Diamond View DV19NF User Manual

Colour monitor 19” (48.3cm) crt size, 18” (45.7cm) max. viewable area
Hide thumbs
Table of Contents

Advertisement

Quick Links

DIAMOND VIEW MONITORS
DIAMOND VIEW MONITORS
DIAMOND VIEW MONITORS
DIAMOND VIEW MONITORS
A TRADE MARK OF MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD.
A TRADE
A TRADE
A TRADE
MARK OF MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD.
MARK OF MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD.
MARK OF MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD.
DV19NF
Colour Monitor
19" (48.3cm) CRT Size,
18" (45.7cm) Max. Viewable Area
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Diamond View DV19NF

Summary of Contents for Diamond View DV19NF

  • Page 1 DIAMOND VIEW MONITORS DIAMOND VIEW MONITORS DIAMOND VIEW MONITORS DIAMOND VIEW MONITORS A TRADE A TRADE A TRADE A TRADE MARK OF MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD. MARK OF MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD. MARK OF MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD.

  • Page 3: Table Of Contents

    Table of Contents Safety Instructions for Display Monitors..................ii Maintenance..............................iii Chapter 1 Introduction............................1 Unpacking the Package ..........................1 Features................................1 Power Management ..........................2 Chapter 2 Getting Started ..........................3 Installing the Monitor ..........................3 Connecting the Signal Cable.......................3 Connecting through D-SUB signal connector..............4 Connecting through BNC signal connector..............4 Chapter 3 Adjusting the Monitor........................5 A Look at the Control Panel ......................5...

  • Page 4: Monitor Information

    For the convenience of service, write following related information of your monitor in the space below. The serial number is on the back of the product. Monitor Information Product Name: DV19NF Serial Number: Date of Purchase: Dealer Information Dealer: Telephone Number:...

  • Page 5: Safety Instructions For Display Monitors

    Safety Instructions for Display Monitors The AC plug isolates this equipment from the AC power supply. Unplug the monitor from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. Slots and openings in the cabinet and the back or bottom are provided for ventilation.

  • Page 6: Maintenance

    Maintenance ✘ Do not expose the monitor to direct sunlight or heat. ✘ Do not spill liquid onto the monitor. ✘ Do not attempt to open the monitor. You may be hurt by electric shock. For service, call your place of purchase.

  • Page 7: Chapter 1 Introduction

    Write down the related information of your monitor and dealer in the space on page ii for future reference. Features Your DV19NF has the following features: Plug’n Play Compatibility With its DDC1 and DDC2B, it is compatible with Plug’n Play feature of ...

  • Page 8: Power Management

    Easy to Use On Screen Display The On-Screen Display (OSD) allows you to adjust all settings simply with on- screen menus. Power Saving Function The power management complies with VESA DPMS standard. When the system is idle (off mode), the monitor automatically cuts its power consumption up to 95%. Green Commitment No CFCs are used in the manufacturing process of your monitor.

  • Page 9: Chapter 2 Getting Started

    Connect the power cord to the monitor and attach it to power source. Turn on the computer and the monitor. Connecting the Signal Cable Your DV19NF provides D-SUB and BNC signal connectors. The D-SUB or BNC signals can automatically be detected by its microprocessor.

  • Page 10: Connecting Through D-Sub Signal Connector

    Connecting through D-SUB signal connector Make sure that the system power is turned off. Connect the computer end of the D- SUB cable to the 15-pin output connector on the video board of your computer. Connect the monitor end of the D- SUB cable to the D-SUB receptacle on the back of the monitor.

  • Page 11: Chapter 3 Adjusting The Monitor

    Adjusting the Monitor A Look at the Control Panel Adjusting the Monitor You can adjust the monitor with the On-Screen Display (OSD) menus. There are 6 keys for user’s control. They include Exit, , Enter. Auto and Power Switch. The following is the introduction: Panel key introduction Auto: Intelligent key used for auto-calibration of picture size and position.

