General Information - Lancom 821 ADSL/ISDN Manual

LANCOM 821 ADSL/ISDN – LANCOM 1621 ADSL/ISDN – LANCOM 1711 VPN
6.1.1

General information

The following entries are required to set up a RAS connection. The first column
indicates whether the information is required for a connection via VPN
(standard method using "preshared keys") and/or ISDN .
Further details to RAS connections via VPN using enhanced methods
can be found in the LCOS reference manual.
Coupling
VPN + ISDN
VPN + ISDN
VPN
VPN
ISDN
ISDN
ISDN
VPN + ISDN
VPN + ISDN
VPN + ISDN
Notes to the individual values:
User name and password: Users authenticate themselves with this
information when dialling in.
Incoming number: The LANCOM uses the optional ISDN caller ID as an
additional user authentication. This security function should not be used
when users dial in from differing locations.
Please refer to chapter "Linking two networks" on page 46 for advice
about the other values required for the installation of a RAS access.
Entry
User name
Password
Shared secret for encryption
Hide local stations for access to remote network (Extranet VPN)?
Incoming number of remote station
TCP/IP routing for access to remote network
IPX routing for access to remote network
IP addresses for the dial-up PCs: static or dynamic by address range (IP
address pool)
NetBIOS routing for access to remote network?
Name of remote workgroup (NetBIOS only)
Chapter 6: Providing dial- up access
55
