Speed Function - CycleOps PowerTap SL Owner's Manual

SPEED FUNCTION

The middle level of the main display shows current, max, and average speed readings.
1) Press [MODE] to scroll the cursor to the middle line of the main display.
2) Press [SELECT] to toggle through the speed function options.
Current Speed
Speed is displayed in either miles per hour (MI) or kilometers per hour (KM) up to
99.9 mi/hr or km/hr in 0.1 mi/hr or km/hr increments. Current speed readings are
displayed when only "MI" or "KM" appears below the middle line. (FIGURE 13)
Maximum Speed
Either "MI" or "KM" and "MX" displayed simultaneously indicate the highest record-
ed speed since the last time data was cleared in trip mode or the selected interval
in interval mode. (FIGURE 14)
Average Power
Either "MI" or "KM" and "AVG" displayed simultaneously indicate the average
recorded speed since the last time data was cleared in trip mode or the selected
interval in interval mode. (FIGURE 15)
FIGURE 13
365
WATTS
3
25
MI
58.I0
D
FIGURE 14
365
WATTS
7
33
MI
MX
58.I0
D
FIGURE 15
365
WATTS
3
20
MI
AV
58.I0
D
16
