Abocom BUD210 Specification

Bluetooth USB Combo Dongle

The Bluetooth USB Combo Dongle, BUD210 is a wireless
device, which connected to the USB port of a PC/NB. It
works automatically as your default sound card when
plugged into your PC/NB. Just like a breeze, it will auto-
matically search its Bluetooth counterpart, BSH201
/202/203 for auto pairing and connection. You just enjoy a
quality stereo music sounds from your PC/NB. It can also
act as a data dongle for you to connect with other Bluetooth
the HCI mode, you can use Headset profile to connect with BSH203/BSR202 to chat with your friend
thru MSN/Yahoo/Skype.

FEATURES

Automatically pairs with AV stereo headset, and connected in AV mode
Could switch between AV and HCI mode automatically
Support variety of Bluetooth profile in HCI mode
Windows 2000, XP compatible

SPECIFICATION

Standards
Frequency Band
Tx Power
Rx Sensitivity
Distance
Audio Streaming Format
Audio Frequency Range
Physical Specification:
Environmental Range:
Certifications:

USER INTERFACE DEFINITION

LED
2005-05-12
Bluetooth specification V1.2 compliant
Native Bluetooth A2DP profile
Native Bluetooth AVRCP profile
Support following profile in HCI mode with soft-
ware install - GAP, DUN, OPP, HCRP, HID, PAN,
BIP, A2DP, AVRCP, SYNC, HSP, FAX, LAP, FTP
2402 ~ 2480 MHz
0.25 ~ 2.5mW (Bluetooth Power Class II)
< -80dBm (PER 1%)
> 10m (open space)
SBC 48.000kHz
20Hz ~ 22kHz
Dimension: 69.53 x 26.68 x 9.19 mm (LxWxH)
Weight: 10g
Operating temperature:-10 ~ +50℃
Humidity: Relative humidity 0 ~ 95%
FCC, CE, BQB, TELEC
Discovery: Green fast blinking
Connected: Green slow blinking
device when you installed the software. In
