Computer Navigation

POWER FUNCTION

The top level of the main display shows current, max, and average power readings.
1) Press [MODE] to scroll the cursor to the top line of the main display
2) Press [SELECT] to toggle through the power function options.
For accurate power readings it is important to frequently zero the torque, see ZERO TORQUE.
Current Power
Power is displayed in watts from 0-1999 in 1 watt increments. Current power
readings are displayed only when the word "WATTS" appears below the top line
(FIGURE 9). NOTE: If "WATTS" does not appear under the top line the computer is
in the Cycle Computer Function. To return to power readings see CYCLE
COMPUTER MODE.
Maximum Power
Both "WATTS" and "MX" displayed simultaneously indicate the highest recorded
power output since the last time the data was cleared in trip mode or the selected
interval in interval mode. (FIGURE 10)
Average Power
Both "WATTS" and "AVG" displayed simultaneously indicate the average power
output since the last time the data was cleared in trip mode or the selected
interval in interval mode. (FIGURE 11)
FIGURE 9
365
WATTS
3
25
MI
58.I0
D
FIGURE 10
849
MX WATTS
3
25
MI
58.I0
D
FIGURE 11
I95
AV WATTS
3
25
MI
58.I0
D
14
