  • Page 1 TX-PR50VT60 TX-PR55VT60 TX-PR65VT60 e HELP English...

  • Page 2: Table Of Contents

    Watching my Home Screen • Information • How to use • Settings Basic • Satellite connection • Basic connection • Selecting channel • Information banner • Option Menu • Subtitle • Off Timer • Last view External equipment • External connection • Watching external input • Operating with TV’s remote control • HDMI features • Terminal information • Valid input signals For best picture • Viewing Mode...
  • Page 3 TV Guide • Using TV Guide • Timer Programming Teletext • Viewing Teletext • Teletext mode • Note • 3D Eyewear - Functions • 3D Eyewear - Registration • 3D Eyewear - Replacing battery • Viewing 3D • 3D Mode Selection • 3D Settings • Source image format Tuning and editing channels • Setting menu • Favourites Edit • Channel List...
  • Page 4 Timer Programming • Setting timer programming • Editing timer programming • Note Technical information • USB HDD Internet service Internet content • Information • Selecting internet content • Note Network connections • Internet connection • Note Network settings • Network Connection • Custom - Wireless • Custom - Wired • Network Status • VIERA remote Settings • Network Link Settings • Software Update • New Software Message...
  • Page 5 Network settings • Network Connection • Custom - Wireless • Custom - Wired • Custom - Wireless Access Point • Network Status • VIERA remote Settings • Network Link Settings • Software Update • New Software Message Photos • Selecting file • Viewing photo • Using slideshow Videos • Selecting file • Watching video • Video Setup • Audio output settings Music...
  • Page 6 • Selecting device / mode Photo mode • Selecting file • Viewing photo • Sorting photos • Multi Shot 3D • Using slideshow Video mode • Selecting file • Watching video • Video Setup • Audio output settings Recorded TV mode • Selecting content • Watching recorded TV • Grouping contents • Deleting content • Changing device • Chapter List • Audio output settings...
  • Page 7 Functions APPS List • Information • How to use • Settings Multi Window • Information • How to use • Note VIERA Link “HDAVI Control™” • Summary of VIERA Link • Preparations • Easy playback • Power on Link • Power off Link • Standby Power Save • Intelligent Auto Standby • VIERA Link Control • Speaker Selection • Note Child Lock...
  • Page 8 Updating the TV Software • Information • Auto update • Manual update Setting characters • Using numeric buttons Built-in Camera • Using built-in Camera Voice Control • Preparations • How to use Electronic Touch Pen • Information • Touch Pen Setup • Using Electronic Touch Pen Bluetooth devices • Bluetooth Setup Keyboard / Gamepad • Keyboard • Gamepad...
  • Page 9 • Intelligent Frame Creation • 24p Smooth Film • Advanced Settings • Option Settings • Screen Settings • 3D Settings • Lock Settings • Copy Adjustment • Reset to Defaults Sound • Mode • Basic settings • Volume settings • Voice Guidance Settings • Advanced settings • Reset to Defaults Network • Network Connection • Network Status • VIERA remote Settings • Network Link Settings • Other settings...
  • Page 10 • Touch Pen Setup • VIERA Touch Pad Controller • Bluetooth Setup • Child Lock • Tuning Menu • Language • Display Settings • Common Interface • VIERA Link Settings • Professional Mode (isfccc) • Data Service Application • System Menu • Other Settings Support FAQs • Picture • Digital TV • Analogue TV • Sound • 3D • HDMI • Network • Other...
  • Page 11 Licence • Licence Letters enclosed in a box indicate remote control buttons. Menu Letters in cyan indicate on-screen display items. References in this eHELP The images shown in this eHELP are for illustrative purposes only. ● - 11 -...

  • Page 12: My Home Screen

    Watching my Home Screen Information “my Home Screen” is a gateway to the TV, applications, and more. It provides easy access to special features such as the Media Player, videos, games, communication tools, etc. as shown below (example). HOME HOME Home Screen Selected content screen (TV, application, etc.) Home Screen Selection...

  • Page 13: How To Use

    How to use Home Screen provides access to special features such as the Media Player, TV, internet content, data services, communication tools, etc. 1. Display Home Screen with HOME (Example) The last viewed Home Screen is displayed when the TV is turned on. ●...

  • Page 14: Settings

    Settings Select the setup menu from the tool guide on the top of the screen, or use coloured button to display the setup menu. (Example) ■ Home Screen Selection 1. Display Home Screen Selection with HOME (Example) 2. Select the screen with and press to set Full Screen...
  • Page 15 ■ Settings You can customise any Home Screen. (For example, changing the wallpaper, renaming freely, editing applications, setting the screen launched when the TV is turned on, etc.) 1. Select Settings from the tool guide 2. Follow the on-screen instructions ■...

  • Page 16: Basic

    Basic Satellite connection Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. For DVB-S ● ■ Dual tuner (DiSEqC) Connect the both of satellite IN 1 / IN 2 terminals to the satellite dish with Multi Switcher, and you can watch or record 2 DVB-S programmes simultaneously, etc.
  • Page 17 ■ Single tuner Connect the satellite IN 1 terminal to the satellite dish. Watching or recording 2 DVB-S programmes simultaneously, etc. are not ● available. Satellite IN 1 terminal Satellite cable Satellite dish = Note = To ensure your satellite dish is correctly installed, please consult your local ●...

  • Page 18: Basic Connection

    Basic connection Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. ■ Aerial Terrestrial / cable terminal RF cable Terrestrial aerial or cable For DVB-C, DVB-T, Analogue ● ■ DVD Recorder / VCR Terrestrial / cable terminal RF cable DVD Recorder / VCR...
  • Page 19 ■ DVD Recorder / VCR and Set top box HDMI terminal HDMI cable Set top box Cable AV1 (SCART) terminal SCART cable – AV1 (SCART) adaptor (supplied) is necessary when connecting to the Terrestrial / cable terminal RF cable DVD Recorder / VCR Terrestrial aerial For VIERA Link connections ●...

  • Page 20: Selecting Channel

    Selecting channel 1. Display the TV Selection screen with 2. Select the mode with and press to set DVB-S DVB-C DVB-T Analogue The selectable modes vary depending on the channels stored. ● You can also select the mode pressing repeatedly on the remote ●...
  • Page 21 ■ To select a channel using TV Guide 1. Display TV Guide with GUIDE 2. Select the current programme or channel with and press to access 3. Select View with and press to access (DVB) – The current programme is displayed on the top left of the screen. 4.

  • Page 22: Information Banner

    Information banner Display information banner with Also appears when changing a channel. ● (Example) Channel position and name Channel type (Radio, HDTV, etc.) / encrypted channel ( ) / TV mode ( , Programme Programme start / finish time (except Analogue) Channel position, etc.
  • Page 23 Multiple audio available Multiple video available Multiple audio and video available Stereo, Mono: Audio mode Data service (Hybrid Broadcast Broadband TV application) available Functions Data Service Application Using Data Service Application – 90: Off Timer remaining time Watching Basic Off Timer To confirm another tuned channel ●...

  • Page 24: Option Menu

    Option Menu Confirm or change the current status. 1. Display Option Menu with OPTION 2. Select one of the following items with and press to access Voice Guidance Settings Multi Video Multi Audio Dual Audio Channel Subtitle Language Teletext Character Set Teletext Language Volume Correction CAM Selection...
  • Page 25 Subtitle Language Selects the language for subtitles (if available). For DVB mode ● Not valid on the sub screen in multi window mode ● Teletext Character Set Sets the teletext language font. Settings Setup Display Settings Teletext Language Selects between alternative languages for teletext (if available). For DVB mode ●...

  • Page 26: Subtitle

    Subtitle Display / hide subtitles (if available) with STTL. To select the preferred language for DVB subtitles (if available), set ● Preferred Subtitles. Settings Setup Language = Note = Subtitles may not be displayed properly in 3D images. ● If you press STTL in Analogue mode, the TV switches to teletext service ●...

  • Page 27: External Equipment

    External equipment External connection These diagrams show our recommendations for connection of your TV to various pieces of equipment. For other connections, consult the instructions for each piece of equipment. For basic connection ● Watching Basic Basic connection To use the specific devices supporting Bluetooth wireless technology ●...
  • Page 28 ■ AV devices AV2 (COMPONENT) terminals Component cables – AV2 (COMPONENT / VIDEO) adaptor (supplied) is necessary. DVD player AV2 (VIDEO) terminals Composite cables – AV2 (COMPONENT / VIDEO) adaptor (supplied) is necessary. Camcorder / Game equipment - 28 -...

