- Page 1 ® CHAT 60-U USB with Call Control Personal Speakerphone for Skype™ USER’S MANUAL VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299...
-
Page 2: Table Of Contents
............3 oLume anD uttons CONNECTINg THE CHAT 60-U TO A PC ........4 CHAPTER 3: CONFIGURING THE CHAT 60-U INSTALLINg THE CHAT SOfTwARE fOR wINdOwS ....5 USINg A 3rd-Party APPLICATION ..........5 USINg THE CHAT APPLICATION ..........6 ............ -
Page 3: Chapter 1: Introduction
Reduction and Automatic Level Controls, producing crystal clear conversations. Though designed specifically to be used with Skype, the CHAT 60-U can also be used with other devices such as enterprise telephones and other applications such as voIP softphones, web conferencing, instant messaging and PC-based gaming. -
Page 4: Important Safety Information
IMPORTANT SAFETy INFORMATION Read the safety instructions before using this product. This personal speakerphone is not designed for making emergency telephone calls when the power fails. You must make alternative arrangements for telephone access to emergency services. • Read and understand all instructions. follow all warnings marked on the product. •... -
Page 5: Chapter 2: Getting Started
CHAPTER 2: GETTING STARTED CHAT 60-U CONTROLS Power LED Indicator The LEd status indicator lights blue when the CHAT 60-U is connected to a PC via USb. The LEd status indicator changes to red when Mute is on. Call Control Button The Call Control button is used to: •... -
Page 6: Connecting The Chat 60-U To A Pc
CONNECTING THE CHAT 60-U TO A PC Using the included USb cable, connect the CHAT 60-U to your PC or laptop. The status LEd on the front of the CHAT 60-U turns blue, then red, then blue again to indicate that windows recognizes the CHAT 60-U The Windows New Hardware Found dialog appears and windows installs the USb 2.0 device drivers for CHAT on your system. -
Page 7: Chapter 3: Configuring The Chat 60-U
The CHAT 60-U can be used right out of the box and there’s no software to download or install since it is only used with a PC. However, ClearOne will occasionally release new versions of the devices’ firmware which will need to be downloaded and installed. -
Page 8: Using The Chat Application
USING THE CHAT APPLICATION If not already open, start the CHAT application. for the CHAT software, click the My Devices button and select the device you want to tune (select the Other or All option if your device/application is not listed), then click the Apply to CHAT button. Adjust the speaker and volume settings on the external device or in the application to 50% (half volume). -
Page 9: Manual Updates
Ok button or Cancel to cancel the update and return to the previous screen. If the update file was downloaded directly off the ClearOne website, use the folder list in the center-right side of this window to navigate to the appropriate folder where the downloaded file was saved. -
Page 10: Help
A series of messages appears under the progress bar indicating the update is in progress. WARNING: do not unplug the CHAT 60-U while the manual update is in progress. when the update is complete, a message will appear below the progress bar stating that the update has been successful with the appropriate revision level information if applicable. -
Page 11: Advanced Settings
The Advanced screen displays the current audio settings for your CHAT 60-U from the Advanced screen, you can adjust audio settings for your CHAT 60-U, view and edit the CHAT 60-U database, and view the CHAT 60-U log file. »... -
Page 12: Chapter 4: Maintenance
Chapter 2: Getting Started of this manual for more information. • If your CHAT 60-U is connected to a USb hub, the USb hub must be connected to an external power source. • If you have another USb device (such as a digital camera) connected to your computer on the same USb bus as your CHAT 60-U, windows may generate the error message “USb Controller bandwidth Exceeded.”... -
Page 13: Interrupted Firmware Update Recovery
INTERRUPTED FIRMWARE UPDATE RECOVERy If a firmware update is interrupted by loss of power to the CHAT 60-U, the USb cable being disconnected, or an unexpected programming error, the CHAT 60-U may not function properly. To restore firmware, boot the CHAT 60-U in generic mode using the instructions shown below. -
Page 14: Chapter 5: Appendix
Audio UL Listed Speaker: bandwidth: 220 Hz - 14 kHz Model Numbers Max Output Level: 82 db SPL @ 1 foot (0.30 meter) 910-159-256 CHAT 60-U Microphone: bandwidth: 50 Hz - 7.75 kHz Processing full duplex Acoustic Echo Cancellation (AEC) -
Page 15: European Compliance
WARRANTy ClearOne Communications, Inc. (the Manufacturer) warrants that this product is free of defects in both materials and workmanship. for complete warranty information including length, coverage, and limitations, visit ClearOne on the web @ www.ClearOne.com.
