- Page 1 DIAMOND VIEW DV200B Colour TFT LCD Monitor 20.1” (51 cm) LCD Panel Size User’s Manual...
- Page 2 Copyright 2002, Mitsubishi Electric Australia Pty. Ltd. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission.
-
Page 3: Table Of Contents
Windows Software Installation .......12 Setting the Display Resolution .......16 Adjusting the Monitor ........20 Picture Optimisation ..........20 The DV200B Monitor’s Controls ........ 21 On Screen Display Functions ........22 Manual Picture Adjustment - D-Sub Input ....26 Security Lock Installation ......28 Troubleshooting ..........29... -
Page 4: Copyright Notice
Diamond View is a registered trademark of Mitsubishi Electric Australia Pty. Ltd. Microsoft and Windows are registered trademarks of Microsoft Corporation. -
Page 5: Important Safety Instructions
Important Safety Instructions Please read the following safety instructions before installing or cleaning your Diamond View monitor: Unplug the monitor power cable from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a soft cloth to clean the monitor’s screen and cabinet. -
Page 6: Features
Watts. ◆ On Screen Display Allows you to adjust all settings simply using on-screen menus. ◆ High Quality Ratiometric Expansion With any resolution within the monitor's specified range, your Diamond View DV200B monitor can expand the image to full screen. - Page 7 ◆ Removable Stand with VESA Standard Mounting ◆ Dual Computer Signal and Dual Video Inputs The DV200B can display 4 types of video signal: Analogue RGB (PC-type VGA graphics via the monitor’s D-Sub con- nection), DVI-D, S-Video and Composite video. Connect external video sources, such as computers, VCRs, video cameras and DVD players directly to the monitor.
-
Page 8: Unpacking The Monitor
Please check that the following items are included with your monitor. If they are missing or damaged, please contact your place of purchase immediately. ◆ DV200B LCD monitor ◆ This User’s Manual ◆ VGA signal cable 1- D-Sub (attached) ◆ DVI-D signal cable 2- DVI-D ◆... -
Page 9: Hardware Installation
Hardware Installation Step 1 Remove the cover from the back of the monitor. To do this, push the cover in on either side, where it is marked with the two arrows. Step 2 Pull the cover down. - Page 10 Step 3 Connect power cord to AC adaptor, and plug the AC adap- tor into DC19V jack at the rear of the monitor. Connect the power cord to an AC power socket. Step 4 Connect a signal cable or cables to the computer, DVD player or other image source.
- Page 11 Step 5 Put the cover back and push it upwards until it is closed.
-
Page 12: Windows Software Installation
Click the Have Disk button at the bottom right corner. The Install From Disk window will appear with the floppy drive A:\ selected. Click OK. Select DV200B from the list and click OK again to install the driver. You will be returned to the Advanced Graphics Properties dialogue. - Page 13 Click the Next button. Select Search for the best driver for your device (recommended) and click Next. Insert the Diamond View LCD Monitor Utilities floppy disk into your floppy disk drive. Select the Floppy disk drive check box and click Next.
- Page 14 In the next window, click Have Disk. The Install From Disk dialogue will open. The default drive is the floppy disk drive, A:\. Click OK. 10. Select the DV200B LCD monitor from the list and then click Next twice. A window displaying the message “Digital Signature Not Found“...
- Page 15 Windows XP 1. Use the mouse to right-click on the Windows desktop and choose Properties. 2. Select the Settings tab and click the Advanced button. A small window will pop up. Select the Monitor tab in the new window and then click Properties. 3.
-
Page 16: Setting The Display Resolution
All Liquid Crystal Displays (LCDs) have a fixed resolution that is the same as the maximum graphics resolution that may be displayed. In the case of the DV200B the LCD resolution is 1600 x 1200 pixels. This is also known as the “native” resolu- tion of the monitor. -
Page 17: Supported Graphics Modes And Refresh Rates
Table 1 on the next page. Other graphics signals may be dis- played poorly or not at all. Note that the DV200B’s preset modes correspond to VESA standard graphics signals for these resolutions. - Page 18 tab and click the Advanced Properties button. 3. Select the Adapter tab. The refresh rate selection field is located in the centre, at the bottom of the dialogue box. 4. Choose a refresh rate that corresponds with one of the factory modes from the table below.