  • Page 29: Usb Devices

    You cannot connect any devices by using USB card reader. ● Additional information for the devices may be on the following website. ● (English only) http://panasonic.net/viera/support ■ To listen with speakers DIGITAL AUDIO Optical digital audio cable Amplifier with speaker system To enjoy the sound from the external equipment in multi-channel sound ●...
  • Page 30 ■ Headphones Headphone jack M3 stereo mini plug Headphones To adjust volume, set Headphone Volume. ● Settings Sound Volume settings - 30 -...

  • Page 31: Watching External Input

    Watching external input Connect the external equipment (VCRs, DVD equipment, etc.) and you can watch through the input. 1. Display the input selection menu with 2. Select the input mode connected to the equipment with and press to watch (The selected mode is displayed on the top left of the screen) TV receives input signals automatically connecting with SCART when ●...

  • Page 32: Operating With Tv's Remote Control

    Operating with TV’s remote control You can operate the contents in Media Player / media server, recording functions or the connected equipment with the below buttons of this TV’s remote control. Playback videocassette / DVD / video content Stop the operations Rewind, view the picture rapidly in reverse (VCR) Skip to the previous track, title or chapter (DVD / video content) Rewind, view the picture rapidly in reverse (VCR)

  • Page 33: Hdmi Features

    ■ How to change the code Each Panasonic product has its own remote control code. Change the code according to the product for operation. 1. Press and hold Standby On / Off switch during the following operations 2. Enter the appropriate code as follows with numeric buttons Codes for each product and features ●...
  • Page 34 ■ Applicable HDMI features Input audio signal: ● 2ch Linear PCM (sampling frequencies - 48 kHz, 44.1 kHz, 32 kHz) Input video signal: ● Matches the output setting of the digital equipment. Watching External equipment Valid input signals VIERA Link (HDAVI Control 5) ●...

  • Page 35: Terminal Information

    Terminal information ■ AV1 SCART terminal (RGB, VIDEO) 1 : Audio out (R) 12: -- 2 : Audio in (R) 13: Red earth 3 : Audio out (L) 14: Earth 4 : Audio earth 15: Red in 5 : Blue earth 16: Status RGB 6 : Audio in (L) 17: CVBS earth...

  • Page 36: Valid Input Signals

    ■ HDMI terminal 1 : TMDS Data2+ 11 : TMDS Clock Shield 2 : TMDS Data2 Shield 12: TMDS Clock− 3 : TMDS Data2− 13: CEC 4 : TMDS Data1+ 14: Utility 5 : TMDS Data1 Shield 15: SCL 6 : TMDS Data1− 16: SDA 7 : TMDS Data0+ 17: DDC/CEC Ground...

  • Page 37: For Best Picture

    For best picture Viewing Mode 1. Display the menu with MENU 2. Select Picture Viewing Mode with and press to access 3. Select the mode with and press to set Viewing Mode (Dynamic Normal Cinema THX Cinema THX Bright Room Custom Professional1 / Professional2)

  • Page 38: Ambient Sensor

    In each Viewing Mode, Contrast, Brightness, Colour, Tint, Sharpness, Colour Temperature, Vivid Colour, Ambient Sensor, Noise Reduction, MPEG Remaster, Resolution Remaster, Caption Smoother, Brilliance Enhancer, Intelligent Frame Creation 24p Smooth Film can be adjusted and stored. When in Custom Professional1 / 2 mode, Advanced Settings can be...

  • Page 39: Aspect

    Aspect Change the aspect ratio (image size) with ASPECT. ■ To change the aspect ratio manually 1. Display Aspect Selection list with ASPECT 2. Select the mode with and press to set You can also change the mode pressing ASPECT. ●...
  • Page 40 = Note = Display the image (TV, external input, etc.) full-screen to use this function ● completely. Aspect mode can be memorised separately for SD (Standard definition) ● and HD (High definition) signals. Aspect cannot be changed in teletext service and 3D mode. ●...

  • Page 41: Aspect Control Signal

    Aspect Control Signal Programmes usually contain an “Aspect Control Signal” (Widescreen signal, Control signal through SCART / HDMI terminal). Auto mode, aspect mode will appear in the top left of the screen if a Widescreen signal (WSS) or a Control signal through SCART (pin8) / HDMI terminal is found.
  • Page 42 ● AV2 (COMPONENT) terminals (WSS only) Valid input signal format: 625 (576) / 50i, 50p Invalid input signal format: 525 (480) / 60i, 60p 750 (720) / 60p, 50p 1,125 (1,080) / 60i, 50i ● HDMI terminal Valid input signal format: 525 (480) / 60i, 60p 625 (576) / 50i, 50p 750 (720) / 60p, 50p...

  • Page 43: Advanced Settings

    Advanced Settings You can adjust and set up the detailed picture settings for each input when Viewing Mode is set to Custom Professional1 / 2 mode. Watching For best picture Viewing Mode 1. Select the input mode with 2. Display the menu with MENU 3.
  • Page 44 ■ Colour Gamut Colour Gamut (Native Rec. 709 SMPTE-C / EBU) Reproduces image colour precisely according to the colour gamut standards. Native: Displays deep colours by expanding the colour gamut to its maximum. Rec. 709: Standard for HD (High definition) SMPTE-C: Standard for NTSC EBU:...
  • Page 45 ■ Colour Management R-Hue R-Saturation R-Luminance Adjusts the picture hue / saturation / luminance of red areas. G-Hue G-Saturation G-Luminance Adjusts the picture hue / saturation / luminance of green areas. B-Hue B-Saturation B-Luminance Adjusts the picture hue / saturation / luminance of blue areas. More Detailed Adjustment Adjusts more detailed Colour Management items.
  • Page 46 ■ Gamma Gamma (2.6 Curve) Switches the gamma curve. Please note the numerical values are reference for the adjustment. ● More Detailed Adjustment Adjusts more detailed Gamma items. Input Signal Level: Adjusts the input signal level. Gain: Adjusts the gain of gamma for selected signal level. Reset to Defaults: Resets to the default detailed Gamma.

  • Page 47: Lock Settings

    Lock Settings Locks the settings of Professional1 / 2 mode for each input. 1. Display the menu with MENU 2. Select Picture Lock Settings with and press to access 3. Enter the PIN number (4 digits) with numeric buttons Enter the PIN number twice at first setting. ●...

  • Page 48: For Best Audio

    For best audio Sound mode 1. Display the menu with MENU 2. Select Sound Mode with and press to access 3. Select the mode with and press to set Mode (Standard Music Ambience / User) Selects your favourite sound mode for each input. Standard: Provides the suitable sound quality for all types of scenes.

  • Page 49: Tv Guide

    TV Guide Using TV Guide TV Guide - Electronic Programme Guide (EPG) provides an on-screen listing of the programmes currently broadcast and the forthcoming broadcasts over the next seven days (depending on the broadcasters). 1. Display the TV Selection screen with 2.
  • Page 50 To watch the programme ● 1) Select the current programme with and press access 2) Select View with and press to access (DVB) – To use timer programming, select Timer Programming. (Depending on the country you select, you can also set Signal Supported Recording.)

  • Page 51: Timer Programming

    Timer Programming The Timer Programming menu allows you to choose programmes that you want to remind watching or record to the USB HDD. At the correct time, the TV will tune to the correct channel even if the TV is in Standby mode. 1.

  • Page 52: Teletext

    Teletext Viewing Teletext 1. Switch to teletext with TEXT Displays the index page (content varies depending on the ● broadcasters). Current / sub page numbers are displayed on the top left of the screen. ● Time / date is displayed on the top right of the screen. ●...
  • Page 53 ■ Watch TV and teletext in two windows at once 1. Press MENU twice 2. Set Picture and text with Operations can be made only in teletext screen. ● ■ Store frequently viewed pages in the colour bar (List mode) 1.

  • Page 54: Teletext Mode

    Teletext mode Teletext services are the text information provided by the broadcasters. The features may vary depending on the broadcasters. ● 1. Display the menu with MENU 2. Select Setup Display Settings Teletext with and press access 3. Select TOP (FLOF) List with and press...

