- Page 1 ® DIAMOND VIEW DV190 Colour TFT LCD Monitor 19.0” (48.26 cm) LCD Panel Size User’s Manual...
- Page 2 Copyright 2003, Mitsubishi Electric Australia Pty. Ltd. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission.
-
Page 3: Table Of Contents
Table of Contents Important Safety Instructions .......... 3 Features ................4 Unpacking the Monitor ............. 5 Hardware Installation............6 VGA Cable Installation............6 DVI-D Cable Installation …………………………………….7 Power Cable Installation ........... 7 Windows Software Installation ........8 Windows 95 ..............8 Windows 98 .............. -
Page 4: Reference Information
Diamond View is a registered trademark of Mitsubishi Electric Australia Pty. Ltd. Microsoft and Windows are registered trademarks of Microsoft Corporation. -
Page 5: Important Safety Instructions
Important Safety Instructions Please read the following safety instructions before installing or cleaning your Diamond View monitor: The AC adapter isolates this equipment from the AC supply. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a soft cloth to clean the monitor housing and sticky tape to remove dust and fingerprints from the screen panel. -
Page 6: Features
Features Your Diamond View DV190 Monitor has the following features: ♦ High Resolution, 1280 x 1024 Pixel LCD Panel ♦ Super Slim Bezel Border Design ♦ High Brightness, Contrast Ratio and Super Wide Viewing Angle 250 cd/m² brightness, 700:1 contrast ratio and ±85/±85(H/V) viewing angle. -
Page 7: Unpacking The Monitor
Unpacking the Monitor Please check that the following items are included with your monitor. If they are missing or damaged, please contact your place of purchase immediately. ♦ LCD monitor ♦ User’s manual ♦ VGA cable ♦ DVI-D cable ♦ Power adapter ♦... -
Page 8: Hardware Installation
If you are unsure, please contact your electricity supplier. To install your Diamond View DV190 monitor: VGA Cable Installation 1. Make sure that the power to the computer and to the monitor are both turned off. -
Page 9: Dvi-D Cable Installation
DVI-D Cable Installation(Optional) 1. Make sure that the power to the computer and to the monitor are both turned off. 2. Connect one end of the monitor’s DVI-D cable to the digital DVI-D connector (24-pin socket) of the computer‘s graphics card. 3. -
Page 10: Windows Software Installation
Installation To get best performance with Windows 95, 98, Millenium Edition, 2000 or XP you should set the PC to use the driver supplied with your DV190 monitor. Windows 95 The first time you start Windows after connecting your new monitor, the system will detect it and automatically install the driver for Plug and Play displays. -
Page 11: Windows Millennium Edition (Windows Me)
The first time you start Windows with a new monitor; the system will detect it and automatically start the Add New Hardware wizard. 1. Insert the Diamond View LCD Monitor Utilities floppy disk into your floppy disk drive. Select the Floppy disk drive check box and click Next. - Page 12 Next. 6. Select Have Disk…, then use Browse, navigate to the floppy drive, highlight the MEA DV190 driver and click Open and OK. 7. Highlight the monitor driver in the Models list and click Next. If a Windows Logo testing window appears, click on Continue Anyway.
-
Page 13: Setting The Display Resolution
LCD. In the case of the DV190 the LCD resolution is 1280 x 1024 pixels. This is also known as the “native” resolution of the monitor. Lower resolutions can be displayed at full screen through an interpolation circuit. -
Page 14: Supported Graphics Modes And Refresh Rates
Table 1 on the next page. Other graphics signals may be displayed poorly or not at all. Note that the DV190’s preset modes correspond to VESA standard graphics signals for these resolutions. All recent models of graphics adaptor should be able to support these modes. - Page 15 • Graphics modes that are not listed in the table may not be supported. For an optimal picture it is recommended that you choose a graphics mode with a resolution of 1280 x 1024pixels that is listed in Table 1 on the next page.
- Page 16 Horizontal Vertical Pixel Resolution Frequency Frequency Frequency Comments (kHz) (Hz) (MHz) 640x350 31.47(P) 70.08(N) 25.17 720x400 31.47(N) 70.08(P) 28.32 640x480 31.47(N) 60.00(N) 25.18 640x480 37.86(N) 72.80(N) 31.50 VESA 640x480 37.50(N) 75.00(N) 31.50 VESA 640x480 35.00(N) 66.67(N) 30.24 Macintosh 800x600 37.88(P) 60.32(P) 40.00 VESA...
