Nilfisk-Advance MX 585 Information & Operating Instructions

Nilfisk-Advance MX 585 Information & Operating Instructions

Multi extractor 220-240v eu & uk
Hide thumbs
Table of Contents

Advertisement

Quick Links

INFORMATION
&
OPERATING
INSTRUCTIONS
CAUTION: DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THIS INSTRUCTION MANUAL
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Connect the machine to a properly grounded outlet.
3. Keep machine from rain, snow, and extremes in temperatures. Store the machine in a
heated location. Use the machine indoors. Do not use outdoors.
4. Use approved chemicals only. NO SOLVENTS.
5. Never use water above 54° C/130° F in the solution tank.
6. Never turn on the solution pump without your solution line connected to the machine
and the tool.
MX 585 MULTI
EXTRACTOR
220-240V
EU & UK
1
8-1-2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX 585 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nilfisk-Advance MX 585

Summary of Contents for Nilfisk-Advance MX 585

  • Page 1 MX 585 MULTI EXTRACTOR 220-240V EU & UK INFORMATION & OPERATING INSTRUCTIONS CAUTION: DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THIS INSTRUCTION MANUAL IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS TheMX 585 MULTIis only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops, and offi ces. TheMX 585 MULTI is not intended for normal residential housekeeping purposes. NOTE: Read all instructions before using this machine. When using any electrical appliance, basic precautions should always be followed, including the following warnings: WARNING!

  • Page 3: Cleaning Solutions

    INSPECTION: Carefully unpack and inspect your MX 585 MULTI for shipping damage. Each machine is tested and in- spected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box, the machine, or its parts.

  • Page 4: Switch Plate

    SWITCH PLATE MODEL (1): This label identifi es the model of your machine. VACUUM SWITCH (2): MODEL This push-button switch turns on the vacuum. The switch will illuminate when it is on. AUTO PUMP OUT SWITCH (3): This switch will turn on the automatic pump-out pump, and it will illuminate when it is on. SOLUTION PUMP SWITCH (4): The pump switch will turn on the 1200 psi solution pump and the switch will illuminate when it is activated.
  • Page 5 SET-UP & OPERATION 1. Before each use, inspect the machine, hoses, and cleaning tools for cleanliness and completeness. Make sure hoses are in good condition and the spray nozzle(s) is tight. 2. If not using the auto-dump feature, just make sure the brass cap is on the drain hose connector on the front of the base of the machine.
  • Page 6 AUTO VACUUM SHUTOFF: When the recovery tank is full, the ball fl oat will shut-off the suction to prevent the machine from overfl owing. NOTE: the fl oat may not work if there is foam in the tank. Always use defoamer to prevent overfl...

  • Page 8: Part List

    MX 585 MULTI Part List ITEM PART No DESCRIPTION ITEM PART No DESCRIPTION 600758576 Valve, pressure relief 600758550 Lid, vacuum 600758551 Filter, dump pump inlet 600758577 Gauge, pressure reading 600758552 Ball fl oat & Filter, vacuum inlet 600758578 Dump pump kit 600758553 Hose and fi...

  • Page 9: Maintenance Schedule

    MAINTENANCE SCHEDULE CLEAN ALL FILTERS CHECK POWER CORD FLUSH OUT with DESCALER REPLACE VAC MOTOR BRUSHES Around 1500 hours REPLACE PRESSURE REGULATOR Or as needed Around 1500 hours REBUILD PUMP TROUBLE SHOOTING: IF THIS OCCURS CHECK THIS Solution tank is empty. Clogged spray tip.

  • Page 10: Specifications

    SPECIFICATIONS: Rotomolded Body: Lifetime Warranty Vacuum: One, 3-stage VAC Shutoff: Ball Float Waterlift: 28 KPa Pump: 83 Bar positive displacement, adjustable Heater: 1600/W - UK, 2000/W EU Wand: Stainless steel, single bend, two tip Weight: 50 kg Dimensions: 97 X 46 X 88 cm NOTES:...