  • Page 55: Note

    Note Display the image (TV, external input, etc.) full-screen for viewing 3D. ● If light appears to flicker under fluorescents or dimmers when using the 3D ● Eyewear, change the setting of 3D Refresh Rate. Watching 3D Settings Do not exert pressure on or scratch the lens of the 3D Eyewear. ●...

  • Page 56: 3D Eyewear - Functions

    3D Eyewear - Functions ■ Part names and functions Power button / Mode change / Indicator lamp Power button ● – Press and hold for approx. 1 second to turn the 3D Eyewear On. (The indicator lamp lights for 2 seconds.) –...
  • Page 57 ■ Indicator lamp status Lights red for 2 seconds when turned on: ● Sufficient battery level Flashes 5 times when turned on: ● Low battery level Flashes red: ● Under registering Flashes red once every 1 second: ● Under reconnecting to the TV Flashes red 3 times: ●...

  • Page 58: 3D Eyewear - Registration

    3D Eyewear - Registration ■ First registration Perform the first registration when the 3D Eyewear is used for the first time. 1. Turn the TV on 2. Press Power button for about 1 second to turn the 3D Eyewear on The lamp lights for about 2 seconds and then flashes.

  • Page 59: 3D Eyewear - Replacing Battery

    3D Eyewear - Replacing battery When the battery is running low, the indicator lamp flashes 5 times on turning the 3D Eyewear on. In this case, early battery replacement is recommended. Dispose of the old batteries as non-burnable rubbish, or in line with the ●...

  • Page 60: Viewing 3D

    Viewing 3D You can enjoy viewing 3D images with contents or programmes corresponding to the 3D effect by wearing the 3D Eyewear. This TV supports Frame Sequential, Side by Side and Top and Bottom 3D ● formats. – Frame Sequential is the 3D format that the images for the left and right eyes are recorded with the high definition quality and alternately played back.

  • Page 61: 3D Mode Selection

    ■ 3D photos and 3D videos taken by 3D-compatible Panasonic products Available in Media Player and Network services ● Media Player Home network ■ 2D images converted to 3D Set to 2D 3D mode in 3D Mode Selection. ● Watching...
  • Page 62 Converts 2D images into 3D. Please note the 3D images appear slightly different from the originals. ● Using this function for profit-making purposes, or publically showing ● images converted from 2D to 3D in places such as shops or hotels etc.

  • Page 63: 3D Settings

    3D Settings 1. Display the menu with MENU 2. Select Picture 3D Settings with and press to access 3. Select one of the following items with and press to access 3D Detection 3D Signal Message 3D Refresh Rate 2D 3D Depth 3D Adjustment L/R Picture Swap Edge Smoother...
  • Page 64 3D Refresh Rate (Auto 100Hz / 120Hz) Reduces juddering and flicker noises of the 3D images when using the 3D Eyewear. 100Hz: If light appears to flicker under fluorescents (or dimmers) of 50 Hz. 120Hz: If light appears to flicker under fluorescents (or dimmers) of 60 Hz. 2D 3D Depth (Max / Min)
  • Page 65 Edge Smoother / Off) Set to if you feel the contoured parts of an image are not smooth enough (except in 2D 3D mode). Safety Precautions Displays the precautions for viewing 3D images. = Note = Display the image (TV, external input, etc.) full-screen to use this function ●...

  • Page 66: Source Image Format

    Source image format If the picture appears to be abnormal, refer to the table of images that can be seen for each 3D Mode Selection (Manual) and the source image format, and select the correct 3D mode. 3D images are displayed correctly with appropriate 3D format as following ●...

  • Page 67: Tuning And Editing Channels

    Tuning and editing channels Setting menu You can retune channels, create your favourite channel lists, skip unwanted channels, etc. 1. Display the TV Selection screen with 2. Select the mode with and press to set DVB-S DVB-C DVB-T Analogue 3. Display the menu with MENU 4.

  • Page 68: Favourites Edit

    Favourites Edit ■ List favourite DVB channels Create your favourite channel lists from various broadcasters (up to 4: Favourites 1 to 4). The DVB Favourites lists are available from Category in the information banner and the TV Guide screen. Watching Basic Information banner Watching...
  • Page 69 ■ Edit DVB Favourites list You can edit the favourites list while the cursor is on the channel in the favourites list. To move the channel ● 1) Select the channel with 2) Press (green) 3) Select the new position with or numeric buttons 4) Press (green) to store...

  • Page 70: Channel List

    Channel List ■ Skip unwanted DVB / Analogue channels You can hide (skip) unwanted channels. The hidden channels cannot be displayed except in this function. 1. Select Channel List with and press to access 2. Select a channel with 3. Press to set Reveal Hide...
  • Page 71 To rename the channel name (Analogue) ● 1) Press (blue) to edit 2) Enter characters (maximum 5 characters) with numeric buttons, and press to set 3) Press BACK/RETURN to store = Note = If a VCR is connected only with the RF cable in Analogue mode, edit VCR. ●...

  • Page 72: Auto Setup

    Auto Setup Automatically retunes the channels received in the area. This function is available if channel tuning is already performed. ● Only the selected mode is retuned. All the previous tuning settings are ● erased. If Child Lock PIN number has been set, the PIN number is required. ●...
  • Page 73 2) Set Satellite for the selected LNB – Select No Satellite if you do not know the connected satellite (available satellite will be searched in Auto Setup). – Select User defined to set Test Transponder Frequency manually. – If you set to Single Cable, additional settings are required.
  • Page 74 ■ DVB-C, DVB-T, Analogue channels 1. Select Auto Setup with and press to access 2. Set DVB-C Auto Setup Settings with and press to store (DVB-C) Scan Mode ● Full: Scans the whole frequency range. Quick: Scans the suitable frequency in your country. Normally set Frequency, Symbol Rate Network ID...

  • Page 75: Manual Tuning

    Manual Tuning Normally use Auto Setup Update Channel List to retune DVB channels. ● If tuning has not been done completely or for adjusting the direction of the ● aerial or dish, use this function. (DVB) All DVB channels found will be added to Channel List.

  • Page 76: Update Channel List

    ■ Analogue Set Analogue channel manually after Auto Setup. 1. Select the channel position with numeric buttons 2. Select the channel with Channel Up / Down button 3. Search with 4. Select Store with and press to set Fine Tuning to make small adjustments to the tuning of an individual ●...

  • Page 77: New Channel Message

    New Channel Message Selects whether to give a notification message when a new DVB channel is found or not. When a notification message appears, you can perform Update Channel ● List pressing OK. Signal Condition Selects a channel and checks the signal condition. A good Signal Strength is not an indication of suitable signal for DVB reception.

  • Page 78: Selectable Satellites

    Selectable satellites ■ Selectable satellites and dish alignment to tune DVB-S channels To ensure your satellite dish is correctly installed, please consult your local dealer. Also please consult the received satellite broadcasting companies for details. Intelsat at 85.2° East Hot Bird at 13° East ●...

  • Page 79: Recording

    Recording USB HDD setup Preparations You can record the digital TV programmes to the connected USB HDD and enjoy playing back in various ways. Prepare the USB HDD for the exclusive use of recording with this TV. ● Connect the USB HDD to the USB 3 port with the USB cable. ●...
  • Page 80 = Caution = All data in the USB HDD will be erased in the following cases: ● – When formatting the USB HDD with this TV Recording USB HDD setup Setting for USB HDD – When formatting the USB HDD to use on PC, etc. When the TV is repaired due to a malfunction, you may have to format ●...

  • Page 81: Setting For Usb Hdd

    Setting for USB HDD Format and set up the USB HDD with this TV in order to use it for recording. All the USB devices recognised as a mass storage device will be listed. Please note that USB HDD will be formatted and all data in it will be ●...
  • Page 82 To change the mode ● To edit USB HDD name ● (green) To format ● (red) To remove the USB HDD safely from the TV ● (yellow) = Note = You can only select one USB HDD for recording at a time. ●...

  • Page 83: One Touch Recording

    Recording current programme One Touch Recording Records the current programme to the USB HDD immediately. Confirm the remote control code is “73”. ● Watching External equipment Operating with TV’s remote control 1. Display the menu with MENU 2. Select Setup Recording Setup One Touch Recording with...

  • Page 84: Rew Live Tv

    REW LIVE TV Records the current programme to the USB HDD constantly within the maximum recordable time. Confirm the remote control code is “73”. ● Watching External equipment Operating with TV’s remote control 1. Display the menu with MENU 2. Select Setup Recording Setup REW LIVE TV...
  • Page 85 ■ To stop REW LIVE TV 1. Display the menu with MENU 2. Select Setup Recording Setup REW LIVE TV with and press to access 3. Select with to stop REW LIVE TV If you stop REW LIVE TV, the recorded content for REW LIVE TV will be ●...

