Page 1: Users Manual
DVD Premium Pro LightScribe Series Stand-Alone, NET, and Rackmount Users Manual www.microboards.com Version 1.07... - Page 2 DVD Premium Pro LightScribe Series MICROBOARDS TECHNOLOGY, LLC...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Microboards Statement Regarding Improper Duplication ... 4 System Overview... 5 Unpacking your system ... 5 Installation Requirements ... 6 Connecting Master and Slave Towers... 7 Microboards NET Configuration ... 8 Configuration Options ... 8 Basic Configuration... 8 Advanced Configuration ... -
Page 4: Microboards Statement Regarding Improper Duplication
As a user of our equipment, we expect you to support that right as well. Microboards Technology is neither responsible nor liable for the infringement of any laws regarding the illegal duplication of property. Microboards Technology products are in no way... -
Page 5: Unpacking Your System
System Overview DVD Premium Pro LightScribe Stand-Alone and Rackmount Series The DVD Premium Pro LightScribe Series includes the Tower and the Rackmount styles. The Tower employs up to 10 General Purpose DVD-+R/DL LightScribe recorders, while the Rackmount employs up to 4 recorders. The hard drive comes standard with the Pro system and allows for DVD/CD image archival and CD track extraction for CD audio compilations. -
Page 6: Installation Requirements
Installation Requirements System Setup • Connect the power cable to the DVD Premium Pro Series tower and plug in to a protected power outlet strip or UPS power supply. • NET Series Only: Connect the 2 towers using the NET cable provided (see page 7 for more information). -
Page 7: Connecting Master And Slave Towers
Connecting Master and Slave Towers The Microboards DVD Premium Pro NET tower line requires a physical connection between the towers. A tower will be designated as a Master or as a Slave tower initially based solely on the configuration of the connection. The directions below give 2 connection scenarios: a 2-tower configuration, and a Multi-Tower configuration. -
Page 8: Microboards Net Configuration
Microboards NET Configuration The Microboards NET configuration allows you to connect multiple 10-drive tower duplicators. They can function together as a single duplicator with 10 drives per tower for ultra high-quantity production, or can operate independently as stand-alone duplicators, each copying from a different master. -
Page 9: Advanced Configuration
Advanced Configuration If, however, you wish to operate them as two 3-tower Master/Slave groups, simply press the YES button on the tower on which the Configuration Options display reads NET SLAVE 3. This will cause all towers following this tower to be slaved to that tower. The YES button on the first tower must also be pressed to slave towers 2 and 3 to the first tower. -
Page 10: Main Menu
Main Menu The Arrow buttons (▼▲)allow you to move forward or backward in the menu without selecting the current menu item. The NO button will move you to the next menu item. YES will select the current menu item. INSERT COPY START? (DISCtoDISC) MASTER DISC... -
Page 11: Registering Data To The Hard Drive (Hdd)
Copy Disc to Disc 1. Place the Master Disc into the Reader drive. Place the blank disc(s) into the Recorder drive(s) and wait 10 seconds for the light(s) on the front of the Recorder(s) to stop blinking. Note that the blanks must be of the same media type as the master;... -
Page 12: Registering Print Images To The Hard Drive (Hdd)
7. You will see this screen after the contents of the master have been analyzed: Press the NO button to register your master as a disc image. 8. Next, name the disc image: If you do not have the Auto Generate in the Setup menu feature turned on, use the ▲or ▼buttons to change the character in the position shown by the cursor. -
Page 13: Printing Hard Drive (Hdd) To Disc
7. You will see this screen after the contents of the master have been analyzed: Press the YES button to add a LightScribe print image. 8. You can have up to 20 print images on your disc. Use the ▲or ▼buttons to select the image you want and press YES. -
Page 14: Simulation Disc To Disc
9. Press YES and the Reader drive will eject and you can insert another master to register to the HDD. 10. Press NO and to exit this menu without registering data to the hard drive partition. Simulation Disc to Disc Important: Simulation is not allowed when using DVD+R/RW media. -
Page 15: Error Status In Track Extraction
