  • Page 1 UPER ® UPER ERVER 7047R-72RF 7047R-72RFT USER’S MANUAL...
  • Page 2 This product, including software and docu- mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Manual

    It provides information for the installation and use of the SuperServer 7047R- 72RF/7047R-72RFT. Installation and maintainance should be performed by expe- rienced technicians only. The SuperServer 7047R-72RF/7047R-72RFT is a high-end server based on the SC745TQ-920B 4U tower/rackmountable chassis and the X9DRH-7F/X9DRH-7TF dual processor serverboard.
  • Page 4 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X9DRH-7F/X9DRH-7TF serverboard, including the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfi...
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SAS ........................ 1-2 SATA ......................1-2 PCI Expansion Slots ..................1-2 I/O Ports ......................1-2 Graphics Controller ..................1-3 Server Chassis Features ................
  • Page 7 Table of Contents Power ......................3-1 Reset ....................... 3-1 Control Panel LEDs ..................3-2 Power ......................3-2 HDD ......................... 3-2 NIC1 ........................ 3-2 NIC2 ........................ 3-2 Information LED ....................3-3 Power Fail ....................... 3-3 Drive Carrier LEDs ..................3-3 Chapter 4 System Safety Electrical Safety Precautions ................
  • Page 8 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual 5-12 Installing Software ..................5-25 Supero Doctor III ................... 5-26 Chapter 6 Advanced Chassis Setup Static-Sensitive Devices .................. 6-1 Precautions ..................... 6-1 Front Control Panel ..................6-3 System Fans ....................6-4 Fan Failure ...................... 6-4 Drive Bay Installation ..................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 7047R-72RF/7047R-72RFT is a high-end server comprised of two main subsystems: the SC745TQ-920B 4U server chassis and the X9DRH-7F/ X9DRH-7TF dual processor serverboard. Please refer to our web site for informa- tion on operating systems that have been certifi ed for use with the system (www.

  • Page 10: Serverboard Features

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Serverboard Features The SuperServer 7047R-72RF/7047R-72RFT is built around the X9DRH-7F/ X9DRH-7TF, a dual processor serverboard based on the Intel C602 chipset and designed to provide maximum performance. Below are the main features of the X9DRH-7F/X9DRH-7TF. (See Figure 1-1 for a block diagram of the chipset).

  • Page 11: Graphics Controller

    Front Control Panel The control panel on the SuperServer 7047R-72RF/7047R-72RFT provides you with system monitoring and control. LEDs indicate system power, HDD activity, network activity, system overheat and power supply failure. A main power button and a system reset button are also included.
  • Page 12 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Figure 1-1. Chipset Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. #H-2 #H-1 #D-2 #G-2 #G-1 #C-2 #C-1 #F-2 #F-1 #B-2 #B-1 #E-2 #A-2 #E-1 E5-2600 E5-2600 #A-1...

  • Page 13: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
  • Page 14 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Notes...

  • Page 15: Chapter 2 Server Installation

    The 7047R-72RF/7047R-72RFT may be employed either as a tower or mounted in a rack as a 4U rackmount chassis.

  • Page 16: Choosing A Setup Location

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for suffi cient airfl ow and ease in servicing.

  • Page 17: Rack Mounting Considerations

    Chapter 2: Server Installation • Allow the hot plug drives and power supply modules to cool before touching them. • Always keep the rack's front door and all panels and components on the servers closed when not servicing to maintain proper cooling. Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera-...

  • Page 18: Installing The System Into A Rack

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Installing the System into a Rack This section provides information on installing the system into a rack unit. Rack installation requires the use of the optional rackmount kit. If the system has already been mounted into a rack or if you are using it as a tower, you can skip ahead to Sections 2-5 and 2-6.

  • Page 19: Installing The Chassis Rails

    Chapter 2: Server Installation Installing the Chassis Rails You will need to remove the top cover and the feet to add rack rails to the chassis. First, remove the top and right covers (top and left covers when standing as a tower chassis) by fi...

  • Page 20: Installing The Rack Rails

    Figure 2-3. Installing the Rails to the Chassis Installing the Rack Rails Determine where you want to place the SuperServer 7047R-72RF/7047R-72RFT in the rack. (See Rack and Server Precautions in Section 2-3.) Position the fi xed rack rail/sliding rail guide assemblies at the desired location in the rack, keeping the sliding rail guide facing the inside of the rack.

