Pulsar NX15 Manual

Duo-display quartz
Hide thumbs
Table of Contents

Advertisement

Quick Links

CAL. NX15
DUO-DISPLAY QUARTZ
l Analogue time display
l Digital time and calendar
l Chronograph
l Tachymeter
l Data recall function
l Alarm
l Illuminating light
(Electroluminescent panel)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NX15 and is the answer not in the manual?

Questions and answers

Related Manuals for Pulsar NX15

Summary of Contents for Pulsar NX15

  • Page 1 CAL. NX15 DUO-DISPLAY QUARTZ l Analogue time display l Digital time and calendar l Chronograph l Tachymeter l Data recall function l Alarm l Illuminating light (Electroluminescent panel)

  • Page 2: Mode Change

    MODE CHANGE CROWN/BUTTONS AND DISPLAYS With each press, the mode in the digital display changes in the following order. Illuminating light Minute hand (TIME/CALENDAR mode only) Hour hand CROWN Second hand TIME/CALENDAR STOPWATCH mode DATA RECALL a: normal position mode mode b: extended position (analogue time setting)

  • Page 3: Illuminating Light

    ILLUMINATING LIGHT CHOICE Of DISPLAY ITEM IN TIME/CALENDAR MODE Press to select the items shown on the display in TIME/CALENDAR Press to turn the illuminating light on only in the TIME/CALENDAR mode. mode. day of the week date The built-in electroluminescent backlight illuminates the display for approximately 3 seconds for easy viewing in darkness.

  • Page 4: Screw Down Crown

    SCREW DOWN CROWN TIME/CALENDAR MODE [for models with screw down crown] ANALOGUE TIME SETTING Unlocking the crown Second hand 1 Turn Crown counterclockwise until you no CROWN longer feel the threads turning. Pull out when the second hand Hour hand Minute hand is at the 12 o’clock position.

  • Page 5: Digital Time/Calendar Setting

    DIGITAL TIME/CALENDAR SETTING NOTES u With each press of the button C (or D), the flashing digits increase (or decrease). Press to enter TIME/CALENDAR u The flashing digits except for second and 12-/24-hour indication move quickly if mode. the button C or D is kept pressed. Press and hold for 2 to 3 seconds u If the watch is left untouched in the TIME/CALENDAR SETTING display with the t o s h o w T I M E / C A L E N D A R digits/item flashing, it will automatically return to the TIME/CALENDAR mode in 1 to 2 minutes.

  • Page 6: Stopwatch Mode

    HOW TO SET THE HOURLY TIME SIGNAL STOPWATCH MODE l The hourly time signal can be set in the TIME/CALENDAR mode. l The stopwatch can measure up to 9 hours 59 minutes 59 seconds With each press of button C, the hourly time signal will be alternately and 99 in 1/100 second increments.
  • Page 7 HOW TO SET THE DISTANCE TO TRAvEL AND UNIT Of DISTANCE Press and hold for 2 to 3 seconds Digits before decimal point to show DISTANCE/UNIT SETTING l Any numeric value between 0.01 and 99.99 can be set as a distance to travel independent of unit of distance.

  • Page 8: Stopwatch Operation

    STOPWATCH OPERATION NOTES u With each press of the button C (or D), the flashing digits increase (or decrease). P r e s s t o e n t e r S T O P WAT C H u The digits before decimal point and digits after decimal point move quickly if the mode. button C or D is kept pressed. u If the watch is left untouched in the DISTANCE/UNIT SETTING display with the digits/item flashing, it will automatically return to the STOPWATCH mode in 1 to and/or 2 minutes. Press to reset the stopwatch to 00’ u The settable range of the distance is between 0.01 and 99.99. 00”00 before use. u The unit of distance is selectable in the order of "mile","km" and "n. mile."...
  • Page 9 <Standard measurement > <Display after a lap time is taken> l Approximately one second after a lap time is taken, the display changes for 5 seconds to show the calculated average speed of the lap and the lap time, and then it automatically returns to the ongoing Start Stop reSet...
  • Page 10 TO vIEW SPLIT TIME (total elapsed time from the start) DURING MEASUREMENT HOW TO USE THE DATA RECALL fUNCTION l In addition to each lap data, split time (total elapsed time from the l Up to 100 measurement data can be recalled. start) can be checked during measurement.
  • Page 11 Press to select the lap number Press to view each component of the selected lap data. of the measurement data you want to see. Average speed for Average speed for Lap number 1 the lap time 1 the split time 1 Repeat the previous step to view each component of the selected lap data.

  • Page 12: Alarm Mode

    ALARM MODE Press to set the flashing digits. l The alarm can be set to sound once every 24 hours. l You can preview the alarm sound by using the sound demonstration function. Press to confirm the alarm setting and return to ALARM mode. Press to enter ALARM mode.
  • Page 13 Engagement/disengagement of the alarm Sound Demonstration Function (Alarm sound preview) With each press of the button C in the ALARM mode, the alarm will l The alarm sound can be previewed in TIME/CALENDAR mode. be alternately engaged or disengaged. Accordingly, the alarm mark will appear or disappear indicating whether the alarm is ON or OFF.

  • Page 14: Battery Change

    When the batteries expire, be sure to replace them as soon as CAUTION possible to prevent any malfunction. l We recommend that you contact an AUTHORIZED PULSAR DEALER l The battery is not rechargeable. Never attempt to recharge it, as for battery replacement.