  • Page 86: Timer Programming

    Timer Programming Setting timer programming The Timer Programming menu allows you to select programmes that you want to be reminded to watch or record to the USB HDD. Not valid in Analogue mode ● 1. Display the TV Selection screen with 2.
  • Page 87 (Example) !: Overlapped timer programming events Function (USB HDD Rec. / Reminder) TV mode S: DVB-S C: DVB-C D: DVB-T – You cannot change the mode within the menu. Channel position and name <TIMER>: Timer Programming STTL: Displays subtitles (if available) –...

  • Page 88: Editing Timer Programming

    Editing timer programming 1. Display the menu with MENU 2. Select Timer Timer Programming with and press to access 3. Select the event with To change a timer programming event ● – Correct as necessary. Recording Timer Programming Setting timer programming To delete a timer programming event ●...

  • Page 89: Note

    Note TV Guide may also be used to set timer programming event. ● Watching TV Guide Timer Programming Timer Programming can store up to 15 events. ● Timer Programming only works reliably if correct time information is ● received via the signal from the broadcaster or service provider. For recording using Timer Programming, the TV must be either on or in...

  • Page 90: Technical Information

    Regarding performance, not all USB HDDs are guaranteed. Check the ● USB HDDs that have been tested for compatibility with this TV at the following website. (English only) http://panasonic.net/viera/support = Note = Data modified with a PC may not be displayed. ●...

  • Page 91: Internet Service

    Internet service Internet content Information You can access some specific websites supported by Panasonic, and enjoy internet contents such as videos, games, communication tools, etc. from APPS List. (Example) To enable this function, you need a broadband network environment. ●...

  • Page 92: Selecting Internet Content

    Selecting internet content 1. Display APPS List with APPS For details of APPS List ● Functions APPS List Depending on the usage conditions, it may take a while to read all the ● data. 2. Select the desired item with and press to access (Example)

  • Page 93: Note

    The services through APPS List are operated by their respective service ● providers and such service may be discontinued either temporarily or permanently without notice. Therefore, Panasonic will make no warranty for the contents or the continuity of the services. Some contents may be inappropriate for some viewers.

  • Page 94: Network Connections

    Network connections Internet connection To use internet service, you need a broadband network environment. If you do not have any broadband network services, please consult your ● retailer for assistance. Dial-up internet connections cannot be used. ● Required speed (effective): at least 1.5 Mbps for SD (Standard Definition) ●...

  • Page 95: Note

    Note Ensure to use a LAN straight cable. ● Set up and connect equipment required for the network environment. You ● cannot make such settings on this TV. Read the manual of the equipment. If your modem has no broadband router functions, use a broadband router. ●...

  • Page 96: Network Settings

    Network settings Network Connection Ensure the connections are completed before starting network setup. Internet service Network connections ■ Quick setup - Wireless 1. Display the menu with MENU 2. Select Network Network Connection with and press to access Confirm the encryption key, settings and position of your access point ●...
  • Page 97 6. Automatically setup is done and the Network Status screen is displayed Internet service Network settings Network Status 7. Select Exit with and press to set To set manually ● Internet service Network settings Custom - Wireless ■ Quick setup - Wired 1.

  • Page 98: Custom - Wireless

    Custom - Wireless Ensure the connections are completed before starting network setup. Internet service Network connections 1. Display the menu with MENU 2. Select Network Network Connection Custom Wireless with and press to access Confirm the encryption key, settings and position of your access point ●...
  • Page 99 4. Enter the encryption key of the access point with and press to set You can set characters using numeric buttons. ● Press BACK/RETURN to store ● 5. The VIERA Name/IP/DNS Settings screen is displayed VIERA Name You can set your favourite name for this TV. ●...

  • Page 100: Custom - Wired

    Proxy Port: This number is also specified by the provider with the Proxy address. 1) Select Proxy Port with 2) Enter the number with numeric buttons 3) Press BACK/RETURN to store 6. Select Network Status with and press to access Internet service Network settings Network Status...
  • Page 101 Proxy Settings It is not required for normal household use. ● Some internet services may not be available depending on the proxy ● settings. Proxy: This is the address of the relay server connected between the browser and the target server and sends data to the browser. 1) Select Proxy with...

  • Page 102: Network Status

    Network Status Displays and checks the network status (MAC Address, current network settings, etc.). 1. Display the menu with MENU 2. Select Network Network Status with and press to access 3. Automatically testing is done and the Network Status screen is displayed Again: Performs automatic testing of the network connection for the TV and displays the current status again.

  • Page 103: Home Network

    Home network DLNA Information This TV is a DLNA Certified™ product. DLNA (Digital Living Network Alliance) is a standard that makes DLNA ® Certified digital electronics easier and more convenient to use on a home network. To learn more, visit www.dlna.org. To enable this function, connect this TV to your home network.
  • Page 104 ● To use a PC as a media server Prepare the PC with Windows 7 / Windows 8 or ensure the server software is installed on the PC. “Windows 7 / Windows 8” and “Twonky 7 (installed on the PC with Windows XP or Mac)” are the server software that has been tested for compatibility with this TV (as of November, 2012).
  • Page 105 And you need to install the application for controlling VIERA on your smartphone. For information of the application (English only): http://panasonic.net/viera/support For the operations, refer to the support information of the application. “Windows 7 / Windows 8” are the OS that have been tested for ●...
  • Page 106 Sharing the current programme may not be available when selecting radio ● channels, encrypted (copy-protected) programmes or when the broadcast prohibits the output of video and audio. = Note = To use this function, turn this TV on. ● This function is available only with 1 piece of other equipment. ●...

  • Page 107: Using Dlna

    Using DLNA To use DLNA features, ensure the preparations of the media server, network ® connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press...

  • Page 108: Network Connections

    Network connections DLNA connection To use DLNA features, you need a home network environment and you can operate the features without a broadband network environment. To use internet service, you need a broadband network environment. ● Internet service Network connections Internet connection ■...
  • Page 109 ■ Wired connection (For DLNA and internet service) ETHERNET terminal LAN cable (Unshielded) Use the Unshielded Twist Pair (UTP) LAN cable. ● Hub or Router Internet environment DLNA Certified media server ■ Wireless connection (For DLNA) To use the TV as a wireless access point ●...

  • Page 110: Note

    Note Ensure to use a LAN straight cable. ● Set up and connect equipment required for the network environment. You ● cannot make such settings on this TV. Read the manual of the equipment. If you use the equipment compatible only with 100BASE-TX, category 5 or ●...

  • Page 111: Network Settings

    Network settings Network Connection Ensure the connections are completed before starting network setup. Home network Network connections ■ Quick setup - Wireless 1. Display the menu with MENU 2. Select Network Network Connection with and press to access Confirm the encryption key, settings and position of your access point ●...
  • Page 112 7. Select Exit with and press to set To set manually ● Home network Network settings Custom - Wireless ■ Quick setup - Wired 1. Display the menu with MENU 2. Select Network Network Connection with and press to access 3.

  • Page 113: Custom - Wireless

    Custom - Wireless Ensure the connections are completed before starting network setup. Home network Network connections 1. Display the menu with MENU 2. Select Network Network Connection Custom Wireless with and press to access Confirm the encryption key, settings and position of your access point ●...
  • Page 114 4. Enter the encryption key of the access point with and press to set You can set characters using numeric buttons. ● Press BACK/RETURN to store ● 5. The VIERA Name/IP/DNS Settings screen is displayed VIERA Name You can set your favourite name for this TV. ●...

  • Page 115: Custom - Wired

    Proxy Port: This number is also specified by the provider with the Proxy address. 1) Select Proxy Port with 2) Enter the number with numeric buttons 3) Press BACK/RETURN to store 6. Select Network Status with and press to access Home network Network settings Network Status...
  • Page 116 Proxy Settings It is not required for normal household use. ● Some internet services may not be available depending on the proxy ● settings. Proxy: This is the address of the relay server connected between the browser and the target server and sends data to the browser. 1) Select Proxy with...

