- Page 1 Zalman Tech Co., Ltd. User s Manual User s Manual http://www.zalman.co.kr E-mail:zalman@zalman.co.kr...
-
Page 2: Dimensions (Mm)
7) Zalman s CPU Coolers enable very stable operation of a CPU in an OVERCLOCKED environment. * If you try OVERCLOCKING, please make sure that the fan is in Normal Mode. * Zalman Tech. Co., Ltd. is not responsible for any damage to systems or CPUs caused by CPU OVERCLOCKING. - Page 3 1) For a noiseless computer, a Noise Prevention (NP) Power Supply, a NP HDD, a NP CD-ROM and a NP VGA Card should be used together with this cooler. 2) Zalman affixes a Computer Noise Prevention System (CNPS) Mark to each of its parts and components used for noiseless computers.
- Page 4 1) Spread the thermal grease thinly onto the CPU core’s surface that comes in contact with the FHS as shown in FIG. 2. 2) Install the clip across the FHS as shown in FIG. 2 3) Hook the short leg of the clip onto the socket first, then hook the long leg on by pushing the hole in the leg with the heatsink installation tool or an ordinary screw driver as shown in FIG.
- Page 5 1) As shown in FIG. 7, you can freely place the fan and the bracket in any desired location with the FB123. Therefore, place the fan in an ideal location as shown in FIG. 6. You can also place an additional fan on the FB123 to maximize the cooling of the VGA Card as shown in FIG.
- Page 6 CPU fan to less than or equal to 1500 RPM. The specifications of the cooler may change without prior notice to improve the performance thereof. For more information on this product, visit our homepage at www.zalman.co.kr.
