- Page 1 REFRIGERATOR INSTRUCTION MANUAL FR-410 Thank you for selecting this refrigerator. Before using the refrigerator, please read this manual carefully. Code: 318-27-1...
-
Page 2: Feature Chart
FEATURE CHART ! ICE TRAY @ F SHELF (MOVABLE) # FREEZER TEMPERATURE CONTROL KNOB $ ICE BOX % CHILLED CASE DOOR ^ CHILLED CASE & REFRIGERATOR TEMPERATURE & CONTROL SWITCH * R SHELF (MOVABLE) ( LAMP COVER ) VEGETABLE CASE COVER 1 VEGETABLE CASE... - Page 3 2 FREEZER POCKET(SMALL) 3 FREEZER POCKET(MIDDLE) 4 EGG CASE 5 UTILITY POCKET(SMALL/LARGE) 6 UTILITY POCKET(SMALL/SMALL) 7 BOTTLE POCKET(LARGE/LARGE) 8 BOTTLE POCKET(MIDDLE/LARGE)
- Page 4 Here are the features of your new refrigerator. Take a moment to know all the features designed for the convenience of the user. Ice Tray Fill 3/4 of the ice tray with water, as the volume expands when the water is frozen.
- Page 5 Lamp cover To remove the lamp cover 1. Push up the bottom end of lamp cover gently, then pull out. 2. Reverse procedure to join together. Vegetable case May be used for fruit and vegetable storage. Both the vegetable case and its cover shelf are removable for easy cleaning.
-
Page 6: Methods Of Safe Installation
METHODS OF SAFE INSTALLATION 1. SAFE INSTALLATION PLACE FOR YOUR REFRIGERATOR • • Place your refrigerator • Place the refrigerator in Place the refrigerator on where there is no heat an area where the a strong and level floor. source nearby. humidity level is low. -
Page 7: Installation Steps
2. INSTALLATION STEPS • Select a safe place to • Level the refrigerator by • Install the parts in their install your refrigerator. using the adjustable feet. own place. Maintain ~ Level • Check if the doors are • Check the voltage. •... - Page 8 3. WHAT YOU NEED TO KNOW BEFORE MOVING OR RELOCATING THE REFRIGERATOR! • Unplung the power cord. • Detach the grille and the • Take food out of the defrost-drain vessel from refrigerator. the refrigerator with driver and then remove water from the defrost- drain vessel located at the rear of the...
-
Page 9: Cleaning Your Refrigerator
4. CLEANING YOUR REFRIGERATOR • Before you clean the • The refrigerator may • Use a soft cloth for refrigerator, unplug the smell during the initial cleaning the interior and power cord. To clean, operation, but the odour exterior of the use a soft piece of cloth. -
Page 10: How To Install
HOW TO INSTALL Location Install the refrigerator in a convenient location away from extreme heat and cold. Allow at least 6cm clearance between the refrigerator and side wall so that the door may open for a fully usable interior and the refrigerator may have good air circulation. -
Page 11: How To Operate
HOW TO OPERATE 1. TEMPERATURE CONTROL Temperature is controlled by thermostat automatically. The Temperature Control inside the refrigerator controls the degree of cooling for each compartment. Freezer Temperature Control Refrigerator Temperature Control WINTER TEMP. CONTROL MAX WINTER TEMP. CONTROL The control has four settings form The control has the four settings from MIN to WINTER. - Page 12 To control temperature Many factors may influence the internal temperature of the refrigerator and freezer compartments. The temperature and humidity of the surrounding environment. The opening frequency of the doors and the amount of warm food placed in the refrigerator. The combination of food and containers stored in the refrigerator.
-
Page 13: Defrosting The Refrigerator
2. DEFROSTING THE REFRIGERATOR You will never have to defrost your refrigerator as it is designed to defrost itself completely and automatically. CAUTION To avoid the risk of electric shock or death, unplug the power cord before replacing a burned out light bulb or cleaning the inner parts. - Page 14 WHAT TO DO... When not operating for a long time Remove the power supply cord. Dry your refrigerator by opening the door for 2-3 days. When you get ready to move Securely fasten movable interior parts (or remove and pack them separately) DO NOT lay down your refrigerator horizontally, or the compressor may be damaged.
