Chapter 2 – Installation
4. Connect a suitable antenna to the SMA connector (see specifications on page 5).
Antenna Connector
(SMA type)
5. Connect both sides of the serial and control cable (15-pin Sub D connector on the modem side).
Serial & Control
Connector
To Serial Port
of PC
Multi-Tech Systems, Inc. MultiModem® GPRS User Guide
