Fitting the lid

Fit the lid (dust cover 10) carefully over the hinge prongs and adjust the screws (12) until the lid stays open
where you want it to without being too stiff to open or close.

Fitting and connecting the cartridge

** All cartridges with half inch mounting holes can be fitted. Leaving the needle's protection cover on, fit the
cartridge to the headshell using the screws supplied with the cartridge by passing one screw through each
slot in the headshell (21). Do not tighten the nuts yet. Connect the tonearm wires to the cartridge pins as follows:
white left channel positive (L+)
red right channel pos. (R+)
green right channel return (R -)
blue left channel return (L -)
The full sound quality of the record player can only be achieved if the cartridge is correctly adjusted. Particular
tools like the PRO-JECT alignment tool are required to accomplish this job properly. If you are not well acquainted
with the adjustment of cartridges you are advised to call upon the willing help of your PRO-JECT dealer to
accomplish this task for you.
Please note: adjusting a cartridge and tonearm calls for the greatest care in order to avoid damaging
the cartridge or tonearm bearings. Leave this work to your dealer if you are in any way unsure of the
necessary steps and precautions to be taken.

Maintenance and cleaning

Your record player requires little or no regular maintenance. Remove dust with a slightly moistened antistatic
cloth. Never use a dry cloth because this will create static electricity which attract more dust! Antistatic
cleaning fluids are available at specialist stores but must be applied sparingly to avoid damage to rubber
parts. It is recommended to fit the needle cover before cleaning or maintenance is carried out to avoid damage.
If the player is not used over a long period of time the drive belt can be removed to prevent unequal stretching.
Always disconnect the record player from the mains power supply as a precaution before maintenance!

Useful tips

The lid is not only a dust cover but also a resonant structure likely to be excited by, and to pass into the
plinth, the acoustic energy emanating from your loudspeakers during replay. It is therefore recommended
that the lid be removed for optimum sound quality.
The record player should be positioned on a low-resonance surface such as wood or multiple layer ply board
to avoid structural vibrations disturbing replay.

Technical specifications PRO-JECT 6

Nominal speeds *
Speed variance
Wow and flutter
Signal to noise
Downforce range
Effective tonearm length
Overhang
Power consumption
Outboard power supply
Dimensions (W x H x D)
Weight
6
© Audio Trade GmbH · Pro-Ject 6
PerspeX
33,33/45,11 r.p.m.
±0,5 %
±0,06 %
-73 dB
15-30mN
9 " (230mm)
18mm
2W
16V/500mA AC, suitable for your country's mains supply
460 x 160 x 365mm, dust cover open 460 x 420 x 465mm
10,5kg
PerspeX SuperPack / Ortofon Valencia · Revision 1.11.08/1.1.09