  • Page 21: Installing The Server Into The Rack

    Chapter 2: Server Installation Installing the Server into the Rack You should now have rails attached to both the chassis and the rack unit. The next step is to install the server into the rack. You should have two brackets in the rack mount kit.
  • Page 22 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Notes...

  • Page 23: Chapter 3 System Interface

    System Interface Overview The control panel on the 7047R-72RF/7047R-72RFT has several LEDs and two buttons. There are also two LEDs on each hard drive carrier. These LEDs keep you constantly informed of the overall status of the system and the activity and health of specifi...

  • Page 24: Control Panel Leds

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Control Panel LEDs The control panel located on the front of the SC745 chassis has six LEDs that provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective ac- tion you may need to take.

  • Page 25: Information Led

    Chapter 3: System Interface Information LED This LED will be solid blue when the UID function has been activated. When this LED fl ashes red, it indicates a fan failure. When red continuously it indicates an overheat condition, which may be caused by cables obstructing the airfl ow in the system or the ambient room temperature being too warm.
  • Page 26 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Notes...

  • Page 27: Chapter 4 System Safety

    System Safety Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 7047R-72RF/7047R-72RFT from damage: • Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 28: General Safety Precautions

    General Safety Precautions Follow these rules to ensure general safety: • Keep the area around the 7047R-72RF/7047R-72RFT clean and free of clutter. • The 7047R-72RF/7047R-72RFT weighs approximately 70 lbs (31.8 kg.) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight.

  • Page 29: Esd Precautions

    Chapter 4: System Safety • Remove any jewelry or metal objects from your body, which are excellent metal conductors that can create short circuits and harm you if they come into contact with printed circuit boards or areas where power is present. •...

  • Page 30: Operating Precautions

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the 7047R- 72RF/7047R-72RFT is operating to assure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed.

  • Page 31: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference. Remember to completely close the chassis when you have fi...

  • Page 32: Unpacking

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Unpacking The serverboard is shipped in antistatic packaging to avoid electrical static dis- charge. When unpacking the board, make sure the person handling it is static protected. Connecting Cables The cables listed below should already be connected to the serverboard. These include the data cables for the peripherals and control panel and the power cables.

  • Page 33: I/O Ports

    Chapter 5: Advanced Serverboard Setup Figure 5-1. Control Panel Header Pins Ground x (Key) x (Key) Power On LED HDD LED NIC1 LED NIC2 LED OH/Fan Fail LED Power Fail LED Ground Reset (Button) Ground Power (Button) I/O Ports The I/O ports are color coded in conformance with the PC 99 specifi cation. See Figure 5-2 below for the colors and locations of the various I/O ports.

  • Page 34: Installing The Processor And Heatsink

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro web site for updates on CPU support. Installing an LGA2011 Processor Press down on the lever labeled 'Close 1st' 1.
  • Page 35 Chapter 5: Advanced Serverboard Setup 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push 4. Using your thumb and the index down to pop the load plate fi...
  • Page 36 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Warning: You can only install the CPU to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't close properly, do not force it as it may damage your CPU.

  • Page 37: Installing A Cpu Heatsink

    Chapter 5: Advanced Serverboard Setup Installing a CPU Heatsink 1. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the retention mechanism. 2. Screw in two diagonal screws (i.e. the #1 and the #2 screws) until just snug (do not over-tighten the screws, which may damage the CPU.) 3.

  • Page 38: Installing Memory

    RDIMM, LRDIMM ECC or UDIMM ECC/non-ECC memory. Use memory modules of the same type and speed. See the following tables for memory installation. Please refer to the Supermicro web site for possible updates to supported memory. DIMM Installation Installing Memory Modules 1.
  • Page 39 Chapter 5: Advanced Serverboard Setup For memory to work properly, populate according to the tables below. Processors and their Corresponding Memory Modules CPU# Corresponding DIMM Modules CPU 1 DIMMA1 DIMMB1 DIMMC1 DIMMD1 DIMMA2 DIMMB2 DIMMC2 DIMMD2 CPU2 DIMME1 DIMMF1 DIMMG1 DIMMH1 DIMME2 DIMM F2...
  • Page 40 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual UDIMM Memory Support Ranks Per DIMM & Memory Capacity Data Width Per DIMM (Note 1) SRx8 Non-ECC DRx8 Non-ECC SRx16 Non-ECC 512MB SRx8 ECC DRx8 ECC Note: 1Gb/2Gb/4Gb DRAMs are supported; however, only 2Gb and 4Gb DRAMs are validated.

