AUSTRALIAN MONITOR AMIS26 Specifications

AMIS26
Distribution Amplifier
Description
The Australian Monitor Installation Series AMIS26 is a high quality 2 input, 6 output
distribution amplifier. The AMIS26 provides a low noise, feature packed, signal
routing solution to cover a wide range of installation needs, at a contractor
friendly price.
Inputs
The AMIS26's 2 inputs can be balanced or unbalanced and each input's sensitivity
can be switched between Mic and Line level. Each of the AMIS26's inputs is
individually assignable to any of the 6 outputs via front panel DIP switches
Outputs
The 6 outputs can again be balanced or unbalanced and feature up to -60dB of
attenuation so they can be run as any combination of line level or mic level outputs.
Controls
Input Level: The input level controls are screw diver adjustable trim pots. The input
level can boost or cut the input signal by up to 15dB.
Input Assign Switches: The recessed DIP switches assign either input A or B to a
desired output.
Output Level: The output level controls are screw driver adjustable trim pots. This
level control attenuates the output level, with a range from -60dB at "Minimum"
position, to 0dBat "Maximum" position.
Output Level DIP switch: This switch will change the output sensitivity of the
desired output from Mic to line level.
24 VDC Phantom Power is also individually switchable per input
Metering
Input Level Meter: These 4 segment LED meters show the strength of each of the
AMIS26's input signals. LED segments are calibrated to the following level markings
and show the following colours -20dBu (green), -10dBu (green), 0dBu (yellow),
+10dBu (red).
Phantom Power
-24 VDC Phantom power is also individually switchable per input.
