ELECTRIC FAN HEATERS
Devil 6002, 6003, 6005, 6009 & 6015
Part Nos: 6925218, 6925220, 6925225, 6925230 & 6925235
OPERATING & MAINTENANCE
INSTRUCTIONS
GC1011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Devil 6002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke Devil 6002

  • Page 1 ELECTRIC FAN HEATERS Devil 6002, 6003, 6005, 6009 & 6015 Part Nos: 6925218, 6925220, 6925225, 6925230 & 6925235 OPERATING & MAINTENANCE INSTRUCTIONS GC1011...
  • Page 2: Introduction

    INTRODUCTION Thank you for purchasing this CLARKE Electric Fan Heater. Please read this manual thoroughly and follow the instructions carefully. Before attempting to use the heater, thoroughly familiarise yourself with the heater & its operation. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to the heater giving you long and satisfactory service.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION .................. 2 GUARANTEE ..................2 ENVIRONMENTAL PROTECTION ............2 SPARE PARTS & SERVICING CONTACTS ..........2 TABLE OF CONTENTS ................3 GENERAL SAFETY RULES ..............4 ELECTRICAL CONNECTIONS .............. 6 OPERATION ..................8 MAINTENANCE ................... 10 FAULT FINDING ...................
  • Page 4: General Safety Rules

    GENERAL SAFETY RULES WORK AREA 1. These heaters are for INDOOR USE ONLY. 2. Do not expose the heater or power cable to rain or wet conditions. Any water entering the heater will increase the risk of electric shock. DO NOT use this heater in a bathroom, shower room, in the vicinity of a swimming pool, or any wet environment.
  • Page 5 3. Keep the mains cable well away from machines and ensure an adequate electrical supply is close at hand so that the operation is not restricted by the length of the cable. 4. ALWAYS disconnect from the mains supply before moving the heater or performing any maintenance tasks.
  • Page 6: Electrical Connections

    ELECTRICAL CONNECTIONS DEVIL 6002 (2KW)AND 6003 (3KW) HEATER UNITS These models are provided with a 13 amp BS 1363 plug, fitted with a 13amp fuse and MUST be connected to a standard, 230 Volt (50Hz) electrical supply, preferably through an approved plug, or a suitably fused isolator switch.
  • Page 7 Plug must be BS1363/A approved Earth Always fit a 13 Amp fuse. (Green and Yellow) Neutral Live (Blue) (Brown) Ensure that the outer sheath of the cable is firmly held by the clamp We strongly recommend that this machine is connected to the mains supply via a Residual Current Device (RCD).
  • Page 8: Operation

    OPERATION The Devil range of fan assisted electric heaters are suitable for household (Devil 6002 & 6003 only) or workshop/factory use. They incorporate a thermostat which detects the temperature of the room air and controls the heater to maintain a pre-selected temperature between 0 & 40°C. A manually reset thermal cutout is provided for safety in the event of overheating on the 6005, 6009 &...
  • Page 9 3-position fan speed control thermostatic temperature control The thermostat will then switch the heater on and off automatically to control the room temperature according to the pre-set value, maintaining a constant room temperature. When using the heater to warm a cold room, first turn the thermostat to MAX and run the heater on full power until the room temperature reaches the required value, then turn the thermostat anti-clockwise until it switches off.
  • Page 10: Maintenance

    • Avoid using solvents when cleaning plastic parts, most plastics are susceptible to damage from various types of commercial solvents. • Refer to your CLARKE dealer if internal maintenance is required. The unit is fitted with tamper-proof screws to discourage users from dismantling the heater.
  • Page 11: Fault Finding

    FAULT FINDING l l u & , y l l n i l i r l n i . t i H " " s i l l l i y l l y l l . t i...
  • Page 12: Parts Lists & Diagrams

    PARTS DIAGRAM DEVIL 6002 c t i l l i r c i t l l i r...
  • Page 13 PARTS DIAGRAM DEVIL 6003 e l l i t n i n i p i l l l o l l o i t a...
  • Page 14 PARTS DIAGRAM DEVIL 6005 e l l c i t l l o l l o...
  • Page 15 PARTS DIAGRAM DEVIL 6009 e l l l l o c i t l l o...
  • Page 16 PARTS DIAGRAM DEVIL 6015 l i r s i s...
  • Page 17: Technical Specification

    ° 0 ° 0 ° 0 ° 0 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice.
  • Page 18: Declarations Of Conformity

    DECLARATION OF CONFORMITY...
  • Page 19 DECLARATION OF CONFORMITY...