  • Page 41: Adding Pci Add-On Cards

    Chapter 5: Advanced Serverboard Setup Adding PCI Add-On Cards The 7047R-72RF/7047R-72RFT can accommodate seven full-sized PCI add-on cards. Installing an Add-on Card 1. Begin by removing the shield for the PCI slot you wish to populate. 2. Fully seat the card into the slot, pushing down with your thumbs evenly on both sides of the card.

  • Page 42: Serverboard Details

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Serverboard Details Figure 5-4. X9DRH-7F/X9DRH-7TF Layout (not drawn to scale) USB2/3 USB0/1 COM1 LAN CTRL BMC CTRL FAN5 KB/MS IPMI_LAN LAN1 LAN2 COM2 CLOSE 1st CPU2 OPEN 1st Battery T-SGPIO1 BIOS X9DRH-7F/iF Rev. 1.01 JITP0...

  • Page 43: X9Drh-7F/X9Drh-7Tf Quick Reference

    Chapter 5: Advanced Serverboard Setup X9DRH-7F/X9DRH-7TF Quick Reference Jumper Description Default Setting JBT1 Clear CMOS See Section 5-9 C1/JI SMB to PCI-E Slots Pins 2-3 (Normal) JPB1 BMC Enable/Disable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPLAN1 LAN1/LAN2 Enable/Disable Pins 1-2 (Enabled) JPS1 SAS Enable/Disable...
  • Page 44 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Onboard Buzzer (Internal Speaker) T-SGPIO1 Serial Link General_Purpose IO Headers (used in conjunc- tion with I-SATA 0~3) T-SGPIO2 Serial Link General_Purpose IO Header (used in conjunc- tion with I-SATA 4/5) T-SGPIO-S Serial Link General_Purpose IO Header (used in conjunc-...

  • Page 45: Connector Defi Nitions

    Chapter 5: Advanced Serverboard Setup Connector Defi nitions ATX Power 24-pin Connector Pin Defi nitions Pin# Defi nition Pin # Defi nition Power Connectors +3.3V +3.3V -12V +3.3V A 2 4 - p i n m a i n p o w e r s u p p l y connector(J22) and two 8-pin power PS_ON connectors (JPWR1/JPWR2) are...
  • Page 46 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Power Fail LED PWR Fail LED Pin Defi nitions (JF1) The Power Fail LED connection is Pin# Defi nition located on pins 5 and 6 of JF1. Re- fer to the table on the right for pin Ground defi...
  • Page 47 Chapter 5: Advanced Serverboard Setup Power On LED Power LED Pin Defi nitions (JF1) The Power On LED connector is lo- Pin# Defi nition cated on pins 15 and 16 of JF1 (use 5V Stby JLED for a 3-pin connector). This Control connection is used to provide LED indication of power being supplied to...
  • Page 48 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Chassis Intrusion Chassis Intrusion The Chassis Intrusion header is des- Pin Defi nitions ignated JL1. Attach an appropriate Pin# Defi nition cable from the chassis to inform you Intrusion Input of a chassis intrusion when the chas-...
  • Page 49 Chapter 5: Advanced Serverboard Setup Standby Power Pin Defi nitions Standby Power Pin# Defi nition The Standby Power header is located +5V Standby at JSTBY1 on the serverboard. See Ground the table on the right for pin defi ni- Wake-up tions.
  • Page 50 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Universal Serial Bus (USB) FP USB (4/5, 6) Backplane USB Pin Defi nitions (USB 0/1, 2/3) Four Universal Serial Bus ports (USB Pin Defi nitions USB 4, 6 USB 5 0/1, 2/3) are located on the I/O back Pin # Defi...

  • Page 51: Jumper Settings

    Chapter 5: Advanced Serverboard Setup Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used Connector to choose between optional settings. Pins Jumpers create shorts between two pins to change the function of the con- nector.
  • Page 52 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Watch Dog Enable/Disable Jumper JWD controls the Watch Dog function. Watch Dog is a system moni- tor that can reboot the system when a Watch Dog Jumper Settings software application hangs. Jumping Jumper Setting Defi nition...

