VC-FH30GM(S)
VC-FH50GM(S)
VC-FH30SM(S)
VC-FH30SM(SN)
Im Interesse der Benutzer-Sicherheit (gemäß
den Scherheitsvorschriften in eingen Lädern)
solite dieses Gerät wieder auf seinen
ursprünglichen Zustand eingestellt und die
vorgeschriebenen Teile verwendet wereden.
Diese Wartungsanleitung behandelt nur diejenigen
Aspekte, die sich vom VC-FH3/5GM(S). Weiterge
hende Informationen, die in diesem indies Nachtrag
nicht behandelt werden, finden Siein der Wartungsan
leitungfür das Gerät VC-FH3/5GM(S).
CONTENTS
SPECIFICATIONS.................................3
ROM MAP............................................. 4
CIRCUIT DIAGRAMS............................5
REPLACEMENT PARTS LIST..............27
PACKING OF THE SET........................ 30
ERGÄNZUNG SERVICE-ANLEITUNG
SUPPLEMENT SERVICE MANUAL
MODELS
MODELLE
VC-FH30GM(S)
VC-FH50GM(S)
VC-FH30SM(S)
VC-FH30SM(SN)
Page
SHARP CORPORATION
1
VIDEO CASSETTE RECORDER
In the interests of user-safety (Required by safety regula-
tions in some countries) the set should be restored to its
original condition and only parts identical to those speci-
fied be used.
This service manual covers only those items that differ
from the VC-FH3/5GM(S). For further information on
items not covered by this supplement refer to the Service
Manual for VC-FH3/5GM(S).
INHALT
TECHNISCHE DATEN............................3
ROM-TABELLE......................................4
LEITUNGSSCHEMA.............................. 5
ERSATZEILLUNGEN.............................27
VERPACKUNG DES GERËÄTES......... 30
S7050VCFH30GM
SY7J5VCA582U/
