Summary of Contents for Zanussi ZI 929K
- Page 1 HÙTÃ-FAGYASZTÓ SZEKRÉNY CH¸ODZIARKO – ZAMRA˚ARKA CHLADNIâKA S MRAZÁKEM FRIDGE-FREEZER ZI 922/9 K HASZNÁLATI UTASÍTÁS INSTRUKCJA OBS¸UGI NÁVOD NA POUÎITÍ INSTRUCTION BOOKLET 2222 337-42...
-
Page 2: Warnings
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
• Do not place carbonated or fizzy drinks in the • If the appliance has been transported freezer as it creates pressure on the container, horizontally, it is possible that the oil contained in which may cause it to explode, resulting in the compressor flows in the refrigerant circuit. -
Page 4: Quick-Freezing - The Temperature Alarm Light - Freezing Fresh Food
Control panel A. Pilot light B. SUPER operating control light C. Warning light D. Normal/Super (quick-freezing) switch E. Thermostat knob Cleaning the interior Before using the appliance for the first time, wash • the quantity of food stored; the interior and all internal accessories with luke- •... -
Page 5: Use / Storage Of Frozen Food - Thawing - Ice Cube Production
Storage of frozen food When the freezer is being turned on for the first time, or after a prolonged period of disuse, turn the N/S knob to the Quick-freezing position and then wait at least two hours before introducing the food to be conserved. -
Page 6: Use / Use Of The Refrigerator - Temperature Regulation - Fresh Food Refrigeration
Use of the refrigerator Temperature regulation To start the appliance, turn the thermostat knob, located inside the compartment, to the required position. This thermostat has six operating positions and an «0» (Stop) position. The higher the number selected, the lower the temperature in the refrigerator. -
Page 7: Movable Shelves
Movable shelves The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired. For better use of space, the front half-shelves can lie over the rear ones. D338 Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be placed at different heights. -
Page 8: Hints / Hints For Refrigeration - Hints For Freezing - Hints For Storage Of Frozen Food
HINTS Hints for refrigeration types together with the recommended storage time (in months) from the time of freezing; Useful hints: • do not put carbonated liquids (fizzy drinks, Meat (all types): wrap in polythene bags and place etc.) in the freezer compartment as they may on the glass shelf above the vegetable drawer. -
Page 9: Maintenance / Periods Of No Operation - Periodic Cleaning - Interior Light - Defrosting
MAINTENANCE Unplug the appliance before carrying out Periods of non-operation any maintenance operation. When the appliance is not in use for long periods, Warning take the following precautions: This appliance contains hydrocarbons in its cooling remove the plug from the wall socket; unit;... -
Page 10: Customer Service And Spare Parts
However, when the ice becomes very thick on the inner liner, complete defrosting should be carried out as follows: 1. pull out the plug from the wall socket or turn the thermostat knob (E) to the «O» setting; 2. remove any stored food, wrap it in several layers of newspaper and put it in a cool place;... -
Page 11: Technical Information / Installation / Location
TECHNICAL INFORMATION Modell ZI 922 K Gross Freezer Capacity lt. Net Freezer Capacity lt. Gross Fridge Capacity lt. Net Fridge Capacity lt. Dimensions (width*height*depth, cm) 178x56x55 Tension (V/Hz) 220-240/50 Energy Consumption (kWh/24h) 1,15 Energy Class Freezing Capacity (kg/24h) Temperature increase time h Noise (dB/A) Climatic Class SN-ST... -
Page 12: Installation/ Electrical Connection
Electrical connection Before plugging in, ensure that the voltage and frequency shown on the serial number plate correspond to your domestic power supply. Voltage can vary by ±6% of the rated voltage. For operation with different voltages, a suitably sized auto-transformer must be used. -
Page 13: Installation / Instructions For Totally Built-In Appliances
Instructions for totally built-in appliances Door reversibility The appliance is supplied with the right door opening. To change the opening direction of the door proceed as in the following instructions before installing it. 1. Unscrew the upper pin and remove the spacer 2. - Page 14 Furthermore, it is necessary that the niche is provid with a conduct of ventilation having the following dimensions: depth 50 mm width 540 mm PR01 Push appliance into the housing until stop strip (A) touches the kitchen unit. D023 Open the door and push the appliance against the side of the kitchen unit opposite to that of appliance hinges.
- Page 15 Apply covers (B) on joint cover lugs and into hinge holes. D726 Separate parts A, B, C, D as shown in the figure PR266 Place guide (A) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes.
- Page 16 Open the appliance door and the furniture door at 90°. Insert the small square (B) into guide (A). Put together the appliance door and the furniture door and mark the holes as indicated in the figure. Remove the squares and drill holes with ø 2 mm at 8 mm from the outer edge of the door.
