- Page 1 FRIGORIFERO- CONGELATORE FRIDGE-FREEZER KÜHL- GEFRIERSCHRANK REFRIGERATEUR- CONGELATEUR ZI 922/10 LIBRETTO ISTRUZIONI INSTRUCTION BOOKLET BEDIENUNGSANLEITUNG MODE D’EMPLOI 2222 281-71...
-
Page 2: Warnings
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
connecting the appliance to allow the oil to flow back in the compressor. Environment Protection This appliance does not contain gasses which could damage the ozone layer, in either its refrigerant circuit or insulation materials. The appliance shall not be discarded together with the urban refuse and rubbish. -
Page 4: Use
Cleaning the interior Before using the appliance for the first time, wash the interior and all internal accessories with luke- warm water and some neutral soap so as to remove the typical smell of a brand-new product, then dry thoroughly. Do not use detergents or abrasive powders, as these will damage the finish. -
Page 5: Freezing Fresh Food
Freezing fresh food The 4-star compartment is suitable for long term storage of commercially frozen food, and for freezing fresh food. To freeze fresh foods it is not necessary to change the setting of the thermostat knob. However, for a quicker freezing operation, turn the thermostat knob to the coldest setting;... -
Page 6: Fresh Food Refrigeration
Fresh food refrigeration To obtain the best performance: ¥ do not store warm food or evaporating liquids in the refrigerator; ¥ do cover or wrap the food, particularly if it has a strong flavour. ¥ Position food so that air can circulate freely round Movable shelves The walls of the refrigerator are equipped with a series of runners so that the shelves can be... -
Page 7: Hints
HINTS Hints for refrigeration types together with the recommended storage time (in months) from the time of freezing; Useful hints: ¥ do not put carbonated liquids (fizzy drinks, Meat (all types): wrap in polythene bags and place etc.) in the freezer compartment as they may on the glass shelf above the vegetable drawer. -
Page 8: Maintenance
MAINTENANCE Unplug the appliance before carrying out Periods of non-operation any maintenance operation. When the appliance is not in use for long periods, Periodic cleaning take the following precautions: remove the plug from the wall socket; Clean the inside with warm water and bicarbonate of soda. -
Page 9: Customer Service And Spare Parts
as follows: 1. pull out the plug from the wall socket or turn the thermostat knob to the ÇOÈ setting; 2. remove any stored food, wrap it in several layers of newspaper and put it in a cool place; 3. leave the door open, and insert the plastic scraper in the appropriate seating at the bottom centre, placing a basin underneath to collect the defrost water. -
Page 10: Technical Information
TECHNICAL INFORMATION Energy Efficiency Class Fridge Net Capacity lt. Freezer Net Capacity lt. Energy Consumption kWh/24h Energy Consumption kWh/annuo Freezing Capacity kg/24h Rising Time The Technical info are on the rating plate situated on the left inside the appliance. INSTALLATION Location Attention The appliance should be installed well away from... -
Page 11: Changing The Opening Direction Of The Doors
I nstructions for totally built-in appliances Door reversibility D114 Right opening Left opening Remove the pins (P) and (P1) Remove (P) from both sides and the door. Remove the middle hinge (A) and refit it on the opposite side. Refit the door and (P) on the left side. Remove (P1) from the right side. - Page 12 Push appliance into the housing until stop strip (A) touches the kitchen unit. D023 Open the door and push the appliance against the side of the kitchen unit opposite to that of appliance hinges. Fasten the appliance with 4 screws provided in the kit included with the appliance.
- Page 13 Separate parts A, B, C, D as shown in the figure PR266 Place guide (A) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes. After having drilled holes, fix the guide with the screws supplied.
- Page 14 Should the lining up of the furniture door be necessary, use the clearance of slots. At the end of operations, it is necessary to check if the door of the furniture closes properly. PR168 Fix cover (D) on guide (B) until it clips into place. PR167/1 If the appliance is to be fitted laterally to the kitchen unit, it will be sufficient to loosen the screws of the...
