- Page 1 Installation Instruction DP Lift 2 M 20 Corner fitting set 26 87x xx1 26 21x 000...
-
Page 2: Table Of Contents
Packing List Wall / Corner Installation Dimensions Diagram Panel Dimensions Fittings / Technical Data Fitting Items / Water Connections Overview Wall Installation Wall Installation Fitting Items / Water Connections Overview Corner Installation Corner Installation Thermostat Setting / Savety Function Trouble Shooting Spare Parts Cleaning Instruction Warranty... -
Page 3: Packing List
free from acetic acid a Handshower b Isiflex B shower hose 140 cm c 1 Angle bracket d 2 Hexagon head cap screws Ø 6 x 50 mm with plugs SX 8 e 2 Washer A 6,3 x 18 1 Set screw M 8 x 80 with 2 nuts M 8 and plug SX 10 g Overhead shower h 2 Water connection elbows ½"... -
Page 4: Wall / Corner Installation Dimensions Diagram
Check for required minimum height of 87" from shower tray floor Wall installation dimensions diagram KW = cold water WW = hot water ½" connection Shower tray floor before starting installation Corner installation dimensions diagram Water connections (DN5, ½“) can be installed on the right or left wall alternatively. -
Page 5: Panel Dimensions
Panel Dimensions The panel is movable 8" downward. The stated dimensions refer to the highest position of the panel. -
Page 6: Fittings / Technical Data
Fittings / Technical Data Overhead shower Aluminium profile Tray Bodyshower Thermostat grip Shut-off/selection valve Handshower Shower hose Technical Data Minimum flow pressure Operating pressure Recommended operating pressure Test pressure Hot water temperature Safety stop Flow capacity at psi Hand shower (1) Body showers, 6 jets (2) Overhead shower Overhead shower + body showers (3) -
Page 7: Fitting Items / Water Connections Overview Wall Installation
Fitting items / water connections Seal all drill holes with silicone free from acetic acid (not in scope of delivery) SW0 mm SW mm Ø0 mm wall installation Before drilling the bottom holes pay attention if hot and/or cold water supply pipes cross this area. In this case, only drill on the side without any supply pipes. - Page 8 Wall Installation mm...
- Page 9 Wall Installation mm SW mm Adjustment Thermostatic mixer please see page ...
-
Page 10: Fitting Items / Water Connections Overview Corner Installation
Fitting Items / Water Connections Overview Corner Installation Fitting items / water connections Seal all drill holes with silicone free from acetic acid (not in scope of delivery) 5 mm Ø mm SW0 mm mm corner installation Before drilling the bottom holes pay attention if hot and/or cold water supply pipes cross this area. - Page 11 Corner Installation...
- Page 12 Corner Installation 24 mm...
- Page 13 Corner Installation 17 mm SW mm Adjustment Thermostatic mixer please see page ...
-
Page 14: Thermostat Setting / Savety Function
Safety Function (-5) The desired maximum temperature for example max. 108 °F can be pre-set thanks to the safety function Thermostat Setting (-7) Set Quattrostat to "Hand shower". Open Quattrostat, adjust thermostat to 100 °F. Push thermostat grip on and align vertically (red button A points upwards), screw tight... -
Page 15: Trouble Shooting
8" (150 N) Fault water level is too low handshower delivering insufficient water temperature regulation not possible (only hot thermostatic cartridge defective or cold water) shower is dripping cartridge of Quattrostat stiff English Cause filter in angled hose connection is dirt filter of handshower dirty at new installation: connection hose exchanged install connection hose correct cartridge of Quattrostat defective... - Page 16 Exchanging lateral shower head...
-
Page 17: Spare Parts
29 x 2,5 25 x 2 23 x 2 Pos. Description head shower shower arm handshower handle for thermostat sleeve handle flange hose body shower escutcheon spray head cartridge on/off control thermostat cartridge sealing set shelf upper cover lower cover connetion hose 900 mm mounting kit handle with showerholder... -
Page 18: Cleaning Instruction
Cleaning Instruction Cleaning Recommendation for Hansgrohe Products Modern sanitary tapware, kitchen mixers and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and reclamations, it is necessary to consider certain criteria when cleaning. Cleaning Materials for Mixers and Showers Acids are necessary ingredients of cleaning materials for removing lime, however please pay attention to the following points when clea- ning mixers and showers:... -
Page 19: Warranty
Limited Lifetime Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. („Hansgrohe“). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 1996, and installed in either the United States or Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original consumer purchaser only. - Page 20 Hansgrohe · Postfach 1145 · D-77761 Schiltach · Telefon +49 (0) 78 36/51-1282 · Telefax +49 (0) 7836/511440 E-Mail: info@hansgrohe.com · Internet: www.hansgrohe.com...
