Your ReSound Azure AZ70-DVI and AZ80-DVI Hearing
Instrument
1. Programme Selector
2. Battery Compartment & On/Off Switch
3. Sound Outlet
4. 1 Microphone Sound Inlet
st
5. 2 nd Microphone Sound Inlet
6. Volume Control
7. Direct Audio Input
6
1
2
4
4
5
3
7
8. Left/Right indicator
(Right=Red, Left=Blue)
9. Battery lock
10. Model
11. Manufacturer
10
11
9
8
5
