Chapter 1: Product Description and
Specifications

Product Description

The Multi-Tech MultiModem® GPRS is an external data/fax/voice wireless modem. It also supports mobile originated
short message service (SMS) and mobile-terminated SMS. It offers standards-based multi-band GSM/GPRS Class
10 performance. This ready-to-deploy, standalone modem allows developers to add wireless communication to
products with a minimum of development time and expense. The MultiModem GRPS
industry-standard open interfaces, is fully type approved, and can be desktop or panel mounted.

Package Contents

Basic Package
one modem
two holding bridles (mounting brackets)
one fused power cable
Bundled Package
All Basic package items except the fused power cable, plus
one RS232 15-to-9 pin cable
one antenna
four adhesive-backed rubber feet for table-top mounting
one universal power supply with power cord
one MultiModem CD
one Quick Start Guide

Interfaces

The Wireless MultiModem has several interfaces:
LED function indicating operating status
External antenna (via SMA connector)
Serial and control link (via 15 pins SUB D)
Power supply (via 2.5mm miniature power jack)
SIM card holder

Parts to be Supplied by Wireless Service Provider

Subscriber Identity Module (SIM) configuration chip
The SIM contains information specific to your wireless account and its features.

Parts to be Supplied by End User

mounting screws (screw shaft diameter = .17" max.)
antenna (Basic Package)
Multi-Tech Systems, Inc. MultiModem® GPRS User Guide
Chapter 1 – Description & Specification
Wireless Modem
is based on
4
