Summary of Contents for Clarke DEVIL 7030
- Page 1 Only suitable for well insulated areas and not designed to be the primary heat source 30KW ELECTRIC FAN HEATER MODEL NO: DEVIL 7030 PART NO: 6935458 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL1123- Rev 11...
-
Page 2: Function And Operating Parameters
INTRODUCTION Thank you for purchasing this CLARKE product. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase. - Page 3 THE FOLLOWING TABLE ADDRESSES THE INFORMATION REQUIREMENTS OF REG.2015/1188 Item Symbol Value Unit Heat output Measured seasonal space heating energy efficiency Nominal heat output Minimum heat output (indicative) Maximum continuous heat output Auxiliary electricity consumption At nominal heat output At minimum heat output In standby mode Type of heat input for electric storage local heaters only Manual heat charge control with integrated thermostat...
-
Page 4: Safety Symbols
6. Check the heater for damage before use. DO NOT use if the heater tubes/ elements are damaged or broken. Any damage should be properly repaired or the part replaced. If in doubt, DO NOT use. Consult your local CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 5 Cleaning and Maintenance. 3. Only recommended parts should be used. Unapproved parts may be dangerous and will invalidate the warranty. 4. DO NOT attempt to repair a damaged heater, contact the Clarke service department. POSITIONING WARNING: DO NOT USE THE HEATER NEAR FLAMMABLE MATERIAL, LIQUIDS, SOLIDS, GASSES OR COMPRESSED GAS CYLINDERS ETC.
-
Page 6: Operation
OPERATION 1. This heater is intended for drying & warming of commercial/industrial buildings where adequate ventilation is provided. It is NOT for domestic use or for heating habitable areas. 2. The heater should NOT be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge. -
Page 7: Electrical Connections
SAFETY SYSTEMS THERMOSTATIC PROTECTION The Devil 7030 has a manual reset thermal cut out to prevent the unit from overheating. If the thermal cut out activates, then turn off the power and disconnect from the power supply. Allow the heater to cool down for several minutes before pressing the reset button. - Page 8 ASSEMBLY 1. Fit the right leg frame to the main body as shown. NOTE: The bolt needs to be inserted before the handwheel. NOTE: The bolt goes through the larger of the 2 holes in the spacer. 2. Fit the axle and left hand support frame.
- Page 9 OPERATION WARNING: DO NOT USE THIS HEATER IN SMALL ROOMS WHEN THEY ARE OCCUPIED BY PERSONS NOT CAPABLE OF LEAVING THE ROOM ON THEIR OWN, UNLESS CONSTANT SUPERVISION IS PROVIDED. CAUTION: SOME PARTS OF THIS PRODUCT CAN BECOME VERY HOT AND CAUSE BURNS.
-
Page 10: Maintenance
• Make sure that the heater grill is not blocked. • No other maintenance is required, should you discover any problem with the heater, return it to the Clarke service department for repair. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 11: Specifications
SPECIFICATIONS Operating Voltage, Current and Frequency: 400 V / 43A / 50Hz / 3 Phase (V / A / Hz / Phs) Operating Temperature: (Min/Max) (°C) 0-40°C Heat Output: (kW) 30 kW Air Output: (m 1440m Safety Device Thermal cut-out Duty Cycle Classification Continuous duty Electrical Insulation Class... -
Page 12: Troubleshooting
Fuse blown or Replace if necessary and investigate although circuit breaker cause. If fuse blows plugged in trips. repeatedly, consult your Clarke dealer. with the No power at Insert the plug in a suitable socket. switch and socket outlet. thermostat switched on. -
Page 13: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts List
PARTS LIST Front Rings Motor Front Grille Rear Grille Heat Shield Rear Rings Switch Knob Heating Elements Securing Rings Heater Bracket Upper Speed Controller Heater Bracket Bottom Location Part For Switch Wheel Temperature Controller Wheel Cover Fasten Spring Securing Plate Thermostat Knob Axle Control Box L... - Page 15 DECLARATION OF CONFORMITY-UKCA & CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
