Model No. HREX36500
Serial No.
USERÕS MANUAL
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
Patent Pending
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before using
www.healthrider.com
this equipment. Keep this manual
new products, prizes,
for future reference.
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Healthrider HREX36500
Summary of Contents for Healthrider HREX36500
- Page 1 ¨ Model No. HREX36500 Serial No. USERÕS MANUAL Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, we will guarantee complete satisfaction through direct assistance from our factory.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............2 BEFORE YOU BEGIN . -
Page 3: Before You Begin
Time (excluding holidays). To help us assist you, please mention the product model number and serial number when calling. The model number is HREX36500. The serial number can be found on a decal attached to the exercise cycle (see the front cover of this manual). -
Page 4: Assembly
ASSEMBLY Assembly requires two persons. Place all parts of the recumbent cycle in a cleared area and remove the pack- ing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench PART CHART Use the part drawings below to identify the small parts used in assembly. - Page 5 1. Attach the Front Stabilizer (2) to the front of the Frame (1) with two M8 x 70mm Carriage Bolts (72), two M8 Curved Washers (28), and two M8 Nylon Locknuts (56). Make sure that the Front Stabilizer is turned so the Roller (75) is not touching the floor. 2.
- Page 6 4. The Console (9) requires two ÒAAÓ batteries (not included); alkaline batteries are recommended. Refer to drawing A. Remove the four indicated screws and lift off the front of the Console. Press two batteries into the battery holder as shown in drawing B.
- Page 7 7. Attach the Seat Carriage (11) to the Seat Frame (27) using four M8 x 40mm Carriage Bolts (7), four M8 Black Flat Washers (57), and four M8 Nylon Locknuts (56). 8. Attach the Seat (12) to the Seat Frame (27) with four M6 x 15mm Hex Screws (29) and four M8 Black Flat Washers (57).
-
Page 8: How To Operate The Recumbent Cycle
10. Turn the Seat Knob (8) counterclockwise two or three turns to loosen it (if the Seat Knob is not loos- ened enough, the Seat Knob may scratch the Frame [1]). Next, pull the Seat Knob and slide the Seat Carriage (11) onto the Frame (1). Move the Seat (12) to the desired position and release the Seat Knob. - Page 9 DESCRIPTION OF THE CONSOLE If there is a thin sheet of clear plastic on the face of the console, remove it. The innovative console offers an impressive array of features to help you get the most from your workouts. When the manual program is selected, you can adjust the resistance of the pedals with a touch of a button.
- Page 10 In addition to the matrix, the display will show your pedaling speed, the number of Calories you have burned, the elapsed time, and your total distance. The display will also show your heart rate when the pulse sensor is used (see step 5). Note: If your heart rate is not shown, press the reset button to reset the pulse sensor.
- Page 11 Measure your heart rate if desired Refer to step 5 on page 10. Note: If your heart rate is not shown, press the reset button to reset the pulse sensor. When you are finished exercising, turn off the power To turn off the power, simply wait for about three minutes.
-
Page 12: Maintenance And Troubleshooting
Measure your heart rate regularly During the program, slow your pedaling speed briefly and measure your heart rate regularly (refer to step 5 on page 10). Each time you mea- sure your heart rate, the resistance of the pedals will automatically increase or decrease, if neces- sary, to keep your heart rate near the preselect- ed percentage of your maximum heart rate. -
Page 13: Exercise Guidelines
EXERCISE GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings. -
Page 16: How To Order Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling: ¥ The MODEL NUMBER of the product (HREX36500) ¥ The NAME of the product (HEALTHRIDER ¥...
Need help?
Do you have a question about the HREX36500 and is the answer not in the manual?
Questions and answers
How to replace the battery on a cc125?
To replace the battery on a Healthrider HREX36500:
1. Remove the handlebar (see assembly step 5 on page 6).
2. Remove the four screws securing the front of the console.
3. Lift off the front of the console.
4. Insert two AA alkaline batteries into the battery holder as shown.
5. Reattach the front of the console and secure it with the screws.
6. Reinstall the handlebar.
This answer is automatically generated