  • Page 117: Custom - Wireless Access Point

    Custom - Wireless Access Point You can use the TV as a wireless access point and connect the network equipment without an access point. Confirm the PIN code, network settings of the equipment before starting ● setup. For details, read the manual of the equipment. 1.

  • Page 118: Network Status

    For the operations, refer to the support information of the application. Device to upload contents Selects device to upload contents from the network equipment (smartphone, etc.). = Note = Depending on the area, this function may not be available. For details, ● consult your local Panasonic dealer. - 118 -...

  • Page 119: Network Link Settings

    To use this function with your smartphone, you need to install the ● application for controlling VIERA on your smartphone. For information of the application (English only): http://panasonic.net/viera/support For the operations, refer to the support information of the application. Registration Type (Auto...

  • Page 120: Software Update

    = Note = Depending on the area, this function may not be available. For details, ● consult your local Panasonic dealer. Software Update Accesses the specific website to update the TV’s software if any updates are available. 1. Display the menu with MENU 2.

  • Page 121: Selecting File

    Photos Selecting file Ensure the preparations of the media server, network connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press to access 3.

  • Page 122: Viewing Photo

    Viewing photo ■ Playback Photos are displayed one at a time. To operate Single view ● : To the previous photo : To the next photo : Stop (return to list) : Slideshow To display / hide the operation guide ●...
  • Page 123 Transition Effect (Off Fade Dissolve Motion / Random) Selects the transition effect for switching the photo during the slideshow. Fade: The next photo fades in gradually. Dissolve: Each photo is dissolved when switching to the next photo. Motion: Each photo is displayed with an effect of enlarging, reducing, moving up or moving down.

  • Page 124: Selecting File

    Videos Selecting file Ensure the preparations of the media server, network connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press to access 3.

  • Page 125: Watching Video

    Watching video ■ Playback If you have stopped the last playback halfway, the confirmation screen is displayed to select whether to start from where you stopped last time or from the beginning. To operate playback ● Manual skip – Press to skip forward approx. 30 seconds. : Rewind : Fast forward : Stop...

  • Page 126: Video Setup

    Video Setup Set up the settings for video file operations on this TV. 1. Display the option menu with OPTION 2. Select Video Setup with and press to access 3. Select one of the following items with and press to access Video Preview Multi Audio Dual Audio...

  • Page 127: Audio Output Settings

    Audio output settings You can enjoy the multi-channel sound via an amplifier connected to DIGITAL AUDIO or HDMI2 (ARC function) terminal. To confirm or change the current sound status ● Home network Videos Video Setup 1. Display the menu with MENU 2.

  • Page 128: Music

    Music Selecting file Ensure the preparations of the media server, network connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press to access 3.

  • Page 129: Playing Music

    Playing music ■ Playback To operate playback ● : Rewind : Fast forward : Stop : Pause / Playback To display / hide the operation guide ● To the previous track ● (red) To the next track ● (green) To return to list ●...

  • Page 130: Diga Recorder

    DIGA Recorder Controlling DIGA Recorder Ensure the preparations of the media server, network connections and network settings are completed. Home network DLNA Information Home network Network connections Home network Network settings 1. Display APPS List with APPS 2. Select Media Server with and press to access...

  • Page 131: Technical Information

    Technical information Photo format ■ Supported Photo formats ● JPEG (.jpg, .jpeg, .mpo) Image resolution (pixel): 8 × 8 to 30,719 × 17,279 Sub-sampling: 4:4:4, 4:2:2, 4:2:0 DCF and EXIF standards ● Progressive JPEG is not supported. ● = Note = Some files may not be played back even if they fulfil these conditions.
  • Page 132 ● SD-Video (.mod) Video codec: MPEG1, MPEG2 Audio codec: Dolby Digital, MPEG Audio SD-Video Standard Ver. 1.31 (Entertainment Video Profile) ● The data may not be available if a folder structure on the device is ● modified. ● AVI (.avi) Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, MPEG4 SP/ASP, VC-1, Windows Media Video Ver.
  • Page 133 Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, MPEG4 SP/ASP Audio codec: AAC, Dolby Digital, Dolby Digital Plus, HE-AAC, MPEG Audio, MP3 This TV supports this container recorded with Panasonic products. For ● details, read the manual of the products. ● FLV (.flv) Video codec: H.264 BP/MP/HP...

  • Page 134: Music Format

    ■ Supported Subtitles formats ● MicroDVD, SubRip, TMPlayer (.srt, .sub, .txt) The video file and subtitles text file are inside the same folder, and the file ● names are the same except for the file extensions. If there are more than one subtitles text files inside the same folder, they ●...

  • Page 135: Media Player

    Media Player Using Media Player Information Media Player allows you to enjoy photo, video or music recorded on an SD Card and a USB Flash Memory with this TV, and contents recorded with this TV to the formatted USB HDD. (Example) Photo mode: Still pictures recorded with digital cameras will be displayed.
  • Page 136 Picture setting may not work depending on the conditions. ● Folder and file names may be different from those on the digital camera or ● digital video camera used. ■ To insert or remove the SD Card Gently insert the SD Card with the label surface facing front. Push the centre of the card until a click is heard.

  • Page 137: Selecting Device / Mode

    Selecting device / mode 1. Insert the SD Card or USB Flash Memory to the TV When you insert the SD Card, Media Player will start automatically. ● Media Player Using Media Player Information To play back contents in the USB HDD, ensure the connection and ●...
  • Page 138 = Note = You may also access each mode directly from APPS List. ● Functions APPS List How to use Recorded TV is available for contents recorded on the USB HDD with this ● Select the appropriate device and content for playing back each file. ●...

  • Page 139: Photo Mode

    Photo mode Selecting file Select the file in the thumbnail view with and press to start playback. : Error display To change the size of photos in the thumbnail view ● 1) Display the option menu with OPTION 2) Select Change Size with and press...

  • Page 140: Viewing Photo

    Viewing photo ■ Playback To operate Single view ● : To the previous photo : To the next photo : Stop (return to thumbnail) : Slideshow To display / hide the operation guide ● To rotate 90° ● (blue) To return to thumbnail ●...

  • Page 141: Multi Shot 3D

    Multi Shot 3D This TV can create a 3D photo using a pair of photos in the SD Card and save it into the same SD Card. This TV can also create a 3D photo from photos in the USB Flash Memory, ●...

  • Page 142: Using Slideshow

    Using slideshow Slideshow ends when all photos within the current thumbnail are viewed. 1. Select the file from the thumbnail of photos for the first view with 2. Start Slideshow with (red) and To display / hide the operation guide ●...
  • Page 143 Gallery (+ calendar) / Gallery: Various sizes of photos in the frames are displayed. You can select whether to display the calendar or not. The month of ● calendar is changed with Cinema: Photos are displayed as old films (sepia tone). Colour Effect (Off Sepia...
  • Page 144 Screen Mode (Normal / Zoom) Selects enlarged or normal viewing in Single view and Slideshow. Not valid when Frame is set to Collage, Drift, Gallery, Cinema or when ● Transition Effect is set to Motion Depending on the photo size, the photo may not be fully enlarged to fill the ●...
  • Page 145 Back Ground Music (Off Type1 Type2 Type3 Type4 Type5 User / Auto) Selects the background music during Photo mode. Type1 - Music files installed on this TV at the factory settings will be played back. Auto: Music files stored in the root folder of the current device will be played back randomly.

  • Page 146: Video Mode

    Video mode Selecting file 1. Select the title in the thumbnail view with : Error display : The file does not support thumbnail view. The preview will start when the title / scene is highlighted in the ● thumbnail view if it supports a preview. To turn off the preview, set Video Preview to Off.

  • Page 147: Watching Video

    Watching video ■ Playback from the selected scene in the title (SD-Video or AVCHD) Playback of the selected scene will start and continue until the end of the title. 1. Select the title with and press to access 2. Select the scene with 3.
  • Page 148 To change aspect ● 1) Display Aspect Selection list with ASPECT 2) Select the mode with and press to set Aspect1: Displays the content enlarged without distortion. Aspect2: Displays the content full-screen. Original: Displays the content original size. – You can also change the mode pressing ASPECT. (Press repeatedly until you reach the desired mode.) –...

  • Page 149: Video Setup

    Video Setup Set up the settings for Video mode. 1. Display the option menu with OPTION 2. Select Video Setup with 3. Select one of the following items with and press to access Video Preview Multi Audio Dual Mono Audio Subtitle Subtitle Text Repeat...

