American Standard Colony Soft 2275.503 Specifications

2275.500 Shown
HOLE
SIZE
29mm
(1-1/8")

GENERAL DESCRIPTION:

Centerset lavatory faucet on 4" centers. 1/4 turn washerless
ceramic disc valve cartridges. Durable cast brass waterways
with one-half inch male inlet shanks. Metal body. Color
matched underbody. Lever handles. 20" (500mm) long flexible
stainless steel drain cable is pre-assembled to faucet body.
®
Metal Speed Connect drain body with 1-1/4 inch (32mm) tail
piece, (2275.509). Non-Metallic Speed Connect drain body with
1-1/4 inch (32mm) tail piece, (2275.503). 1.5 gpm/5.7L/min.
maximum flow rate.
SUGGESTED SPECIFICATION:
Two-handle 4" centerset lavatory faucet shall feature a cast brass waterway. Shall also feature 1/4 turn washerless ceramic
disc valve cartridges. Shall also feature a drain body with stainless steel cable actuation. Fitting shall be American Standard
Model # 2275.____.____.
© 2008 AS America Inc.
102mm
(4")
154mm
(6-1/16")
TWO-HANDLE CENTERSET LAVATORY FAUCET
MODEL NUMBER:
2275.503 Colony Soft 2 Handle Centerset
Lever Handles. Non-metalic Speed Connect
Pop-up drain.
2275.509 Colony Soft 2 Handle Centerset
Lever Handles. Metal Speed Connect Pop-up drain.
22mm
(7/8")
28mm
(1-1/16")

PRODUCT FEATURES:

Cast Brass Waterways
durable. Integral tabs on casting provide a wobble-free
installation.
Ceramic Disc Valve Cartridges:
drip-free performance.
Low Lead:
Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Longer Spout: Provides extended reach into lavatory.
Exclusive Speed Connect Metal Drain:
• Fewer parts. Installs in less time.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in tight spaces.
Simple Installation:
Faucet drops in from top. Quick spin nuts secure faucet in
place.
C85
COLONY SOFT
®
107mm
(4-3/16")
41mm
(1-5/8")
1/2 NPSM
107mm
(4-3/16")
32mm OD
(1-1/4 OD)
with "City Shanks"
Assures a lifetime of
Fast and easy one person installation.
:
Strong and
