Lancom 821 ADSL/ISDN Manual page 48

LANCOM 821 ADSL/ISDN – LANCOM 1621 ADSL/ISDN – LANCOM 1711 VPN
Chapter 5: Linking two networks
Coupling Entry
VPN IP address of remote station
VPN IP network address of the remote network
VPN Netmask of the remote network
VPN Domain name of the remote network
VPN Hide local stations for access to remote net-
work (Extranet VPN)?
ISDN TCP/IP routing for access to remote network
ISDN IPX routing for access to remote network
VPN + ISDN NetBIOS routing for access to remote net-
work?
VPN + ISDN Name of remote workgroup (NetBIOS only)
ISDN Data compression
ISDN Channel bundling
48
In case your device has an ISDN connection, the wizard asks whether the
remote site has ISDN as well.
The type of IP address must be stated for both sides for VPN connections
via the Internet. There are two types of IP addresses: static and dynamic.
An explanation of the two IP address types can be found in the reference
manual.
Thanks to Dynamic VPN, connections can be enabled not only
between gateways with fixed, static IP addresses, but even between gate-
ways with dynamic IP addresses. The active initiation of VPN connec-
tions towards remote sites with dynamic IP addresses requires ISDN.
If you haven't already named your LANCOM, the wizard will ask you for a
new, unique device name. With this entry, you will rename your
LANCOM. Be sure to give the two devices different names.
The name of the remote station is needed for its identification.
Enter the subscriber number of the remote station in the ISDN subscriber
number field. The complete subscriber number including all necessary
area and country codes is required.
The stated ISDN caller ID is used to identify and authenticate callers.
When a LANCOM receives a call, it compares the ISDN caller ID entered
for the remote station with the actual caller ID transferred via the D chan-
nel. An ISDN caller ID generally consists of an area code and an MSN.
Gateway 1
'10.0.2.100'
'10.0.2.0'
255.255.255.0
'head'
yes/no
yes/no
yes/no
yes/no
'workgroup1'
on/off
on/off
Gateway 2
'10.0.1.100'
'10.0.1.0'
255.255.255.0
'branch'
yes/no
yes/no
yes/no
yes/no
'workgroup2'
on/off
on/off
