- Page 1 KÜHL- GEFRIERSCHRANK FRIDGE-FREEZER JÄÄKAAPPI- PAKASTIN ZI 921/9 KA BEDIENUNGSANLEITUNG INSTRUCTION BOOKLET KÄYTTÖOHJE 2223 430-11...
-
Page 2: Warnings
WARNINGS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
speed up the thawing process other than those Environment Protection recommended by the manufacturer. Never use metal objects for cleaning your appliance as it may get damaged. This appliance does not contain gasses which could damage the ozone layer, in either its Installation refrigerant circuit or insulation materials. -
Page 4: Use
Cleaning the interior Fresh food refrigeration Before using the appliance for the first time, wash To obtain the best performance: the interior and all internal accessories with luke- • do not store warm food or evaporating liquids in warm water and some neutral soap so as to remove the refrigerator;... -
Page 5: Storage Of Frozen Food
Storage of frozen food Thawing When first starting-up or after a period out of use, Deep-frozen or frozen food, prior to being used, can before putting the products in the compartment let be thawed in the refrigerator compartment or at the appliance run for at least two hours on the room temperature, depending on the time available coldest setting, then turn the thermostat knob to the... -
Page 6: Positioning The Door Shelves
Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be placed at different heights. To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows until it comes free, then reposition as required. Humidity control The glass shelf incorporates a device with slits (adjustable by means of a sliding lever), which... -
Page 7: Hints
HINTS Hints for refrigeration • The symbols on the drawers show different types of frozen goods. Useful hints: The numbers indicate storage times in months for Meat (all types): wrap in polythene bags and place the appropriate types of frozen goods. Whether on the glass shelf above the vegetable drawer. -
Page 8: Maintenance
MAINTENANCE Unplug the appliance before carrying out Periods of non-operation any maintenance operation. When the appliance is not in use for long periods, Warning take the following precautions: This appliance contains hydrocarbons in its cooling remove the plug from the wall socket; unit;... -
Page 9: Customer Service And Spare Parts
Never use sharp metal tools to scrape off frost from the evaporator as you could damage it. However, when the ice becomes very thick on the inner liner, complete defrosting should be carried out as follows: 1. pull out the plug from the wall socket or turn the thermostat knob to the «O»... -
Page 10: Technical Information
TECHNICAL INFORMATION Fridge Net Capacity lt. Freezer Net Capacity lt. Energy Consumption kWh/24h 0,871 Energy Consumption kWh/annuo Freezing Capacity kg/24h Rising Time The Technical info are on the rating plate situated on the left inside the appliance. INSTALLATION Location Attention The appliance should be installed well away from sources of heat such as radiators, boilers, direct It must be possible to disconnect the appliance from... -
Page 11: Changing The Opening Direction Of The Doors
I nstructions for totally built-in appliances Door reversibility The appliance is supplied with the right or the left door opening. To change the opening direction of the door proceed as in the following instructions before installing it. 1. Unscrew the upper pin and remove the spacer 2. - Page 12 Fit the appliance in the niche by making sure that it stands against the interior surface of the unit on the side where the door hinges of the appliances are fitted. Insert the appliance until the upper strip butts up against the unit (1) and make sure that the lower hinge is in line with the surface of the unit (2).
- Page 13 Place guide (Ha) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes. After having drilled holes, fix the guide with the screws supplied. Fix cover (Hc) on guide (Ha) until it clips into place Open the appliance door and the furniture door at 90°.
- Page 14 Fix cover (Hd) on guide (Hb) until it clips into place. If the appliance is to be fitted laterally to the kitchen unit, it will be sufficient to loosen the screws of the little plates (D), move them as shown in Fig. and then fasten them up again.
- Page 15 www.zanussi.pl...
