- Page 1 Operating & Installation Instructions Cooker SG205/1WL...
-
Page 2: Table Of Contents
CONTENTS Instructions for the User Instructions for the Installer Important Safety Information Technical Features Description of the appliance Safety Advice Gas connections Using the appliance Using the oven Hints & Tips Installation Using the Grill Location Cooking Chart Ventilation Using the Hob Levelling Maintenance and Cleaning Gas connections... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION You MUST read these warnings carefully before installing or using the appliance. If you need assistance, contact our Customer Care Department on 08705 950950 Installation During Use • This cooker must be installed by • This cooker is intended for domestic qualified personnel, according to the cooking only. -
Page 4: Environmental Information
• Never pull the appliance by the oven Environmental Information handle. After installation, please dispose of the • • This cooker should be kept clean at all packaging with due regard to safety times. A build-up of fat or foodstuff could and the environment. -
Page 5: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Cooker lid 2000W 1000W Control panel Door handle Oven door with glass 2000W 2600W Front left burner (semi-rapid) Back left burner (semi-rapid) Back right burner (auxiliary) Front right burner (rapid) Adjustable small feet Control panel Oven/grill knob Back left burner control knob Front left burner control knob Back right burner control knob... -
Page 6: Using The Appliance
USING THE APPLIANCE Before the First Use of the Cooker Remove all packaging both inside and outside of the cooker, before Shelf levels using it. Before first use, the oven should be heated without food. During this time, an unpleasant odor may be emitted. -
Page 7: Cooking In The Oven
Cooking in the Oven Traditional cooking is made by natural Maximum “8” convection; the heated air circulates on the Minimum “1” principle of ascending and descending Grill function (heat come from the top draughts. It is necessary to pre-heat the burner only. -
Page 8: Hints And Tips
Hints and Tips Condensation and steam The effects of dishes on cooking When food is heated it produces steam in results the same way as a boiling kettle. The oven Dishes and tins vary in their thickness, vents allow some of this steam to escape. conductivity, colour, etc. -
Page 9: Using The Grill
Using the Grill Grill burner ignition Accessible parts may become hot • Open the oven door. when the grill is in us. Children should be • Hold a flame to the gas grill burner holes kept away. (see fig.). • Press the oven/grill function control The grill pan will become hot during knob, then turn it to the “grill symbol”. - Page 10 Grilling Grilling meat When using the grill it has to be When using the grill it has to be supervised, the oven door opened and supervised, the oven door opened the grill deflector “A” in place. and the grill deflector “A” in place. Attention: when turning on the When grilling, only the top burner is heating.
-
Page 11: Cooking Chart
COOKING CHART Preheating Cooking Tray type or Material of Shelf Food dimension Thermostat Time Thermostat Time the tray pos. (dxwxh) cm tray pos. (min) pos. (min) Roasting meal 20 min. for each 0.5 Kg / rare 25 min. for each - beef 0..5 Kg/medium 30min. -
Page 12: Using The Hob
If you should cooking more than one tray, you can take the top tray out of the oven when the cakes are finished and move the lower tray to the higher shelf to finish the cooking (about 5 min.) These two pans are positioned on the same shelf, at the diagonal of the oven grid Put the dishes in the center of the shelf The oven grid in the position... - Page 13 Selecting the Correct burner Good use Above every knob there is a symbol for the corresponding burner. For good cooking results, always choose pans, which correctly fit to the diameter of the burner used (see figs). Choose thick, flat bottom pots. We recommend the flame is lowered as soon Bad use as the liquid starts boiling.
-
Page 14: Maintenance And Cleaning
MAINTENANCE AND CLEANING Oven Cavity The oven should be kept clean at The enamelled oven cavity is best cleaned all times. A build-up of fats or other whilst the oven is still warm. foodstuffs could result in a fire, Wipe the oven over with a soft cloth soaked especially in the grill pan. -
Page 15: Something Not Working
Burners The burner caps and crowns can be Burner removed for cleaning. Wash the burners caps and crowns using Burner hot soapy water, and remove marks with a ring mild paste cleaner. A well-moistened soap impregnated steel wool pad can be used with caution, if the marks are particularly IIgnition difficult to remove. - Page 16 4. Cooking results are not satisfactory Check that: The correct temperature has been selected • The cooking time is adapted • The grill is placed correctly in the oven • 5. The oven smokes Check that: The oven does not need cleaning •...
