Canon imagePROGRAF iPF8400S Series Setup Manual page 3

Mount the Ink Tanks
1
Press the Power button to turn on the
printer.
4
Instructions on ink tank installation are
shown on the display screen.
Open the ink tank covers as instructed.
7
Open the pouch and remove the ink tank.
• Never touch the ink holes (a)
or metal contacts (b). Touching
these parts may cause stains,
damage the ink tank, and
affect print quality.
• Avoid dropping the ink tank after
removing it from the pouch. Otherwise,
ink may leak and cause stains.
• Do not remove ink tanks to shake them
after they have been mounted. Doing so
may cause ink to spill.
Mount the 8 ink tanks.
2
When the following screen appears, use
the ▲ and ▼ keys to select a language
and press OK.
5
Raise the stopper (a) of the ink tank lock
lever for the color you are mounting. After
raising the ink tank lock lever as far as
possible, pull it forward.
a
• Press down on the ink tank lock lever
until it locks.
• Make sure the ink tank lock lever stays
in the locked position.
8
Orient the ink tanks and mount them in
the holders with ink holes down as shown
in the figure.
a
b
• An ink tank cannot be mounted in the
holder if it is not oriented correctly for
the color.
• Do not try to force an ink tank into the
holder if it does not go in normally.
Check the color indicated on the label
affixed to the ink tank lock lever and
the ink tank orientation, and then try
mounting the tank into the holder again.
Language
English
Français
Italiano
Deutsch
3
3
Select your local time zone and press
OK.
Time Zone
0:London (GMT)
+1:Paris,Rome
+2:Athens,Cairo
+3:Moscow
+4:Eerevan,Baku
6
Shake each ink tank gently 7 to 8 times
before opening its pouch.
• Failure to shake the ink tanks may
result in reduced print quality because
ink ingredients have settled on the
bottom of the tank.
9
After raising the ink tank lock lever as far
as possible, press it back down until it
clicks into place.