  • Page 150: Audio Output Settings

    Audio output settings You can enjoy the multi-channel sound via an amplifier connected to DIGITAL AUDIO or HDMI2 (ARC function) terminal. To confirm or change the current sound status ● Media Player Video mode Video Setup 1. Display the menu with MENU 2.

  • Page 151: Recorded Tv Mode

    Recorded TV mode Selecting content For exclusive USB HDD ● To play back contents in the USB HDD, ensure the connection and ● settings are completed. Recording USB HDD setup 1. Contents list of the selected device is displayed in Recorded TV mode Remaining capacity of the selected device is displayed on the top right.

  • Page 152: Watching Recorded Tv

    Watching recorded TV ■ Playback To operate playback ● Manual skip – Press to skip forward approx. 30 seconds. – Press and hold to skip backward approx. 15 seconds. : Rewind : Fast forward : Stop : Pause (displays the time seek bar) / Playback To jump to the specified time point ●...

  • Page 153: Grouping Contents

    To confirm or change the current status (if available) ● Watching Basic Option Menu To return to list ● BACK/RETURN The recorded content may not be played back properly while 2 recordings ● are in progress. Grouping contents 1. Select the content to edit with and press (blue) to tick in the contents list...

  • Page 154: Deleting Content

    Deleting content 1. Select the content to edit with and press (blue) to tick in the contents list 2. Delete the content with (red) 3. When the confirmation screen is displayed, select with press to set Changing device You can change the current device to another device directly in the same mode when two or more available devices are connected.

  • Page 155: Audio Output Settings

    Audio output settings You can enjoy the multi-channel sound via an amplifier connected to DIGITAL AUDIO or HDMI2 (ARC function) terminal. To confirm or change the current sound status ● Media Player Video mode Video Setup 1. Display the menu with MENU 2.

  • Page 156: Music Mode

    Music mode Selecting file 1. Select the folder in the thumbnail view with 2. Start playback with (red) For supported file formats ● Media Player Technical information Music format ■ Thumbnail view To display / hide information of the highlighted content ●...

  • Page 157: Playing Music

    Playing music ■ Playback of the selected file in the folder 1. Select the folder with and press to access 2. Select the file with 3. Start playback with (red) ■ Playback To operate playback ● : Rewind : Fast forward : Stop : Pause / Playback To display / hide the operation guide...

  • Page 158: Music Setup

    Music Setup Set up the setting for Music mode. This function is available in the thumbnail view. ● 1. Display the option menu with OPTION 2. Select Music Setup Repeat with 3. Select Folder with and press to set Folder: Playback repeat within the selected folder One: Playback repeat of the selected one file...

  • Page 159: Technical Information

    Back up the recorded data at regular intervals to prevent data ● deterioration, data damage or erratic operation of the TV. Panasonic is not liable for any deterioration or damage of recorded data. SD Card ■...

  • Page 160: Usb Devices

    You cannot connect any devices using a USB card reader. ● Additional information for the devices may be found on the following ● website. (English only) http://panasonic.net/viera/support ■ USB Flash Memory (for playing back in Media Player) USB Flash Memory format: FAT16, FAT32 or exFAT USB HDDs formatted on a PC are not guaranteed to work in Media Player.

  • Page 161: Photo Format

    Photo format ■ Supported Photo formats ● JPEG (.jpg, .jpeg, .mpo) Image resolution (pixel): 8 × 8 to 30,719 × 17,279 Sub-sampling: 4:4:4, 4:2:2, 4:2:0 DCF and EXIF standards ● Progressive JPEG is not supported. ● = Note = Some files may not be played back even if they fulfil these conditions. ●...

  • Page 162: Video Format

    Video format ■ Supported Video formats ● AVCHD (.mts) Video codec: H.264 BP/MP/HP Audio codec: Dolby Digital AVCHD Standard Ver. 2.0 (AVCHD 3D, AVCHD Progressive) ● The data may not be available if a folder structure on the device is ●...
  • Page 163 Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, MPEG4 SP/ASP Audio codec: AAC, Dolby Digital, Dolby Digital Plus, HE-AAC, MPEG Audio, MP3 This TV supports this container recorded with Panasonic products. For ● details, read the manual of the products. ● FLV (.flv) Video codec: H.264 BP/MP/HP...
  • Page 164 ● PS (.mod, .mpg, .mpeg, .vob, .vro) Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, VC-1 Audio codec: AAC, Dolby Digital, Dolby Digital Plus, HE-AAC, LPCM, MPEG Audio, ● TS (.mts, .m2ts, .tp, .trp, .ts, .tts) Video codec: H.264 BP/MP/HP, MPEG1, MPEG2, VC-1 Audio codec: AAC, Dolby Digital, Dolby Digital Plus, DTS core, HE-AAC, MPEG Audio, MP3...

  • Page 165: Music Format

    Music format ■ Supported Music formats ● MP3 (.mp3) ● AAC, Apple Lossless (.m4a) Copy-protected files cannot be played back. ● ● WMA / WMA Pro (.wma) Copy-protected files cannot be played back. ● ● LPCM (.wav) ● FLAC (.flac) = Note = Some files may not be played back even if they fulfil these conditions.

  • Page 166: Information

    Functions APPS List Information Various applications (internet contents, network contents, Media Player, etc.) can be accessed easily from APPS List. ■ APPS List (Example) = Note = APPS List is subject to change without notice. ● - 166 -...
  • Page 167 How to use You can access special features such as internet contents, network contents, Media Player, etc. from APPS List. 1. Display APPS List with APPS (Example) To exit APPS List ● EXIT 2. Select an icon of the features with and press to access Internet contents...

  • Page 168: Information

    Multi Window Information Displays two windows at once for viewing the TV programmes or external input (AV, Component or HDMI) as shown below (example). (green) Zapping View Watching View Zapping View Zapping View To swap windows ● To exit multi window ●...
  • Page 169 How to use You can select a channel while watching another programme or external input. 1. Display the menu with MENU 2. Select Picture Screen Settings Multi Window with and press to access You can also access the multi window mode by selecting Multi Window ●...
  • Page 170 ■ Watching View (Example) Main screen TV mode / input mode / channel position and name Sub screen Press to select the screen to operate. ● – displays on the screen. To select the sound ● 1) Display Option Menu with OPTION 2) Select...

  • Page 171: Note

    Note Ensure that Dual Tuner Mode is set to Auto Setup to display DVB-S ● mode both in two windows. Watching Tuning and editing channels Auto Setup Analogue channel cannot be displayed both in two windows. ● Data services are not available in the multi window mode. ●...

  • Page 172: Summary Of Viera Link

    VIERA Link “HDAVI Control™” Summary of VIERA Link Enjoy additional HDMI Inter-Operability with Panasonic products which have “HDAVI Control™” function. VIERA Link (HDAVI Control) connects the TV and the equipment with VIERA Link function, and enables easy control, playback, energy saving, creating home theatre, etc., without complicated settings.
  • Page 173 ● Connect the equipment supporting VIERA Link to the TV’s HDMI terminal ● via an HDMI cable. About HDMI cable for connecting Panasonic HD Video Camera or LUMIX Camera, read the manual of the equipment. HDMI terminal HDMI cable Equipment with VIERA Link function (DIGA Recorder / DVD Player / Blu- ray Disc Player / HD Video Camera / LUMIX Camera) ■...
  • Page 174 ■ VIERA Link (HDMI and Audio out connections) Use a fully wired HDMI compliant cable. ● Connect the equipment supporting VIERA Link to the TV’s HDMI terminal ● via an HDMI cable. Use a fully wired SCART cable. ● Use the optical digital audio cable or SCART cable for audio output from ●...
  • Page 175 : If the connected equipment has “HDAVI Control 5” function, you do not have to use this audio cable (Optical digital audio cable or SCART cable). In this case, connect the equipment to the TV’s HDMI2 terminal via an HDMI cable. ■...

  • Page 176: Easy Playback

    ■ VIERA Link Control of compatible equipment The following is the maximum number of compatible equipment that can be controlled by VIERA Link Control. This includes connections to equipment already connected to the TV. For example, DIGA Recorder connected to Amplifier which is connected to the TV via an HDMI cable.

  • Page 177: Power On Link

    Power on Link Power on Link in the Setup Menu to use this function. Settings Setup VIERA Link Settings When the connected equipment starts playback or direct navigator / function menu for the equipment is activated, the TV is automatically turned on. (Only when the TV is in Standby mode.) Power off Link Power off Link...