  • Page 53: 5-10 Onboard Indicators

    Chapter 5: Advanced Serverboard Setup 5-10 Onboard Indicators LAN LEDs The Ethernet ports (located beside the JLAN1/2 LED VGA port) have two LEDs. On each (Connection Speed Indicator) port, the yellow LED fl ashes to indi- LED Color Defi nition cate activity while the other LED may NC or 10 Mb/s be green, amber or off to indicate the...

  • Page 54: 5-11 Sas And Sata Ports

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual 5-11 SAS and SATA Ports SATA Ports SATA Port There are ten Serial ATA Ports (I- Pin Defi nitions SATA0~I-SATA 5) located on the Pin# Defi nition Defi nition serverboard, including eight SATA2 Ground ports (I-SATA2~5, S-SATA0~3) and Ground two SATA3 ports (I-SATA0~1).

  • Page 55: 5-12 Installing Software

    5-12 Installing Software After the hardware has been installed, you should fi rst install the operating system and then the drivers. The necessary drivers are all included on the Supermicro CDs that came packaged with your serverboard. Driver/Tool Installation Display Screen Note: Click the icons showing a hand writing on paper to view the readme fi...

  • Page 56: Supero Doctor Iii

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Supero Doctor III The Supero Doctor III program is a web-based management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The Supero Doctor III program included on the CD-ROM that came with your serverboard allows you to monitor the environment and operations of your system.
  • Page 57 Supero Doctor III Interface Display Screen (Remote Control) Note: SD III Software Revision 1.0 can be downloaded from our Web Site at: ftp://ftp. supermicro.com/utility/Supero_Doctor_III/. You can also download the SDIII User's Guide at: <http://www.supermicro.com/PRODUCT/Manuals/SDIII/UserGuide.pdf>. For Linux, we will recommend using Supero Doctor II.
  • Page 58 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Notes 5-28...

  • Page 59: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform simple maintenance on the SC745TQ-R920B chassis. Following the component installation steps in the order given will eliminate most common problems. If some steps are unnecessary, skip ahead to the step that follows.
  • Page 60 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Figure 6-1. Chassis Front View Main Power System Reset USB Ports 5.25" Drive Bays (2) 8 Hard Drive Bays (behind locking bezel)

  • Page 61: Front Control Panel

    Chapter 6: Advanced Chassis Setup Front Control Panel The front control panel must be connected to the JF1 connector on the serverboard to provide you with system status and alarm indications. A ribbon cable has bundled these wires together to simplify this connection. Connect the cable from JF1 on the serverboard (making sure the red wire plugs into pin 1) to the appropriate comnnec- tor on the front control panel PCB (printed circuit board).

  • Page 62: System Fans

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual System Fans Three 8-cm chassis cooling fans (located in the center of the chassis) provide cool- ing airfl ow while two 8-cm exhaust fans expel hot air from the chassis. The chassis is also fi tted with an air shroud to concentrate the fl ow of cooling air over the areas of highest generated heat.
  • Page 63 Chapter 6: Advanced Chassis Setup Removing the Air Shroud Under most circumstances you will not need to remove the air shroud to perform any service on the system. However, if you wish to temporarily remove it (the air shroud should always be in place when the system is operating), please follow this procedure.

  • Page 64: Drive Bay Installation

    Warning: Regardless of how many drives are installed, all drive carriers must remain in the drive bays to promote proper airfl ow. Warning: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com/products/nfo/ storage.cfm Installing/Removing Hard Drives 1.

  • Page 65: Sas/Sata Backplane

    Chapter 6: Advanced Chassis Setup Figure 6-5. Removing a Drive Carrier Figure 6-6. Mounting a Drive in a Carrier Important! Use extreme caution when working around the SAS/SATA back- plane. Do not touch the backplane with any metal objects and make sure no cables touch the backplane or obstruct the airfl...

  • Page 66: Storage Module

    4. Replace the top/left chassis cover before restoring power to the system. Storage Module If the 7047R-72RF/7047R-72RFT is to be used in a rack confi guration, you must turn the storage module 90 degrees. This can be done before, during, or after setup.
  • Page 67 Chapter 6: Advanced Chassis Setup Figure 6-7. Rotating the Storage Module Storage Module Storage Module Release Lever...

  • Page 68: Power Supply

    The PWR Fail LED will illuminate and remain on until the failed unit has been replaced. Replacement units can be ordered directly from Supermicro (see contact information in the Pref- ace). The hot-swap capability of the power supply modules allows you to replace the failed module without powering down the system.

