Tips For Environmental Protection; Technical Specifications; Description Of The Appliance - Zanussi TC 7122 User Manual

Tips for environmental protection

To save energy and to help protect the environment,
we recommend that you follow these hints:
• Try to load the maximum capacity of the machine
as small loads are uneconomical.
• Always load well spun laundry. The higher the spin
speed, the lower the electricity consumption and
the shorter the drying times.
• Do not over-dry laundry, this avoids creasing and
saves energy.
Select the drying time/section according to the
type of laundry and the required degree of

Technical specifications

DIMENSIONS:
ELECTRICAL CONNECTION:
MAX. POWER ABSORBED:
MIN. FUSE RATING:
MAX. DRYING CAPACITY:
CONSUMPTION:
This appliance complies with the following E.E.C. Directives:
- 73/23 EEC of 19.2.73 (Low Voltage Directive) and subsequent modifications;
- 89/336 EEC of 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.

Description of the appliance

01 Worktop
02 Programme guide
03 Control panel
04 Fluff filters
05 Rating Plate
06 Condenser Unit
07 Water reservoir
08 Adjustable feet
dryness.
• To utilize the maximum load, laundry which is to
be dried ready to put away (store dry) can be dried
together with items to be ironed. To do this, select
the time for iron-dry, remove the iron-dry items at
the end of the programme and then finish-dry the
rest of the load.
• Clean the filters regularly to avoid excessive drying
times and high electricity consumption.
• Ventilate the room well. The room temperature
should not exceed +35°C during drying.
Height
Width
Depth
Cotton, linen
Synthetics
Cotton, linen
Cotton, linen
Synthetics
4
85 cm
60 cm
58 cm
220/230 V/50 Hz
2200 W
10 A
5 kg
2.5 kg
3.64 kWh (5.5 kg store dry)
3.64 kWh (5.5 kg iron dry)
1.40 kWh (2.5 kg store dry)