  • Page 178: Viera Link Control

    VIERA Link Control You can control some functions of the connected equipment with this TV’s remote control by pointing at the TV’s signal receiver. 1. Display APPS List with APPS 2. Select VIERA Link with and press to access 3. Select VIERA Link Control with and press...

  • Page 179: Speaker Selection

    = Note = If you cannot operate the equipment, check the settings and the ● equipment. Functions VIERA Link “HDAVI Control™” Summary of VIERA Link Some operations may not be available depending on the equipment. In ● this case, use the remote control of the connected equipment. For details of the operations for the connected equipment, read the ●...

  • Page 180: Note

    ■ Multi-channel sound If you want to enjoy the multi-channel sound (e.g. Dolby Digital 5.1ch) via an Amplifier, connect it with an HDMI cable and Optical digital audio cable, and then select Home Cinema. If your Amplifier has the “HDAVI Control 5” function, you only need to connect it with an HDMI cable to the TV’s HDMI2 terminal.

  • Page 181: Using Child Lock

    Child Lock Using Child Lock You can lock specific channels / AV input terminals to restrict access to them. When the locked channel / input is selected, a message appears. Enter the PIN number to watch. 1. Display the menu with MENU 2.

  • Page 182: Pin Number

    PIN number You can change the PIN number. 1. Select Change PIN with and press to access 2. Enter a new PIN number twice with the numeric buttons = Note = Setting Shipping Condition erases the PIN number and all settings. ●...

  • Page 183: Using Data Service Application

    Data Service Application Using Data Service Application You can enjoy Hybrid Broadcast Broadband TV application that is one of the interactive data services for digital broadcasting. 1. Display the TV Selection screen with 2. Select the mode with and press to set DVB-S DVB-C...

  • Page 184: Note

    Note To use Hybrid Broadcast Broadband TV application fully, you need a ● broadband network environment. Ensure the network connections and network settings are completed. Internet service Network connections Internet service Network settings Not all the data services are available depending on the country, area and ●...

  • Page 185: Caution

    Common Interface Caution Turn the TV off with Mains power On / Off switch whenever inserting or ● removing the Common Interface (CI) Module. If a view card and a card reader come as a set, first insert the card reader, ●...
  • Page 186 ■ Insert the CI module (optional) The features that appear on screen are dependent on the contents of the ● selected CI module. Normally encrypted channels will appear. Follow the on-screen ● instructions. If encrypted channels do not appear, take the following steps. For more details, read the manual of the CI module, or check with the ●...

  • Page 187: Shipping Condition

    Shipping Condition Shipping Condition Resets the TV to its original condition (i.e. no channels tuned in). All settings other than USB Device Setup are reset (channels, picture, sound settings, etc.). 1. Display the menu with MENU 2. Select Setup System Menu Shipping Condition with and press...

  • Page 188: Information

    Updating the TV Software Information A new version of software may be released for download to enhance the performance or operations of the TV. If there is an update available and the channel has the update information, a notification message is displayed. To install new software, select Standby with...

  • Page 189: Manual Update

    = Note = Download may take a few hours. ● During software download and update, DO NOT switch off the TV. ● A notification message may be a reminder. In this case, schedule ● information (the date when the new version can be used) will appear. You can set the reservation for update.

  • Page 190: Setting Characters

    Setting characters Using numeric buttons You can enter characters for free input items using numeric buttons. Press the numeric button repeatedly until you reach the desired character. : . @ / 1 ! : # + - * _ ( ) “ ‘ % & ? , ; = $ [ ] ~ < > { } | ` ^ \ : a b c 2 A B C : d e f 3 D E F : g h i 4 G H I...

  • Page 191: Built-In Camera

    Built-in Camera Using built-in Camera You can use the built-in Camera as a communication tool for specific applications such as face recognition, video message, etc. Watching my Home Screen Settings ■ Auto pop-up When the application for camera operation is activated, the built-in Camera automatically pops up.

  • Page 192: Voice Control

    Voice Control Preparations Voice Control function allows you to operate the TV (e.g. selecting a channel), search the content from various features, etc. with your speech. To use this function fully, you need a broadband network environment. ● Ensure the network connections and network settings are completed. Internet service Network connections Internet service...

  • Page 193: How To Use

    = Note = To use Voice Control function fully, you need a broadband network ● environment, because this function accesses the speech recognition server with the internet connection. Even if you have the internet environment, this function may not be available depending on the proxy settings.

  • Page 194: Electronic Touch Pen

    Electronic Touch Pen Information This function allows you to paint or play games on the TV screen using Electronic Touch Pen (hereafter referred to as “Touch Pen”). Touch Pen is not included. Please purchase as necessary. ● Support Optional accessories Electronic Touch Pen The Touch Pen is available only for specific applications.

  • Page 195: Using Electronic Touch Pen

    Using Electronic Touch Pen ■ How to paint on the photo / video 1. Press Power button to turn on the Touch Pen 2. Display the following images full-screen – DVB mode – HDMI input – Photo / video contents of Media Player / Network services 3.

  • Page 196: Bluetooth Devices

    Bluetooth devices Bluetooth Setup You can use Bluetooth keyboards and Bluetooth audio devices (headphones, etc.) with this TV by setting Bluetooth Setup in the Setup Menu. Settings Setup Bluetooth Setup : HID (Human Interface Device Profile) compliant keyboards can be used. : A2DP (Advanced Audio Distribution Profile) compliant audio devices can be used.
  • Page 197 This setup has not been designed for the 3D Eyewear, VIERA Touch ● Pad Controller and Electronic Touch Pen supporting Bluetooth wireless technology. Additional information for the devices may be found on the following ● website. (English only) http://panasonic.net/viera/support - 197 -...

  • Page 198: Keyboard / Gamepad

    Keyboard / Gamepad Keyboard Keyboards requiring the drivers are not supported. ● To change the language type, set Keyboard Layout. ● Settings Setup System Menu Characters may not be displayed correctly on the TV screen depending on ● the connected keyboard or the keyboard layout setting. Some of the keys of keyboards may correspond to the operation of the ●...

  • Page 199: Gamepad

    Gamepad Check the gamepads that have been tested for compatibility with this TV ● at the following website. (English only) http://panasonic.net/viera/support Some of the keys of gamepads correspond to the operation of the remote ● control. Volume Up / Down...

  • Page 200: Setting Menu

    Settings Setting menu How to use Various menus allow you to make settings for the picture, sound, and other functions. 1. Display the menu with MENU Displayed items vary depending on the input signal. ● 2. Select the menu with and press to access 3.
  • Page 201 To exit the menu screen ● EXIT To return to the previous screen ● BACK/RETURN To change menu pages ● = Note = A different menu will be displayed in the mode of Media Player or Network ● services. Media Player Using Media Player Home network DLNA...

  • Page 202: Viewing Mode

    Picture Viewing Mode Selects your favourite picture mode for each input. (Dynamic Normal Cinema THX Cinema THX Bright Room Custom Professional1 / Professional2) Dynamic: Improves contrast and sharpness for viewing in a bright room. Normal: Normal use for viewing in a normal lighting condition. Cinema: Improves the performance of contrast, black and colour reproduction for watching movies in a darkened room.
  • Page 203 In each Viewing Mode, Contrast, Brightness, Colour, Tint, Sharpness, Colour Temperature, Vivid Colour, Ambient Sensor, Noise Reduction, MPEG Remaster, Resolution Remaster, Caption Smoother, Brilliance Enhancer, Intelligent Frame Creation 24p Smooth Film can be adjusted and stored. When in Custom Professional1 / 2 mode, Advanced Settings can be...

  • Page 204: Basic Settings

    Basic settings Contrast, Brightness, Colour, Tint, Sharpness Adjusts the levels of these options according to your personal preference. Colour Temperature (Cool Normal / Warm) Sets the overall colour tone of the picture (bluer - redder). Vivid Colour / Off) Automatically adjusts colours to vivid ones. Colour Remaster (Auto / Off)

  • Page 205: Noise Reduction Settings

    Noise reduction settings Noise Reduction (Auto / Off) Reduces unwanted picture noise. MPEG Remaster (Auto / Off) Reduces flicker noise in contoured parts of a picture and block noise. Resolution Remaster Enhances picture resolution to make the image sharper. (Max / Off) Caption Smoother Makes caption contours smooth.

