CAUTION: Use the Kenmore part number to order parts, not the illustration number.
# = Functional Parts
* = Non-Illustrated Parts
MOTOR / BLOWER / BELT
POS. NO
PART NO
1
131295200
2
131168200
4
131362400
6
134086300
8
3205245
9
5303304824
10
131784500
10A
134145100
12
131476300
14 #
131658100
15 #
3204307
16
131311900
18
131413600
19
131363901
22
3205241
23
131863100
25 #
134163500
26
5303212870
27
134242400
28 #
134196600
33
131731400
38
3204320
39
131205100
42
3204324
43
131751500
44
3204326
48
131731300
50
3204329
417.94702300
DESCRIPTION
Seal,air duct
Screw,pan head ,8-18B x 0.31
Fastener,push-in
Duct,air
Screw,pan head ,6-18AB x 0.60
Clamp,blower wheel
Housing,blower ,front ,with seal
Housing,blower ,rear
Blower Wheel
Thermostat,heater
Thermostat,control
Screw,quadrex ph ,8-18AB x 0.500
Cradle,motor mount ,with idler stud
Panel,motor cradle mt
Spring,idler
Idler Arm Assy,with pulley
Belt,dryer drive
Block,support ,bottom panel
Clamp,motor mtg.
Motor,dryer drive ,with pulley
Shield,access area ,cover
Elbow,exhaust duct
Screw,#8 pan head ,10-10B x 0.500, cr/sq drive
Bracket,marriage ,interior
Screw,hex head ,12-24T 0.63
Bracket,L mounting ,cabinet rear, external
Panel,dryer ,bottom rear
Cover,safety ,lower front
5
06/03