-
Page 17: Instructions For The Installer
INSTRUCTIONS FOR THE INSTALLER Technical features Free standing Class 1 Pan support Enamelled Front right Rapid 2,60 kW Back right Auxiliary 1,00 kW Front left Semi-rapid 2,00 kW Back left Semi-rapid 2,00 kW Oven Oven Oven power 3,20 kW Grill Grill power 2,50 kW Accessories... -
Page 18: Gas Connections
ADVICE FOR SAFETY Gas connections Flexible hoses, end fittings and sockets for gas burning appliances – BS Before installation ensure gas type and • 669 Current editions; pressure and the pre-setting of the Installation of domestic gas cooking appliance are consistent. appliances (1 and 3 family gases) –... -
Page 19: Installation
INSTALLATION Location of appliance The cooking appliance must be The appliance must not be installed in a bed- fitted with a stability chain firmly secured sitting room of volume less than 20m or in a to the wall. bathroom or shower room. It is essential that the Stability appliance is positioned as in the enclosed figure hook... -
Page 20: Gas Connections
Leveling Fix the support with two legs with the washer and nuts, delivered with the cooker, see the figure. GAS CONNECTIONS Your cooker is delivered adjusted for the kind BACK OF THE COOKER of gas stated on the rating plate. If the appliance is converted to natural gas and the pressure for natural gas is 20mbar, the following methods of connection to the... - Page 21 • The appliance flexible connector should not be subjected to undue forces either in Rigid Connection Where it is not possible to make the normal use or whilst connected or connection using a rubber hose, a rigid pipe disconnected; The socket which the plug of work connection must be used.
-
Page 22: Conversion Of Gas
CONVERSION OF GAS Your cooker is designed to work with natural adjust the primary air (oven and grill); • gas, and is convertible for use with propane check the gas connection; • or butane. Stick the label supplied with the The LPG conversion kit is available from your replacement nozzles (from the Service Service Force Centre and must be fitted by a... - Page 23 Replace the nozzles of the hob burners Every appliance has spare nozzles for every type of gas. The whole length of every nozzle is marked in millimetres on the nozzle. Before any modifications or conversion to a different kind of gas, you have to ensure that all control knobs are in the OFF position, and the appliance has cooled completely.
- Page 24 Unscrew or screw the by-pass screw • until a regular small flame is reached. For LPG screw completely the by-pass • screw. Reassemble the parts following the same procedure in reverse. Check that, when turning the knob quickly from the maximum position to the minimum one, the flame does not go out.
- Page 25 Flame adjustment Table no.2 Air adjusting (mm) Oven burner Gas type The burner is correctly adjusted when the Oven Grill flame is stable, silent and goes out without any noise. • When the flames are too short, the nozzle is whistling or the flames have the tendency to detach from the burner, it means that there is too much air in the valve.
- Page 26 Unscrew or screw the by-pass screw • by-pass until a regular small flame is reached. For LPG completely tighten the by-pass • screw. The flame shouldn’t extinguish when closing the oven door. Grill burner The grill temperature cannot be adjusted. To obtain a lower temperature or slower cooking time the grill pan must be lowered away from the flame.
-
Page 27: Service And Spare Parts
Ireland please contact us at the address Bendix appliance and or for further below: information on our products, contact our Tricity Bendix Customer Care Department by letter or Electrolux Group ( Ire ) Ltd telephone as follows: Long Mile Road... -
Page 28: Guarantee Conditions
GUARANTEE CONDITIONS Standard Guarantee Conditions Exclusions We Tricity Bendix undertake that if, within 12 This guarantee does not cover: months of the date of the purchase, this Tricity • Damage or calls resulting from Bendix appliance or any part thereof is proved... -
Page 29: European Guarantee
European Guarantee If you should move to another country within Before you move, please contact your Europe then your guarantee moves with you nearest Customer Care Centre, listed below, to your new home subject to the following to give them details of your new home. They qualifications: will then ensure that the local Service Organization is aware of your move and able... - Page 30 www.electrolux.com Albania +35 5 4 261 450 Rr. Pjeter Bogdani Nr. 7 Tirane Belgique/België/Belgien +32 2 363 04 44 Bergensesteenweg 719, 1502 Lembeek Česká republika +420 2 61 12 61 12 Budějovická 3, Praha 4, 140 21 Danmark +45 70 11 74 00 Sjællandsgade 2, 7000 Fredericia Deutschland +49 180 32 26 622...
- Page 31 Portugal +35 12 14 40 39 39 Quinta da Fonte - Edificio Gonçalves Zarco - Q 35 -2774-518 Paço de Arcos Romania +40 21 451 20 30 Str. Garii Progresului 2, S4, 040671 Schweiz - Suisse - Svizzera +41 62 88 99 111 Industriestrasse 10, CH-5506 Mägenwil Slovenija...
- Page 32 www.electrolux.com 342 702 368 – 00 – 05042007 Subject to change without notice...
