct Disposal of this product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