  • Page 69: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS Setup utility for the X9DRH-7F/X9DRH-7TF. It also provides the instructions on how to navigate the AMI BIOS Setup utility screens. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. Starting BIOS Setup Utility To enter the AMI BIOS Setup utility screens, press the <Del>...

  • Page 70: How To Change The Confi Guration Data

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual How To Change the Confi guration Data The confi guration data that determines the system parameters may be changed by entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing <F2> at the appropriate time during system boot.

  • Page 71: Advanced Setup Confi Gurations

    Chapter 7: BIOS The AMI BIOS main menu displays the following information: System Time/System Date Use this option to change the system time and date. Highlight System Time or System Date using the arrow keys. Enter new values through the keyboard and press <Enter>.

  • Page 72: Boot Feature

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual  Boot Feature Quiet Boot Set this value to allow the bootup screen options to be modifi ed between POST messages or the OEM logo. Select Disabled to allow the computer system to display the POST messages. Select Enabled to allow the computer system to display the OEM logo.
  • Page 73 Chapter 7: BIOS to power off when the user presses the power button for 4 seconds or longer. The options are Instant Off and 4 Seconds Override. Restore on AC Power Loss Use this feature to set the power state after a power outage. Select Stay Off for the system power to remain off after a power loss.
  • Page 74 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual  Socket 1 CPU Information This item displays if a CPU is installed in Socket 1. CPU Speed This item displays the speed of the CPU installed in Socket 1. 64-bit This item indicates if the CPU installed in Socket 1 supports 64-bit technology.
  • Page 75 Chapter 7: BIOS DCU Streamer Prefetcher (Available when supported by the CPU) Select Enabled to support Data Cache Unite (DCU) prefetch to speed up data accessing and processing in the DCU to enhance CPU performance. The options are Disabled and Enabled. DCU IP Prefetcher Select Enabled for DCU (Data Cache Unit) IP Prefetcher support, which will prefetch IP addresses to improve network connectivity and system performance.
  • Page 76 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Turbo Mode This feature allows processor cores to run faster than marked frequency in specifi c conditions. The options are Disabled and Enabled. P-STATE Coordination This feature selects the type of coordination for the P-State of the processor.

  • Page 77: North Bridge

    Chapter 7: BIOS Factory Long Duration Maintained This item displays the period of time set by the manufacturer during which long duration power is maintained. Long Duration Maintained This item displays the period of time during which long duration power is main- tained.
  • Page 78 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual IOH 0 PCIe Port Bifurcation Control This submenu allows the user to confi gure the following 8 PCIe Port Bifurcation Control settings for the IOH 0 PCI-Exp port. This feature determines how to distribute the available PCI-Express lanes to the PCI-E Root Ports.
  • Page 79 Chapter 7: BIOS Port 3C Link Speed Select GEN1 to enable PCI-Exp Generation 1 support for Port 3C. Select GEN2 to enable PCI-Exp Generation 2 support for Port 3C. Select GEN3 to enable PCI-Exp Generation 3 support for Port 3C. The options are GEN1, GEN2, and GEN3.
  • Page 80 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Port 3A Link Speed Select GEN1 to enable PCI-Exp Generation 1 support for Port 3A. Select GEN2 to enable PCI-Exp Generation 2 support for Port 3A. Select GEN3 to enable PCI-Exp Generation 3 support for Port 3A. The options are GEN1, GEN2, and GEN3.
  • Page 81 Chapter 7: BIOS Memory Mode When Independent is selected, all DIMMs are available to the operating system. When Mirroring is selected, the motherboard maintains two identical copies of all data in memory for data backup. When Lockstep is selected, the motherboard uses two areas of memory to run the same set of operations in parallel.
  • Page 82 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Rank Interleaving This feature allows the user to select a rank memory interleaving method. The options are Auto, 1 Way, 2 Way, 4, Way, and 8 Way. Patrol Scrub Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source).

  • Page 83: South Bridge

    Chapter 7: BIOS  South Bridge This feature allows the user to confi gure the settings for the Intel PCH chip. PCH Information This feature displays the following PCH information. • Name: This item displays the name of the PCH chip. •...
  • Page 84 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual SATA Mode Use this feature to confi gure SATA mode for a selected SATA port. The options are Disabled, IDE Mode, AHCI Mode, and RAID Mode. The following are displayed depending on your selection: IDE Mode...
  • Page 85 Chapter 7: BIOS  SAS Confi guration If a SAS port is detected in the system, the following items will be displayed. SCU Devices Select Enabled to enable support for PCH SCU (System Confi guration Utility) de- vices. The options are Disabled and Enabled. OnChip SAS Oprom Select Enabled to support the onboard SAS Option ROM to boot up the system via a storage device if a SAS device is installed.
  • Page 86 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Maximum Payload This feature selects the setting for the PCIE maximum payload size. The options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes. Maximum Read Request This feature selects the setting for the PCIE maximum Read Request size. The options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.

