- Page 1 HOT AIR GUN PART No.HG1601 STOCK No.53266 • INSTRUCTIONS • IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND EFFECTIVE USE OF THIS TOOL. 07/97...
-
Page 2: Specification
SPECIFICATION Whilst every effort has been made to ensure that the information given in this manual is correct at the time of going to print, the Draper Tools policy of continuous improvement determines the right to change specification without notice. -
Page 3: Power Supply
(i.e. red). Fuse covers are available from your Draper Tools stockist. If the fitted plug is not suitable, it should be cut off and destroyed. *The end of the cable should now be suitably prepared and the correct type of plug fitted. -
Page 4: Safety Warning
IMPORTANT Draper Tools Limited recommends that this machine should not be modified or used for any application other than that for which it was designed. If you are unsure of its relative applications do not hesitate to contact us in writing and we will advise you. -
Page 5: Added Safety Rules For Hot Air Guns
ADDED SAFETY RULES FOR HOT AIR GUNS NOTE: A FIRE COULD ARISE IF THIS HOT AIR GUN IS NOT USED WITH CARE. 1. Ensure that the hot air gun is switched OFF before connecting to the power supply. 2. Do not use this hot air gun as a hair dryer. 3. -
Page 6: On/Off Switch
OPERATION IMPORTANT - ensure that the machine is switched OFF before connecting to the power supply. ON/OFF SWITCH The ON/OFF switch has three positions/settings, see Figs.1, 2 and 3. Fig.1 shows the switch in the OFF position, 2 shows the switch in low heat position and Fig.3 shows the switch in the higher heat position. - Page 7 APPLICATIONS The following instructions should only be used Fig.5 as a guide as the ideal temperature should be ascertained by performing a test on the workpiece. Heating efficiency will vary depending on the properties of the workpiece, and the distance kept between the metal nozzle and the workpiece.
-
Page 8: Defrosting Water Pipes
APPLICATIONS Cont’d DEFROSTING WATER PIPES Fig.8 IMPORTANT: Do not defrost plastic tubing/piping. Fit the relector hook nozzle ✫✌ Fig.8 (not supplied see optional accessories, page 8). Switch the hot air gun on to the higher heat setting, gently heat the frozen area of the pipe starting from the edge of the area and moving in towards the centre. -
Page 9: Maintenance
Please note all repairs/adjustments should be carried out by a qualified person. POWER DIVISION HELPLINE: 01703 494313 OPTIONAL ACCESSORIES The following accessories are available from your local Draper Stockist. GLASS PROTECTION NOZZLE WALL SCRAPERS Part No. AHG1 Part No. 49325 (2") Stock No.34410... -
Page 10: Declaration Of Conformity
DECLARATION OF CONFORMITY We Draper Tools Ltd. Hursley Road, Chandler’s Ford, Eastleigh, Hampshire. SO53 1YF. England. Declare under our sole responsibility that the product: Part No. HG1601. Stock No. 53266. Description:- Hot Air Gun To which this declaration relates is in conformity with the following directive(s) 73/23/EEC &... - Page 11 NOTES - 10 -...
- Page 12 ©Published by Draper Tools Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
