- Page 1 OPERATING & INSTALLATION INSTRUCTIONS GAS COOKER SG 211...
-
Page 3: Table Of Contents
CONTENTS Instructions for the User Instructions for the Installer Warnings Technical Features Use and care Advice for safety Gas connection Use of the appliance Electrical connections Using the Oven Using the Grill Installation Cooking Chart Using the Hob Gas connection Hints and tips Conversion of gas Maintenance and cleaning... -
Page 4: Warnings
IMPORTANT SAFETY INFORMATION You MUST read these warnings carefully before installing or using the appliance. If you need assistance, contact our Customer Care Department on 08705 950950. Installation • This cooker must be installed by qualified • Unstable or misshapen pans should not be personnel, according to the manufacturer’s used on the hob burners as unstable pans instructions and to the relevant British... -
Page 5: Instructions For The User
INSTRUCTIONS FOR THE USER USE AND CARE Control panel SG211X 1. Back left burner control knob 4. Back right burner control knob 2. Front left burner control knob 5. Ignition switch 3. Front right burner control knob 6. Oven/Grill burner control knob (selector) 1. -
Page 6: Use Of The Appliance
USE OF APPLIANCE Before the First Use of the Cooker Remove all packaging both inside and outside of the cooker, before using it. Before first use, the oven should be heated without food. During this time, an unpleasant odour may be emitted. This is quite normal. 1. -
Page 7: Cooking In The Oven
Ignition Attention: when turning on the oven and grill burner the oven door has to be opened. • Open the oven door, push and turn the control knob to the left to position 8, keeping the control knob pressed. • At the same time, push the electronic ignition knob (see fig). -
Page 8: Using The Grill
Using the Grill When grilling, the accessible parts of the appliance are hot and the appliance should not be left unattended. Take care that children do not play near it. While the grill is operating leave the oven door half open and put the grill deflector “A”... - Page 9 Heat comes from the top of the oven. It is suitable for grilling meat (beef bacon, pork bacon …) that remains tender, for toast or to brown dishes already cooked dishes. Grilling meat When using the grill it has to be supervised, the oven door opened and the grill deflector “A”...
-
Page 10: Cooking Chart
COOKING CHART Preheating Cooking Tray type or Material of Shelf Thermo- Thermo- Food dimension Time Time the tray position stat stat (dxwxh) cm tray (min) (min) pos. pos. Roasting meal 20 min. for each 0.5 Kg / rare - beef 25 min. -
Page 11: Using The Hob
Using the Hob The Hob Burners The symbol on the control panel shows which burner is operated by the knob. (See control panel). Maximum level Minimum level Use the maximum level for boiling and the minimum for simmering. Always choose positions between the minimum and maximum, never between maximum and off. - Page 12 The following diameter pans can be used: Burner Power Diameter (mm) (kW) min. max. Rapid 3,00 Semi-Rapid 2,00 Auxiliary 1,00 Accessories delivered with the appliance The following accessories are supplied with your appliance. • Grill Deflector To be used when the grill is operation. •...
-
Page 13: Hints And Tips
Hints and Tips • The thickness, the material and the colour of Condensation and steam the pan will influence the cooking results. Condensation may form on the cooker. This is • When cooking, certain dishes increase in quite normal and nothing to worry about. The condensation water forms when heat and volume, ensure the pan is large enough. -
Page 14: Maintenance And Cleaning
MAINTENANCE AND CLEANING The oven should be kept clean at all To remove more stubborn stains, wet and leave to dissolve, do not scratch and avoid the use of times. A build-up of fats or other abrasive or caustic products that could damage foodstuffs could result in a fire. -
Page 15: Something Not Working
SOMETHING NOT WORKING If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 16: Service And Spare Parts
Please note that it will be necessary to provide proof of purchase for any in-guarantee service calls. CUSTOMER CARE For general enquiries concerning your Tricity Bendix appliance and or for further information on our products, contact our Customer Care Department by letter or telephone as follows: Customer Care Department... -
Page 17: Guarantee Conditions
GUARANTEE CONDITIONS Standard Guarantee Conditions We Tricity Bendix undertake that if, within 12 months of the date of the purchase, this Tricity Bendix appliance or any part thereof is proved to be defective by any reason only of faulty workmanship or... -
Page 18: Instructions For The Installer
INSTRUCTIONS FOR THE INSTALLER TECHNICAL FEATURES Free standing Class 1 Pan support Enamelled 2000 W Front right burner Semirapid 2000 W Back right burner Semirapid 3000 W Front left burner Rapid 1000 W Back left burner Auxiliary Spark Hob ignition Oven Oven Oven burner power... -
Page 19: Advice For Safety
ADVICE FOR SAFETY Gas connections • Before installation ensures that the local distribution conditions (gas type pressure) pre-setting appliance are consistent. • This appliance must be installed only in a room with good ventilation. • This appliance must not connect to a chimney. -
Page 20: Electrical Connections
Electrical connections A cut off plug inserted into a 13-amp Any electrical work required to install socket is a serious safety (shock) hazard. this cooker should be carried out by a Ensure that the cut off plug is disposed of qualified electrician or competent person, in safety. -
Page 21: Installation
INSTALLATION Location of appliance The appliance must not be installed in a bed-sitting room of volume less than 20m or in a bathroom or shower room. It is essential that the appliance is max 400 positioned as in the enclosed figure i.e. shelves, wall cabinets and cooker hoods must be fitted a minimum of 690mm directly above the hob and min 600... -
Page 22: Gas Connection
Levelling The appliance is provided with adjustable small feet placed in the back and front corners of the base. By adjusting the small feet it is possible to change the height of the appliance so as to ensure a better levelling with other surfaces and a uniform distribution of the liquids contained in pans or pots. - Page 23 Connection shall be by means of an appliance flexible connector for use with a self-sealing plug- in device, complying with: Flexible hoses, end fittings and sockets for gas burning appliances – BS 669; The appliance flexible connector should not be subjected to undue forces either in normal use or whilst connected or disconnected;...
-
Page 24: Conversion Of Gas
CONVERSION OF GAS Your cooker is designed to work with natural gas, and is convertible for use with propane or butane. The LPG conversion kit is available from your Service Force Centre and must be fitted by a Corgi Registered engineer. For changing the gas type it is necessary to: •... - Page 25 Replace the nozzles of the hob burners Before any modifications or conversion to a kind of different gas, you must DISCONNECT the cooker from the electricity supply and ensure that all control knobs are in the OFF position, and the appliance has cooled completely.
- Page 26 Replace the nozzles of the oven burners Oven burner To replace the gas oven nozzle, follow this procedure: • Check the table no.1 for diameter of nozzle; • Remove the oven removable base panel; • Remove the screw 1 on the oven burner •...
- Page 28 Slough Berkshire SL1 1DZ Tel: 08705 950 950 SG 211 - 342701424-A-030505-01 © Electrolux plc 2005 From the Electrolux Group. The world’s No.1 choice The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