Track Extraction When extracting tracks to the internal hard drive, the DVD Premium Pro Series will use the next available partition space on the hard drive. Like any time a master is registered to the hard drive, you have the ability to name the partition. 1. -
Page 16: Setup Menu
Setup Menu SETUP MODE SELECT? COPY? (COPY MODE) (DISC to DISC) DVD WR MAX? SPEED? (MAX) CD WR SPEED? MAX? (MAX) ISRC CHECK? ISRC ON? (OFF) Auto Run? (OFF) COPY QUANTITY? COPY QUANTITY? (xxxx/xxxx) SESSION MODE? AUTO? (AUTO) READER SELECT? DRIVE01 (DRIVExx) READER... -
Page 17: Copy And Print Logs
Shows DVD Premium Pro LightScribe Series firmware version and H/W information. F/W Update Used when updating the firmware of the DVD Premium Pro LightScribe Series duplicator. Copy and Print Logs Displays the number of successful and unsuccessful burned and printed discs over the entire life of the duplicator. -
Page 18: Lightscribe Template Labeler
LightScribe Template Labeler The LightScribe Template Labeler and LightScribe System Software included with the DSR Premium Pro LightScribe Series duplicator are required for creating the necessary print image files for the LightScribe Print feature to work. Do not update or attempt to use any version of the LightScribe Template Labeler or the LightScribe System other than those provided by Microboards Technology. -
Page 19: Error Codes
Error Codes Read Errors ASCQ Description NO ADDITIONAL SENSE INFORMATION I/O PROCESS TERMINATED, PLAY OPERATION ABORTED AUDIO PLAY OPERATION IN PROGRESS AUDIO PLAY OPERATION PAUSE AUDIO PLAY OPERATION SUCCESSFULLY COMPLETED AUDIO PLAY OPERATION STOPPED DUE TO ERROR NO CURRENT AUDIO STATUS TO RETURN CLEANINF REQUESTED NO INDEX/SECTOR SIGNAL NO SEEK COMPLETE... - Page 20 RECOVERED ID WITH ECC CORRECTION INVALID COMMAND OPERATION CODE LOGICAL BLOCK ADDRESS OUT OF RANGE INVALID FIELD IN CDB LOGICAL UNIT NOT SUPPORTED INVALID FIELD IN PARAMETER LIST PARAMETER NOT SUPPORTED PARAMETER VALUE INVALID THRESHOLD PARAMETERS NOT SUPPORTED INVALID RELEASE OF ACTIVE PERSISTENT RESERVATION NOT READY TO READY CHANGE, MEDIUM MAY HAVE CHANGED POWER ON, RESET, OR BUS DEVICE RESET OCCURRED POWER ON OCCURRED...
-
Page 21: Write Errors
LOGICAL UNIT FAILED SELF-CONFIGURATION TAGGED OVERLAPPED COMMANDS (NN=QUEUE TAG) OVAERLAPPED COMMANDS ATTEMPTED MEDIA LOAD OR EJECTED FAILED MEDIUM REMOVAL PREVENTED SYSTEM RESOURCE FAILURE UNABLE TO RECOVER TABLE-OF-CONTENTS OPERATOR REQUEST OR STATE CHANGE INPUT OPERATOR MEDIUM REMOVAL REQUEST LOG EXCEPTION THRESHOLD CONDITION MET LOG COUNTER AT MAXIMUM LOG LIST CODES EXHAUSTED FAILURE PREDICTION THRESHOLD EXCEEDED - Predicted Logical Unit Failure... - Page 22 WRITE ERROR-RECOVERED WITH AUTO REALLOCATION WRITE ERROR-RECOMMEND REASSIGNMENT WRITE ERROR-RECOVERY NEEDED WRITE ERROR-RECOVERY FAILED WRITE ERROR-LOSS OF STREAMING WRITE ERROR-PADDING BLOCKS ADDED UNRECOVERED READ ERROR CIRC UNRECOVERED ERROR RANDOM POSITIONING ERROR MECHANICAL POSITIONING ERROR POSITIONING ERROR DETECTED BY READ OF MEDIUM DATA SYNCHRONIZATION MARK ERROR DATA SYNC ERROR-DATA REWRITTEN DATA SYNC ERROR-RECOMMEND REWRITE...
- Page 23 POWER ON, RESET, OR BUS DEVICE RESET OCCURRED POWER ON OCCURRED SCSI BUS RESET OCCURRED BUS DEVICE RESET FUNCTION OCCURRED DEVICE INTERNAL RESET PARAMETERS CHANGED MODE PARAMETERS CHANGED LOG PARAMETERS CHANGED RESERVATIONS PREEMPTED COPY CANNOT EXECUSE SINCE HOST CANNOT DISCONNECT COMMAND SEQUENCE ERROR NOT READY TO READY CHANGE, MEDIUM MAY HAVE CHANGED POWER ON, RESET, OR BUS DEVICE RESET OCCURRED...
- Page 24 OVAERLAPPED COMMANDS ATTEMPTED ERASE FAILURE ERASE FAILURE - Incomplete erase operation detected MEDIA LOAD OR EJECT FAILED MEDIUM REMOVAL PREVENTED SYSTEM RESOURCE FAILURE UNABLE TO RECOVER TABLE-OF-CONTENTS OPERATOR REQUEST OR STATE CHANGE INPUT OPERATOR MEDIUM REMOVAL REQUEST OPERATOR SELECTED WRITE PROTECT OPERATOR SELECTED WRITE PERMIT LOG EXCEPTION THRESHOLD CONDITION MET...
-
Page 25: Supported Formats
Only those firmware versions recommended and provided by Microboards Technical Support for this specific product should be installed. Installation of an incorrect firmware on any Microboards Technology product may result in any remaining warranty being voided. Technical Support For technical questions or support issues, contact Microboards Technology technical support:... - Page 26 Tower Models (Stand-Alone and NET Series) Any unauthorized modification to this equipment may result in the revocation by the FCC of the user’s authority to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
