User's Manual
CNPS10X Quiet
Intel Socket 1155/1156/1366/775 CPU
AMD Socket AM3/AM2+/AM2/754/939/940 CPU
To ensure safe and easy installation,
please read the following precautions.
www.ZALMAN.com
Core i7
Core i5
Core i3
Core 2 Quad
Core 2 Duo
Core 2 Extreme
Dual Core Pentium
Pentium D
Pentium 4
Celeron D
Phenom Ⅱ
Phenom
Athlon 64 FX
Athlon 64 X2 Dual-Core
Athlon 64
Opteron
Opteron Dual-Core
Sempron
Ver. 1.3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ZALMAN CNPS10X Quiet
Summary of Contents for ZALMAN CNPS10X Quiet
- Page 1 User’s Manual CNPS10X Quiet Intel Socket 1155/1156/1366/775 CPU Core i7 Core i5 Core i3 Core 2 Quad Core 2 Duo Core 2 Extreme Dual Core Pentium Pentium D Pentium 4 Celeron D AMD Socket AM3/AM2+/AM2/754/939/940 CPU Phenom Ⅱ Phenom Athlon 64 FX...
-
Page 2: Specifications
Check the components list and condition of the product before installation. If any problem is found, contact the retailer to obtain a replacement. Zalman Tech Co., Ltd. is not responsible for any damages due to overclocking. During transportation of the system, the cooler must be removed. - Page 3 3. Components 1) Common Components Thermal Grease Fan Mate 2 Cooler (ZM-STG2) Fan Mate 2 User’s Manual Double-Sided Washers Cable Tape 2) Intel Socket 1155/1156/775 Components Socket 1155/1156/775 Clip Socket 1155/1156/775 Socket 775 Clip Support Backplate Bolts (Silver) Socket 1155/1156 Nuts 3) Intel Socket 1366 Components Socket 1366 Clip...
-
Page 4: Installation Requirements
4. Installation Requirements 1) Space Requirements The cooler’s installation requires unobstructed space with dimensions of 140mm(width),140mm(length), 165mm(height), and the CPU as a central reference point. Please check if components such as ODDs and PSU protrude into the required space. 2) Air Guide Removal Air guides on enclosures must be removed, before the cooler’s installation, for they protrude into the cooler’s required space. - Page 5 ① - B Socket 1155/1156 Clip Support Installation Bolt (Silver) Socket 1155/1156/775 Clip Support Washer Socket 1155/1156 Nut ① - C Socket 1366 Clip Support Installation Socket 1366 Clip Support Washer Bolt (Gold) ② Clear off any particles or residue from the CPU’s surface then spread (outwards from center) a thorough layer of Thermal...
- Page 6 ③ Remove the Fan from the Heatsink by unfastening the Fan Fixing Clip. Fixing Clip ④ Insert the Intel Socket 1155/1156/775 or Socket 1366 Clip through the cooler’s heatpipes at an odd angle then center its orientation. Making sure that the cooler and the clip are centered, fasten the clip by tightening the Intel Socket Clip Fixing Bolts.
- Page 7 ⑤ Use the Fixing Clip to fasten the Fan to the Heatsink. Fixing Clip ⑥ Power Connection ※ Refer to page 7 for Fan Mate 2 installation 2) AMD Socket AM3/AM2+/AM2/754/939/940 Installation ① Clear off any particles or residue from the CPU’s surface then spread (outwards from center) a thorough layer of Thermal...
- Page 8 6. Fan Mate 2 Installation and Usage 1) Fan Mate 2 Installation ② Fan Mate 2 can be installed to the ① Connect the motherboard and side of the case using Double-Sided Fan Cable to the Fan Mate Tape. 2 as shown in the diagram below.
- Page 9 .COM...
