Summary of Contents for Diamond View DV154
- Page 1 DIAMOND VIEW DV154 Colour TFT LCD Monitor 15” (38.1 cm) LCD Panel Size...
- Page 2 Copyright 2001, Mitsubishi Electric Australia Pty. Ltd. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission.
-
Page 3: Table Of Contents
Table of Contents 1 Important Safety Instructions ..........1 2 Features................2 3 Unpacking the Monitor .............3 4 Monitor Overview .............4 5 Hardware Installation ............5 6 Windows Software Installation ........6 Windows 95 ..............6 Windows 98 ..............6 Windows Me (Millennium Edition) ........7 Windows 2000 ..............7 Windows XP ..............8 7 Setting the Display Resolution ........9 Choosing the Best Resolution...........9... -
Page 4: Reference Information
Diamond View is a registered trademark of Mitsubishi Electric Australia Pty. Ltd. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other trademarks remain the property of their respective owners. -
Page 5: Important Safety Instructions
Important Safety Instructions Please read the following safety instructions before installing or cleaning your Diamond View monitor: 1. Unplug the monitor’s power cable from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a soft cloth to clean the monitor housing. -
Page 6: Features
♦ High Quality Ratiometric Expansion With any resolution within the monitor’s specified range, your Diamond View DV154 monitor can expand the image to full screen. ♦ Auto Adjustment Function The auto-adjustment key automatically optimises the displayed image. -
Page 7: Unpacking The Monitor
Unpacking the Monitor Please check that the following items are included with your monitor. If they are missing or damaged, please contact your place of purchase immediately Utilities and Driver LCD monitor User’s Manual Floppy Diskette Audio Cable Power Cord Extension Base Locate the model name and the serial number label on the back of your monitor, and write the details of the monitor and your place of purchase in... -
Page 8: Monitor Overview
Monitor Overview Front View Back View Audio jack for audio cable Video jack for video cable Power jack for power cable... -
Page 9: Hardware Installation
If you are unsure, please contact your electricity supplier. To install your Diamond View DV154 monitor: 1. Make sure that the power to the computer and the power to the monitor are both turned off. -
Page 10: Windows Software Installation
5. Click the Have Disk button at the bottom right corner. The Install From Disk window will appear with the floppy drive A:\ selected. Click OK. 6. Select DV154 from the list and click OK again to install the driver. 7. You will be returned to the Advanced Graphics Properties dialogue box. -
Page 11: Windows Me (Millennium Edition)
4. Select the Driver tab and click Update Driver. 5. The Upgrade Device Driver Wizard will start. Click Next. 6. Insert the Diamond View LCD Monitor Utilities disk into your floppy disk drive. 7. Select Display a list of the known drivers for this device so that I... -
Page 12: Windows Xp
The default drive is the floppy disk drive, A:\. Click OK. 9. Select the DV154 LCD monitor from the list and then click Next twice. 10. The Digital Signature Not Found window might appear. Click Yes and then click Finish to complete the driver installation. -
Page 13: Setting The Display Resolution
LCD monitor. In the case of the DV154 the LCD resolution is 1024 x 768 pixels. This is also known as the native resolution of the LCD monitor. Lower resolutions can be displayed at full screen through an interpolation circuit. -
Page 14: Supported Graphics Modes And Refresh Rate Selection10
Table 1 on the next page. Other graphics signals may be displayed poorly or not at all. Note that the DV154’s preset modes correspond to VESA or Apple Macintosh standard graphics signals for these resolutions. All recent models of graphics adaptor should be able to support these modes. - Page 15 it is still visible after using the Automatic adjustment, you can usually improve the displayed image by manually adjusting the phase, horizontal position and pixel frequency settings using the "Geometry" menu. See Chapter 8, Adjusting the Monitor, for more details. •...
-
Page 16: Adjusting The Monitor
Adjusting the Monitor Picture Optimisation The easiest way to obtain an optimal picture is by using the Auto button. This only works reliably if the graphics adaptor is set to use one of the monitor’s factory modes (see Table 1 in the previous chapter) and if you are displaying an appropriate full-screen test pattern. - Page 17 Auto Exit Enter Auto Exit Enter Power Automatically adjusts the vertical position, pixel phase, horizontal Auto position and pixel clock. Exit Return to the main menu or exit the OSD menu without saving. Press the exit key when the OSD is not displayed to adjust the audio volume.
-
Page 18: Restoring The Factory Default Settings
lines or a uniform level of noise will appear across the image once the clock adjustment is correct. Close the clock submenu by pressing Exit. 6. Select Horizontal Position and press Enter. 7. Adjust the horizontal position so that the image is centred. Its width should be the same as the visible width of the screen. -
Page 19: On Screen Display Functions
On Screen Display Functions The On Screen Display (OSD) provides functions that allow you to adjust the displayed image, change the audio volume, reset the monitor and get information about the displayed graphics signal. The OSD has five functional groups for Luminance, Geometry, Colour, Miscellaneous functions and Auto Setup. -
Page 20: Frequently Asked Questions
Frequently Asked Questions The image is blurred, how can I get the best quality picture? Read chapter 7, Setting the Display Resolution, and select a graphics ♦ signal with the correct resolution and refresh rate. Then read chapter 8, Adjusting the Monitor, and make adjustments to the displayed image based on these instructions. - Page 21 No image is displayed, what can I do? Check that the light (LED) next to the monitor’s power button is lit and ♦ is green in colour. If the LED is green, press the Exit button on the monitor to access the On Screen Display. If the message NON PRESET MODE appears there, please read chapter 7, Setting the Display Resolution and reset the graphics card to one of the monitor’s supported graphics signals.
-
Page 22: Specifications
Specifications Diamond View DV154 Model: Display Characteristics Display Type 15“ active matrix Thin Film Transistor Liquid Crystal Display Viewable Diagonal Area 38.1 cm / 15” Native (Maximum) Resolution 1,024 x 768 pixels Colours 16.7 million Contrast Ratio 400:1 (typical) Brightness 250 cd/m²... -
Page 23: Input Signal
Input Signal Line Frequency 31 - 63kHz multi-frequency Image Frequency (Refresh Rate) 56 - 75Hz Within the parameters detailed in chapter 7 Video Signal RGB analogue (Positive polarity) 0.7 Vpp/75 Ohm Synchronization TTL separate, composite TTL Signal Connection 15-pin mini D-sub cable Physical Characteristics Power Management VESA DPMS, Energy Star... -
Page 24: Service Contacts
Service Contacts If problems remain after checking this manual, please contact your place of purchase or contact: Australian Service Contacts Visit the Customer Support section of Mitsubishi Electric Australia’s web site at www.mitsubishi-electric.com.au for details of your nearest Mitsubishi Electric Authorized Service Center or contact the Service Department for your state: New South Wales and Australian Capital Territory 348 Victoria Road... - Page 25 Western Australia 5 / 329 Collier Road Bassendean, WA, 6054 Telephone: (08) 9377-3411 Fax: (08) 9377-3499 New Zealand Contact: BDT New Zealand Ltd. 1 Parliament St. Lower Hutt Wellington Telephone: (04) 560-9100 Fax: (04) 560-9140 Web site: www.bdt.co.nz...