  • Page 12: Selecting Function And Making Adjustments

    Selecting function and making adjustments 1) Auto (Auto-calibration hot-key) Pressing Auto, the monitor will automatically adjust the display’s size and position to the optimum settings. In some cases , or for some applications , these settings may need to be fine tuned using the Geometry controls. 2) Contrast hot-key mode 1.

  • Page 13: Make Adjustments

    Make adjustments In Main Menu: Press to locate the item you desire to change. Press Enter to go into the Sub Menu.

  • Page 14: Control Functions Available In Main Menu

    to locate the function item. Then press Enter and Press make the adjustment. Press Exit to save the setting. Press Exit to return to main menu. Control functions available in main menu Luminance Contrast: adjusts the difference between the light and dark areas. Brightness: adjusts the brightness of the display.

  • Page 15: Colour Adjustment

    Unbalance: adjusts the pincushion balance if both sides of the display are bowed toward the left or right. Trapezoid: makes the vertical edges of the display parallel. Parallelogram: aligns the top and bottom edges of the image. Top corner: adjusts the edge curvature at the top corners of the image. Bottom corner: adjusts the edge curvature at the bottom corners of the image.
  • Page 16 Recall geometry preset setting and press Enter to recall the preset settings. The word “Recall” will keep Locate blinking on the screen in the process of recall. This page is also a “status display” that shows current horizontal and vertical frequencies. Please note that the resolution data is only displayed if you are using a graphics signal that corresponds with one of the monitor’s presets.

  • Page 17: Timing Setting

    Note: The setting of each parameter is represented by a numeric value and corresponding scale. The on-screen menu will automatically disappear after 20-seconds of inactivity. If changes have been made, the monitor will automatically save them. Timing Setting By making adjustments of your video card settings, you can set the timing and the refresh rate to your preferences.

  • Page 18: Factory Preset Timings

    Factory Preset Timings Mode Resolution Vertical Horizontal Frequency (Hz) Frequency (KHz) Industry 640 x 400 31.47 Industry 640 x 480 31.47 VESA 800 x 600 46.88 VESA 800 x 600 53.67 VESA 1024 x 768 60.02 1024 x 768 60.24 VESA 1024 x 768 68.68...

  • Page 19: Chapter 4 Troubleshooting And Useful Hints

    Troubleshooting and Useful Hints Troubleshooting Make sure that your monitor is properly installed if you encounter any trouble using this product (For hardware installation, see Chapter 2, Getting Started). If the problems persist, check this chapter for possible solutions. There is no picture on the screen. Check: Video sync signal.
  • Page 20 Colours are impure. Check the signal cable and connector pins. If there are bent or missing pins, consult your place of purchase. Adjust related settings. See Chapter 3, Adjusting the Monitor. Move any sources of magnetic fields away from the monitor. These include speakers and power supplies.

  • Page 21: Need More Help

    Need More Help? If your problems remain after checking this manual, please contact your place of purchase or contact: Australia Visit the Mitsubishi Electric Australia web site at www.mitsubishi-electric.com.au Or contact the Service Department for your state: New South Wales and Australian Victoria and Tasmania Capital Territory 4 / 303 Burwood Hwy...

  • Page 22: Chapter 5 Specifications

    Specifications Picture Tube Size 19” (48.3cm) diagonal Type Natural Flat Tube AG pitch 0.25mm aperture grille pitch (at center) 0.27mm aperture grille pitch (at edges) Surface coating AR film (AR, AS) coating Maximum Viewable Size 18” (45.7cm) diagonal Power Supply (Universal) Input voltage 100~240 V AC, 50~60 Hz (Universal) Power consumption(Max.)

  • Page 23: Ambient Temperature

    Ambient Temperature Operating +5°C ~ +40°C / +41°F ~ +104°F Storage -20°C ~ +60°C / -4°F ~ +140°F Humidity Operating 20% ~ 90% Storage 10% ~ 90% Dimensions (W x H x D) 474 mm (W) x 485 mm (H) x 483 mm (D) Weight (net) 28 Kg...
