MORE INFORMATION ABOUT YOUR VCR

SPECIFICATIONS

Format:
Number of heads:
Video signal system::
Hi-Fi audio recording
system:
Maximum playing time:
Tape width:
Tape speed:
Antenna:
Reception channels:
RF output signal:
Power requirement:
Power consumption:
Operating temperature:
Storage temperature:
Video input:
Video output:
Audio input:
Audio output:
Hi-Fi audio:
Dimensions:
Weight:
Supplied accessories:
• Specifications are subject to change without notice as part of our policy of continuous
improvement.
• No liability is accepted for any inaccuracies or omissions in this publication, although
every possible care has been taken to make it complete and as accurate as possible.
VHS PAL standard/VHS SECAM-L
6
PAL/MESECAM colour or monochrome signal:
625 lines
Deep layer recording system conforming to
stereo Hi-Fi VHS standard.
480 min. with E-240 video cassette in Long Play
(LP) mode
12.7 mm
23.39 mm/s Standard Play (SP): 11.70 mm/s
Long Play (LP)
75 Ω unbalanced
B/G: Channel VHF 2-12 + S1-S41
Channel UHF 21-69
L: Channel VHF 2-12 + B-Q
Channel UHF 21-69
UHF channel 21-69
AC 230V, 50 Hz
19 W approx (STANDBY ≤ 4 W)
5 ˚C to 40 ˚C
-20 ˚C to 55 ˚C
1.0 Vp-p, 75 Ω
1.0 Vp-p, 75 Ω
Line1&2: -3.8 dBs, 10 kΩ, Line 3: -3,8 dBs, 47 kΩ
Line1&2: -3.8 dBs, 1 kΩ Audio Out: -3,8 dBs, 1 kΩ
Dynamic range:~ 90 dBs typ. (SP); Frequency
response: 20 Hz - 20 kHz; Wow and
flutter: < 0.005% Wrm (JIS A)
430(W) x 300(D) x 91.5(H) mm
4.3 kg (approx)
75 Ω RF Connection cable, operation manual,
remote control, AA/R6/UM3 battery (x2)
38