  • Page 87: Serial Port Console Redirection

    Chapter 7: BIOS Network Stack Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Unifi ed Extensible Firmware Interface) for network stack support. The options are Enabled and Disabled. Note that if Enabled, IPV4 and IPV6 PXE support will be disabled. ...
  • Page 88 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual transmission. Select Mark to add mark as a parity bit to be sent along with the data bits. Select Space to add a Space as a parity bit to be sent with your data bits. The options are None, Even, Odd, Mark, and Space.

  • Page 89: Acpi Settings

    Chapter 7: BIOS Console Redirection Select Enabled to use a COM Port selected by the user for Console Redirection. The options are Enabled and Disabled.  Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user.
  • Page 90 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual to use power-reduced mode. Power will only be supplied to limited components (such as RAMs) to maintain the most critical functions of the system. The options are S1 (CPU Stop Clock) and Suspend Disabled. Numa This feature enables the Non-Uniform Memory Access ACPI support.
  • Page 91 Chapter 7: BIOS  Intel TXT(LT-SX) Confi guration This feature indicates if the following hardware components support the Intel TXT (Trusted Execution Technology), which helps protect against software-based attacks and ensures protection, confi dentiality and integrity of data stored or created on the system.

  • Page 92: Event Logs

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Event Logs Use this menu to confi gure Event Log settings.  Change SmBIOS Event Log Settings Enabling/Disabling Options Smbios Event Log Change this item to enable or disable all features of the Smbios Event Logging during boot.

  • Page 93: Ipmi

    Chapter 7: BIOS MECI The Multiple Event Count Increment (MECI) counter counts the number of oc- curences a duplicate event must happen before the MECI counter is incremented. Enter a number between 1 to 255. The default setting is 1. METW The Multiple Event Time Window (METW) defi...

  • Page 94: System Event Log

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual  System Event Log Enabling/Disabling Options SEL Components Select Enabled for all system event logging at bootup. The options are Enabled and Disabled. Erasing Settings Erase SEL Select 'Yes, On next reset' to erase all system event logs upon next system reboot.

  • Page 95: Boot

    Chapter 7: BIOS Station IP Address This item displays the Station IP address for this computer. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). Subnet Mask This item displays the sub-network that this computer belongs to. The value of each three-digit number separated by dots should not exceed 255.

  • Page 96: Security

    UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Boot Option Priorities Boot Option #1/ Boot Option #2/ Boot Option #3 Use this feature to specify the sequence of boot device priority. Network Device BBS Priorities, Hard Drive BBS Priorities This option sets the order of the legacy network devices and Hard Disks detected by the motherboard.

  • Page 97: Save & Exit

    Chapter 7: BIOS Administrator Password Use this feature to set the Administrator Password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 8 characters long. User Password Use this feature to set a User Password which is required to log into the system and to enter the BIOS setup utility.
  • Page 98 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual When the dialog box appears, asking you if you want to exit the BIOS setup without saving, click Yes to quit BIOS without saving the changes, or click No to quit the BIOS and save changes.

  • Page 99: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 100 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Notes...

  • Page 101: Appendix B System Specifi Cations

    Appendix B: System Specifi cations Appendix B System Specifi cations Processors Single or dual Intel® E5-2600 Series (Socket R) processors in LGA 2011 sockets (both CPUs must be of the same type) Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel C602 chipset BIOS...
  • Page 102 UPER ERVER 7047R-72RF/7047R-72RFT User's Manual Serverboard X9DRH-7F/X9DRH-7TF Dimensions: 12 x 13 in (305 x 330 mm) Chassis SC745TQ-R920B, tower/4U rackmount Dimensions (as tower): (WxHxD) 7 x 19 x 27 in. (178 x 483 x 686 mm) Weight 70 lbs. (31.8 kg.)
  • Page 103 Appendix B: System Specifi cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3- 3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 104 ERVER 7047R-72RF/7047R-72RFT User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
