Healthrider HREX04981 User Manual

Healthrider user's manual treadmill hrex04981
Hide thumbs

Advertisement

Table of Contents

¨
Model No. HREX04981
Serial No.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Patent Pending

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HREX04981 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Healthrider HREX04981

Summary of Contents for Healthrider HREX04981

  • Page 1 ¨ Model No. HREX04981 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, we will guarantee complete satis- faction through direct assis- tance from our factory.

  • Page 2: Table Of Contents

    ¨ TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............3 BEFORE YOU BEGIN .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the exercise bike. 1. Read all instructions in this manual before using the RC150. 2. It is the responsibility of the owner to ensure that all users of the RC150 are ade- quately informed of all precautions.

  • Page 4: Before You Begin

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please mention the product model number and serial number when calling. The model number is HREX04981. The serial number can be found on a decal attached to the HealthRider manual).

  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the recumbent cycle in a cleared area and remove the pack- ing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench PART CHART Use the part drawings below to identify the small parts used in assembly.
  • Page 6 1. Attach the Front Stabilizer (2) to the front of the Frame (1) with two M8 x 70mm Carriage Bolts (72), two M8 Curved Washers (28), and two M8 Nylon Locknuts (56). Make sure that the Front Stabilizer is turned so the Roller (75) is not touching the floor.
  • Page 7 4. The Console (9) requires two ÒAAÓ batteries (not included); alkaline batteries are recommended. Refer to drawing A. Remove the four indicated screws and lift off the front of the Console. Press two batteries into the battery holder as shown in drawing B.
  • Page 8 7. Attach the Seat Carriage (11) to the Seat Frame (27) using four M8 x 40mm Button Bolts (24), eight M8 Black Flat Washers (57), and four M8 Nylon Locknuts (56). 8. Attach the Seat (12) to the Seat Frame (27) with four M6 x 16mm Hex Screws (29) and four M8 Black Flat Washers (57).

  • Page 9: How To Operate The Recumbent Cycle

    10. Turn the Seat Knob (79) counterclockwise two or three turns to loosen it (if the Seat Knob is not loos- ened enough, the Seat Knob may scratch the Frame [1]). Next, pull the Seat Knob and slide the Seat Carriage (11) onto the Frame (1). Move the Seat (12) to the desired position and release the Seat Knob.
  • Page 10 HOW TO ADJUST THE RESISTANCE To adjust the intensity of your exercise, the resistance of the pedals can be Resistance adjusted. To Control increase the resistance, turn the resistance control clockwise; to decrease the resistance, turn the control counter- clockwise. Important: Stop turning the control when rotation becomes difficult or damage may result.
  • Page 11 Select one of the three pacer programs or the manual mode To select one of the pacer Program Indicator programs, repeatedly press the pro- gram button. The program indicator will Program Button show which program you have select- ed. To select the manual mode, press the program button until the program indicator disappears.

  • Page 12: Maintenance And Troubleshooting

    Turn off the power To turn off the power, simply wait for about six minutes. If the pedals are not moved and the console buttons are not pressed for six min- utes, the power will turn off automatically. HOW TO SELECT KILOMETERS OR MILES The console can display distance and speed in either kilometers or miles.

  • Page 13: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for individuals over the age of 35 or individuals with pre- existing health problems. WARNING: The pulse sensor is not a med- ical device. Various factors may affect the accuracy of heart rate readings.

  • Page 16: How To Order Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling: ¥ The MODEL NUMBER of the product (HREX04981). ¥ The NAME of the product (HealthRider ¥...