- Page 17 Input Signal (Multi-scan mode) Horizontal Vertical Pixel Resolution Comments Frequency Frequency Frequency (kHz) (Hz) (MHz) 1024x768 60.02(P) 75.00(P) 78.75 VESA 1024x768 60.24 (N) 74.93 (N) 80.00 Macintosh 1152x864 67.50(P) 75.00(P) 108.00 VESA 1152x870 68.68(N) 75.06(N) 100.00 Macintosh 1152x900 61.80(N) 66.00(N) 94.50 1152x900 61.80(N)
-
Page 18: Adjusting The Monitor
Adjusting the Monitor Picture Optimisation The easiest way to obtain an optimal picture is by using the AUTO button. This only works reliably if the graphics adaptor is set to use one of the monitor’s factory modes (see Table 1 in the previous chapter) and if you are displaying an appropriate full-screen test pattern. - Page 19 6 5 4 3 2 1 1.Power on/ off: Turn the monitor on or off. 2.Enter: Enter sub-menus, select items, save changes. Hot Key: Press and hold for 3 seconds, to select between “ Picture Mode” and “ Text Mode”. ( Note* ) 3.
- Page 20 To manually adjust the image: 1. Display the adjustment test pattern. This is the best way to observe changes as you adjust the image. Windows users should run the Auto.exe test pattern program. For non-Windows operating systems, you also can use the test pattern described in the previous section or another full-screen image, such the desktop of the operating system.
- Page 21 The monitor will remember your settings and use them whenever you turn the monitor on. Note that you may need to readjust the monitor if it is connected to a different computer or if the computer’s graphics adaptor is replaced.
-
Page 22: Security Lock Installation
Security Lock Installation The Diamond View DV190 can be secured to your desk or any other fixed object with a Kensington lock security product. The Kensington lock‘s cable can be attached to a slot located at the rear of the monitor. -
Page 23: Frequently Asked Questions
Frequently Asked Questions The image is blurred, how can I get the best quality picture? - Read chapter 6, Setting the Display Resolution, and then select a graphics signal with the correct resolution and refresh rate. Then read chapter 7, Adjusting the Monitor, and make adjustments to the displayed image based on these instructions. - Page 24 No image is displayed, what can I do? - Check that the light (LED) next to the monitor’s power button is lit and is green in colour. If the LED is green, press the "Exit" button on the monitor to access the On Screen Display. If the message "NON PRESET MODE" appears there, please read chapter 6, Setting the Display Resolution and reset the graphics card to one of the monitor’s supported graphics signals.
-
Page 25: Specifications
Specifications Model Diamond View DV190 Display Characteristics Display Type 19.0“ active matrix Thin Film Transistor Liquid Crystal Display Viewable Diagonal Area 48.26 cm / 19.0” Native (Maximum) Resolution 1280 x 1024 pixels Colours 16.7 million Contrast Ratio / Brightness 700:1 / 250 cd/m² (typical) - Page 26 Synchronisation TTL separate, composite TTL Signal Connection 15-pin mini D-sub cable 24- pin DVI-D cable Physical Characteristics Power Management VESA DPMS, Energy Star Maximum Power Consumption 40 Watts Power Saving Mode < 1 Watts Operating Voltage Automatic switched mode power supply, 100 - 264 V, 50 - 60Hz Dimensions (W x H x D) 415.4 x 436.1 x 192.7 mm...
-
Page 27: Service Contacts
Service Contacts If problems remain after checking this manual, please contact your place of purchase or contact Australian Service Contacts Visit the Mitsubishi Electric Australia web site at www.mitsubishi-electric.com.au For details of your nearest Mitsubishi Electric Authorised Service Centre or contact the Service Department for your state: New South Wales and Australian Capital Territory 348 Victoria Road... -
Page 28: New Zealand Service Contacts
Victoria and Tasmania 4 / 303 Burwood Hwy East Burwood, Vic, 3151 Telephone: (03) 9262-9899 Fax: (03) 9262-9850 Western Australia 5 / 329 Collier Road Bassendean, WA, 6054 Telephone: (08) 9377-3411 Fax: (08) 9377-3499 New Zealand Service Contacts Contact: BDT Ltd. 1 Parliament St.
