A. PREPROGRAMMED CYCLES
The Phase 6 OPL microprocessor controller (computer) can store in its memory six (6) preprogrammed cycles
(Keys "A" through "F" on the keyboard [touch pad]). This allows the user to have the six (6) most commonly
used cycles, requiring only the push of a single keyboard (touch pad) entry to start the dryer.
These preprogrammed cycles can be set in either the Automatic Drying Cycle (Mode) (Patent 4,827,627)
where the drying cycle will end when the percentage of extraction (dryness level) programmed has been reached
or in the Timed (Manual) Drying Cycle (Mode) where the dryer will operate for the specific drying time
programmed. These cycles can be programmed in any combination.
Once the drying cycle is completed, the Phase 6 OPL microprocessor controller (computer) then goes into the
Cool Down Cycle where the articles are tumbled in room temperature air. Once the programmed Cool Down
Cycle is completed, the dryer will shut off automatically.
With the Anti-Wrinkle Program active, when the cooling cycle is completed and the dryer is shut off, if the main
door is not opened, the load will be tumbled without heat (i.e., for 20-seconds every 90-seconds). This process
is repeated until either the main door is opened or 10 minutes has elapsed, whichever comes first.
Preprogrammed Cycle Selections:
1. Automatic Drying Cycle (Mode) (Patent No. 4,827,627)
a. For optional reversing models, the Phase 6 OPL microprocessor controller (computer) can be
programmed to reverse or not reverse (single direction rotation).
b. Anti-Wrinkle Program - active or non-active.
c. Drying Temperature - programmable from 160º F to 200º F in one-degree increments or from 71º C to
93º C in one-degree increments.
d. Dryness Level (percentage of extraction) - programmable from 90% to 100% in one-percent increments.
e. Cool Down Time - programmable from 0 to 99 minutes in one-minute increments.
f. Cool Down Temperature - programmable from 70º F to 100º F in one-degree increments or from 20º C
to 37º C in one-degree increments.
g. A Factor
h. b Factor
SECTION III

PROGRAM SELECTIONS

6
