Introduction

This manual is provided by Walter Meier (Manufacturing) Inc., covering the safe operation and
maintenance procedures for the JET Model JMS-12SCMS Dual Bevel Sliding Compound Miter Saw with
laser. This manual contains instructions on installation, safety precautions, general operating procedures,
maintenance instructions and parts breakdown. This machine has been designed and constructed to
provide years of trouble free operation if used in accordance with instructions set forth in this manual. If
there are any questions or comments, please contact either your local supplier or Walter Meier. Walter
Meier can also be reached at our web site: www.waltermeier.com.

Specifications

Model Number ................................................................................................................ JMS-12SCMS
Stock Number .......................................................................................................................... 707120
Motor ......................................................................................................................... 120V, 60Hz, 15A
No Load Speed (Arbor) .......................................................................................................... 4200RPM
Motor Arbor Shaft Size .................................................................................................................... 5/8"
Blade ............................................................................................................... 12", 60T, carbide tipped
Blade Arbor Size...................................................................................................... 1" with 5/8" reducer
Miter Stops ................................................................................................................. ten at -45° to 60°
Bevel Stops ...................................................................................................0°, 33.9°, 45° left and right
Base Dimensions......................................................................................................... 37-1/2" x 26-1/4"
Net Weight .................................................................................................................................. 72 lb.
The above specifications were current at the time this manual was published, but because of our policy of
continuous improvement, Walter Meier (Manufacturing) Inc., reserves the right to change specifications at
any time and without prior notice, without incurring obligations.

Cutting Capacity

Cut Type
Cross Cut
Miter
Miter
Bevel
Bevel
Compound Cut
Compound Cut
Compound Cut
Vertical Capacity (Baseboard)
Read and understand the entire contents of this manual before attempting
assembly or operation! Failure to comply may cause serious injury!
Miter Angle
0º
45º Right & Left
60º Right
0º
0º
45º Right & Left
45º Right & Left
60º Right
0º
8
Bevel Angle
0º
0º
0º
45º Left
45º Right
45º Left
45º Right
45º Right
0º
Cutting Capacity
4" x 12-1/4"
4" x 8-3/4"
4" x 6-1/4"
2-1/2" x 12-1/4"
1-3/4" x 12-1/4"
2-1/2" x 8-3/4"
1-3/4" x 8-3/4"
1-3/4" x 6-1/4"
5-1/2"
