Spectralink 8400 Series
product specifications
The Spectralink
®
8400 VoWLAN handsets deliver on a fundamental need for enterprise-grade on-site voice mobility. Characterized
by market-leading HD voice quality, durability, and broad telephony and WLAN interoperability, Spectralink 8400 handsets deliver a
reliable user experience and predictable return on investment.
The Spectralink 8400 series enhances the customer value proposition through an optional integrated barcode scanner and an
enhanced standards-based applications interface. In partnership with the Spectralink applications development ecosystem, the
Spectralink 8400 products enable new opportunities for end-user productivity solutions.
©2013 Spectralink
physical characteristics
Durability and Performance
Display
• 2.2-inch 240 x 320 resolution
• 65,000 color palette
Buttons
• Four (4) context-sensitive softkey buttons
• Push-to-Talk
• Five-way navigation and select control
• Home & Back navigation keys
• Up/Down volume control
• Barcode reader (8452/8453 handsets)
• Start and End Keys
• Panic/Duress
status lED
• Message (voicemail) waiting
• Out of coverage
• Phone ringing
pEriphEral intErfacEs
• Micro USB interface for wall charging and configuration
• 2.5mm connector for wired headset
• Bluetooth
BattEriEs
• Two easy-access cosmetic battery capacity options
• Standard – Up to 8 hrs talk time, 80hrs standby time
• Enhanced – Up to 12 hrs talk time, 120hrs standby time
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SpectraLink 8400 Series
Summary of Contents for SpectraLink 8400 Series
-
Page 1: Product Specifications
Spectralink 8400 Series product specifications The Spectralink ® 8400 VoWLAN handsets deliver on a fundamental need for enterprise-grade on-site voice mobility. Characterized by market-leading HD voice quality, durability, and broad telephony and WLAN interoperability, Spectralink 8400 handsets deliver a reliable user experience and predictable return on investment. The Spectralink 8400 series enhances the customer value proposition through an optional integrated barcode scanner and an enhanced standards-based applications interface. In partnership with the Spectralink applications development ecosystem, the Spectralink 8400 products enable new opportunities for end-user productivity solutions. physical characteristics Durability and Performance Display • 2.2-inch 240 x 320 resolution • 65,000 color palette Buttons • Four (4) context-sensitive softkey buttons • Push-to-Talk • Five-way navigation and select control • Home & Back navigation keys • Up/Down volume control • Barcode reader (8452/8453 handsets) • Start and End Keys • Panic/Duress status lED • Message (voicemail) waiting... -
Page 2: Physical Characteristics
2.4 - 2.4835 GHz 48, 54 Mbps 21.7, 43.3, 65, 72.2 DimEnsions & wEight 802.11n* 2.4 & 5 GHz Mbps spEctralink spEctralink 2.4GHz and 5GHz dynamic band roaming supported 8440/8441 8452/8453 *Single-stream, 20MHz channel with SGI 147mm x 53mm x 146mm x 54mm x Dimensions 25mm 34mm Bluetooth Headset Support Weight 5.1 oz 5.7 oz • Version 2.1, HSP Version 1.2 • Class 1 support with range of ~10 meters As measured with standard battery. FRONT VIEW - ALL MODELS spectralink 8440 ©2013 Spectralink... -
Page 3: Telephony Features
• G.711 (a-law, u-law), G.729, G.722, G.722.1 • Speed dial menu list • Contacts directory with support for 1000 local entries push-to-talk (ptt)/paging • Call logs - Minimum of 20 logged entries for each call type (Incoming, dialed, and missed) • On-board native ‘walkie-talkie’ capability • Emergency system-wide speed dial • One-to-one, one-to-many broadcast communication • Auto-answer & any key answer capability • 24 configurable channels • Selectable ring tones • Priority, default channel • Unicode UTF-8 Multilingual User Interface aDDitional tElEphony fEaturEs • RTCP (RFC 3550, RFC 1889) • Call server redundancy • Predictive dialing from contacts list • Recent call lists ©2013 Spectralink... -
Page 4: Instant Messaging
• Standards-based XHTML API • Server based central provisioning via FTP, FTPS, TFTP, • On-board WebKit-based browser (JavaScript, CSS, DOM) HTTP or HTTPS for rich applications integration • Centralized user administration • Corporate directory access LDAP • Provisioning and call server redundancy • Initial configuration via USB spEctralink opEn application intErfacE (oai) • Unicode UTF-8 Multilingual User Interface • Backward compatibility with Spectralink OAI applications pErformancE anD fault managEmEnt instant mEssaging • On-board site survey and diagnostics tools • Handset-to-handset, PC client-to-handset IM support via • Enhanced syslog reporting Microsoft OCS and/or Microsoft Lync ®... - Page 5 • IEEE 802.1p/Q tagging (VLAN)/DSCP tagging • Acoustic echo cancellation & background noise suppression quality of sErvicE (qos) • Wi-Fi Multimedia (WMM) Data captUre speciFicatiONs • WMM-Power Save • WMM-Admission Control (draft) • IEEE 802.1p/Q tagging (VLAN)/DSCP tagging High-performance scanning sEcurity fEaturE spEctralink 8452/8453 • WEP, WPA-Personal, WPA2-Personal, WPA2-Enterprise Type 1D/2D Area Imagers with 802.1X (EAP-FAST, PEAP-MSCHAPv2) with Light Source 617 nm Highly Visible LED (5) Opportunistic Key Caching (OKC) and Cisco Client Key Management (CCKM) Scan Angle 38.9° Horiz., 25.4° Vert. • Media encryption via Secure Real-Time Protocol (SRTP) Label print Down to 25% • SIP signaling encryption via Transport Layer Security (TLS)
-
Page 6: Speakerphone Dock
• Docking base provides full-duplex HD Voice speakerphone and charging • Ideal for small group conference settings • Suitable for replacement of a desktop phone • Includes on-board mute, volume and speakerphone controls • Wired headset options • Provides handset and spare battery charging Dual chargEr • Ideal for desktop use to augment or replace a desktop phone • Provides handset and spare battery charging quaD chargEr • Charges up to 4 spare battery packs simultaneously • Ideal for shift-work environments and highly-mobile users • Designed for tabletop or wall-mounting multi-chargEr • Charges up to 12 battery packs simultaneously • Wall or desk mount • Ideal for multi-shift environment ©2013 Spectralink...