- Page 19 Resolution Horizontal Vertical Pixel Comments Frequency Frequency Frequency (kHz) (Hz) (MHz) 720x400 31.47 (N) 70.08(P) 28.32 640x480 31.47 (N) 60.00(N) 25.18 640x480 37.50 (N) 75.00(N) 31.50 VESA 800x600 37.88 (P) 60.32(P) 40.00 VESA 800x600 46.87 (P) 75.00(P) 49.50 VESA 1024x768 48.36 (N) 60.00(N) 65.00...
-
Page 20: Adjusting The Monitor
Adjusting the Monitor Picture Optimisation The easiest way to obtain an optimal picture is by using the monitor’s AUTO button. This only works reliably if the com- puter’s graphics adaptor is set to use one of the monitor’s fac- tory modes (see Table 1 in the previous chapter) and if you are displaying an appropriate full-screen test pattern. -
Page 21: The Dv200B Monitor's Controls
D-SUB Power Composite Input Menu DVI-D The 8 buttons on the front of the DV200B monitor perform the following functions: Power Turns the monitor on or off. Auto Automatically adjusts and optimises the picture, based on the currently displayed image. For best results, run the test pattern program (Auto.exe, sup-... -
Page 22: On Screen Display Functions
On Screen Display Functions Press Menu to open the On-Screen Display (OSD) and adjust the monitor. The OSD has 8 sub-menus, organised in separate functional groups: Luminance, Geometry, Color, OSD, Language, Recall, PIP and OSD. Press ↑ or ↓ to select the required functions and press Menu again to open the Luminance sub-menu. - Page 23 The 1:1 setting displays an image that has the same resolution as the connected signal. Signals that have a lower resolution than the monitor’s LCD panel are displayed with a black border around them. The Fill selection causes the image to be scaled to fill the full screen.
- Page 24 Changes the position of the On Screen Display on the screen. Three items can be set: H. Position The horizontal position of the image. V. Position The vertical position of the image. OSD Time The idle time before the OSD switches off Language Select the language that is used by the On Screen Display.
- Page 25 Picture In Picture (PIP) Enables and configures the Picture-In-Picture window. The PIP window is used to display a video image from either the Com- posite video or the S-Video input, while computer graphics are being displayed on the main part of the screen, from either the D-Sub or the DVI-D input.
-
Page 26: Manual Picture Adjustment - D-Sub Input
Manual Picture Adjustment - D-Sub Input This section applies to the D-Sub input, only, as it is the input connection for analogue RGB graphics, including VGA-type signals. Adjustments to the displayed image are made using the On-Screen Display’s Geometry submenu, described previ- ously in this chapter. - Page 27 If you are still not satisfied with the result, try repeating the pro- cedure using a graphics signal that has a different refresh rate. Notes: For best results, you must use one of the factory modes. If the AUTO button is not working, or the NON PRESET MODE mes- sage is shown on the OSD you are not using one of the sup- ported modes.
-
Page 28: Troubleshooting
Troubleshooting Frequently Asked Questions (FAQ) 1. The image is blurred, how can I get the best quality picture? Please read chapters 6 and 7 of this manual for information about selecting the correct type of video signal and adjusting the monitor for best performance. For computer graphics, set the computer’s graphics adaptor to display a resolution of 1600 pixels x 1200 pixels. - Page 29 Check the monitor's colour settings. Press the Menu button to open the OSD, select Recall and the press Menu. Select Colour Recall and press Menu to restore the factory colour settings. 3. No image is displayed, what can I do? Check that you have selected the correct input.
-
Page 30: Specifications
Specifications Model DV200B Display type Active Matrix Thin Film Transistor Viewable diagonal size 20.1" / 51cm Native (maximum) Resolution 1600 x 1200 pixels Colours 16.7 million Contrast Ratio / Brightness 350:1 / 250 cd/m² maximum Response time 45 ms Viewing angle... -
Page 31: Service Contacts
Service Contacts If problems remain after checking this manual, please contact your place of purchase or your nearest Mitsubishi Electric office. Australian Service Contacts Visit the Mitsubishi Electric Australia web site at www.mitsubishi-electric.com.au For details of your nearest Mitsubishi Electric Authorised Ser- vice Centre or contact the Service Department for your state: New South Wales and the Australian Capital Territory 348 Victoria Road... - Page 32 South Australia and the Northern Territory 77 Port Road Hindmarsh, SA, 5007 Telephone: (08) 8340-0444 Fax: (08) 8340-0555 Victoria and Tasmania 4 / 303 Burwood Hwy East Burwood, Vic, Telephone: (03) 9262-9899 Fax: (03) 9262-9850 Western Australia 5 / 329 Collier Road Bassendean, WA, 6054 Telephone: (08) 9377-3411...
