American Standard Colony Soft 2275.40 Specification Sheet

2275.400 Shown.
HOLE
SIZE
29mm
(1-1/8")

GENERAL DESCRIPTION:

Centerset lavatory faucet on 4" centers. 1/4 turn washerless
ceramic disc valve cartridges. Durable cast brass waterways
with one-half inch male inlet shanks. Metal body. 20" (500mm)
long flexible stainless steel drain cable is pre-assembled to
faucet body. Metal Speed Connect™ drain body with 1-1/4 inch
(32mm) tail piece, (2275.409). Non-Metallic Speed Connect™
drain body with 1-1/4 inch (32mm) tail piece, (2275.403). 2.2
gpm/8.3L/min. maximum flow rate. Clear Acrylic Handles are
facetted on the inside.
SUGGESTED SPECIFICATION:
Two-handle 4" centerset lavatory faucet shall feature a cast brass waterway. Shall also feature 1/4 turn washerless ceramic
disc valve cartridges. Shall also feature a drain body with stainless steel cable actuation. Fitting shall be American Standard
Model # 2275.40__.____.
© 2006 American Standard Inc.
TWO-HANDLE CENTERSET LAVATORY FAUCET
102mm
(4")
154mm
(6-1/16")
MODEL NUMBER:
2275.403 Centerset Lavatory Faucet
Clear Acrylic Handles. Non-metalic Speed Connect™
Pop-up drain.
2275.409 Centerset Lavatory Faucet
Clear Acrylic Handles. Metal Speed Connect™ Pop-up
drain.
1/2 NPSM
22mm
(7/8")
28mm
(1-1/16")

PRODUCT FEATURES:

Cast Brass Waterways
durable. Integral tabs on casting provide a wobble-free
installation.
Ceramic Disc Valve Cartridges:
smooth handle operation
Reversible for use on either "hot" or "cold" side.
Low Lead:
Meets NSF Standard 61/Section 9 & Prop 65 lead
requirements.
Speed Connect™ Drain:
• Fewer parts. Installs in less time.
• No adjustments required - seals the first time, every time.
• Flexible stainless steel cable - installs effortlessly in tight spaces.
Longer Spout:
Provides extended reach into lavatory.
Simple Installation:
Fast and easy one person installation.
Faucet drops in from top. Quick spin nuts secure faucet in
place.
C99
COLONY SOFT
107mm
(4-3/16")
41mm
(1-5/8")
107mm
(4-3/16")
32mm OD
(1-1/4 OD)
:
with "City Shanks"
Assures a lifetime of
and drip-free performance.
Strong and