  • Page 206: P Smooth Film

    24p Smooth Film Automatically compensates the picture frame rate to make the 24p source movie images smooth. (Max / Off) This function is available only for 24p signal input and displayed instead of ● Intelligent Frame Creation. Not valid in multi window mode or when Game Mode is set to ●...
  • Page 207 HDMI Content Type (Graphics Photos Auto / Off) Adjusts the picture settings of each HDMI input according to the selected content type. Auto: Automatically adjusts the picture settings according to the received HDMI content if the connected equipment supports HDMI Content Type.

  • Page 208: Screen Settings

    Screen Settings 16:9 Overscan / Off) Selects the screen area displaying the image for 16:9 aspect. Enlarges the image to hide the edge of the image. Off: Displays the image in the original size. Set to if noise occurs on the edge of the screen. ●...
  • Page 209 Side Panel (High / Off) Adjusts the brightness of the side panel. The recommended setting is High to prevent panel “image retention”. ● Pixel Orbiter / Auto) Selects the mode for wobbling of the image to prevent panel “image retention”. Auto: Automatically works only for the appropriate images and you rarely recognise the wobbling.

  • Page 210: D Settings

    3D Settings 3D Detection (On (Advance) / Off) Selects whether to switch to the 3D mode automatically or not. (Advance): Detects all the 3D format signals and displays the 3D image automatically. Detects the particular 3D format signals (Frame Sequential, etc.) and displays the 3D image automatically.
  • Page 211 3D Adjustment / Off) Adjustment of the 3D effect (except in 2D 3D mode). Set to to enable Effect setting. When setting to On, a safety precaution message will appear. Read it ● carefully and press BACK/RETURN to go to Effect setting.

  • Page 212: Copy Adjustment

    Lock Settings Locks the settings of Professional1 / 2 mode for each input. Watching For best picture Lock Settings Copy Adjustment Copies the selected Custom, Professional1 Professional2 settings to those of the other input. Watching For best picture Copy Adjustment Reset to Defaults Resets the current Picture Viewing Mode to the default settings.

  • Page 213: Mode

    Sound Mode Selects your favourite sound mode for each input. (Standard Music Ambience / User) Standard: Provides the suitable sound quality for all types of scenes. Music: Improves sound quality for watching music videos, etc. Ambience: Improves spatial effects and provides clear sounds. User: Adjusts the sounds manually using the equaliser to suit your favourite sound quality.

  • Page 214: Basic Settings

    Basic settings Bass Adjusts level to enhance or minimise lower, deeper sound output. Treble Adjusts level to enhance or minimise sharper, higher sound output. Equaliser Adjusts the frequency level to suit your favourite sound quality. This function is available when Mode is set to User.

  • Page 215: Volume Settings

    Digital Remaster / Off) Compensates a compressed audio signal to reproduce the original sound quality. This function is effective only for the sound from TV speakers. ● Volume settings Headphone Volume Adjusts the volume of headphones. Auto Gain Control / Off) Automatically regulates large sound level differences between channels and inputs.

  • Page 216: Voice Guidance Settings

    Voice Guidance Settings Voice Guidance / Off) Set to to enable voice guidance of the basic features (menu item, on- screen messages, etc.) for visually impaired users. Speed (Fast Normal / Slow) Selects the readout speed for the voice guidance. Volume (Max / Min)

  • Page 217: Advanced Settings

    Advanced settings Selects multiplex sound mode (if available). Stereo: Use this normally. Mono: When stereo signal cannot be received / M2: Available while mono signal is transmitted. For Analogue mode ● Audio Preference (Auto / MPEG) Selects the initial setting for audio tracks. Auto: Automatically selects the audio tracks if a programme has more than two tracks.
  • Page 218 SPDIF Selection (Auto / PCM) Selects the initial setting for digital audio output signal from DIGITAL AUDIO and HDMI2 (ARC function) terminals. SPDIF is a standard audio transfer file format. ● Auto: Dolby Digital Plus, Dolby Digital and HE-AAC multi-channel are output as Dolby Digital Bitstream.

  • Page 219: Reset To Defaults

    Sets to control the TV with devices connected to the network. Home network Network settings Network Link Settings Other settings Software Update Checks for available software updates from the Panasonic website. Internet service Network settings Software Update Home network Network settings...

  • Page 220: Off Timer

    Timer Off Timer Sets the duration of time until the TV automatically goes into Standby mode. (minutes)) Watching Basic Off Timer Timer Programming Sets a timer to record or remind forthcoming programmes. Recording Timer Programming For DVB mode ● Time Zone Adjusts the time data.

  • Page 221: Eco Navigation

    Setup Eco Navigation Automatically sets the TV to the most suitable energy-saving mode. The concerned items and their current settings are displayed. Select Set to to set them to the energy-saving settings at once. Voice Control Settings Settings for Voice Control function. Functions Voice Control Preparations...

  • Page 222: Bluetooth Setup

    Bluetooth Setup Settings for the specific devices supporting Bluetooth wireless technology Functions Bluetooth devices Bluetooth Setup Child Lock Applies access control for channels or inputs to prevent unwanted access. Functions Child Lock Tuning Menu Favourites Edit Creates a list of favourite channels. Watching Tuning and editing channels Favourites Edit...
  • Page 223 Signal Condition Checks the signal condition. Watching Tuning and editing channels Signal Condition Not valid in Analogue mode ● Antenna System (One LNB MiniDiSEqC DiSEqC 1.0 Single Cable) Sets the antenna system to use plural LNBs for receiving several satellites. Watching Tuning and editing channels Auto Setup...

  • Page 224: Language

    Language OSD Language Changes language for on-screen displays. Preferred Audio 1 / 2 Selects the first and second preferred language for DVB multi audio (depending on the broadcaster). Preferred Subtitles 1 / 2 Selects the first and second preferred language for DVB subtitles (depending on the broadcaster).
  • Page 225 Teletext Character Set (West East1 / East2) Selects teletext language font. West: English, French, German, Greek, Italian, Spanish, Swedish, Turkish, etc. East1: Czech, English, Estonian, Lettish, Rumanian, Russian, Ukrainian, etc. East2: Czech, Hungarian, Lettish, Polish, Rumanian, etc. Default Guide (Channel List Guide) Selects the default TV Guide type when pressing GUIDE.

  • Page 226: Common Interface

    VIERA Connect Banner / Off) Sets the VIERA Connect introduction banner display. For Full Screen TV ● Playing Time Display / Off) Set to to display a time period of continuous use in Game mode on the top right of the screen every 30 minutes. This function is available when Game Mode is set to On.

  • Page 227: Viera Link Settings

    VIERA Link Settings VIERA Link / Off) Sets to use VIERA Link functions. Functions VIERA Link “HDAVI Control™” Power on Link / Off) Sets to use Power on Link functions. Functions VIERA Link “HDAVI Control™” Power on Link Power off Link / Off) Sets to use Power off Link functions.

  • Page 228: Professional Mode (Isfccc)

    Professional Mode (isfccc) Enables the professional picture settings. Set to to display the modes of Professional1 Professional2 Viewing Mode. isfccc is the picture setting for the certified professional dealer. For details, ● consult your local dealer. Data Service Application Service (Auto Start On Auto Start Off / Off)

  • Page 229: System Menu

    System Menu Keyboard Layout Selects the language that your USB or Bluetooth Keyboard supports. For information of using Keyboard ● Functions Keyboard / Gamepad Keyboard Shipping Condition Resets all settings to the original condition. Functions Shipping Condition System Update Downloads new software to this TV. Functions Updating the TV Software Licence Menu...

  • Page 230: Picture

    Picture Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Auto aspect Auto aspect is designed to provide you with the best ratio to fill the screen.
  • Page 231 No image can be displayed Check all required cables and connections are firmly in place. ● Check the correct input mode is selected. ● Check the setting of AV2 (COMPONENT / VIDEO) in Input Selection ● match the output of the external equipment. Watching External equipment Is Contrast,...

  • Page 232: Digital Tv

    Digital TV Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Block noise, frozen or disappearing image occurs / Some channels cannot be tuned Check the position, direction and connection of the aerial or dish.
  • Page 233 No programmes shown on TV Guide Check the digital transmitter. ● Adjust the direction of the aerial or dish to another transmitter installed ● nearby. - 233 -...

  • Page 234: Analogue Tv

    Analogue TV Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. White spots or shadow image (ghosting) occurs / Some channels cannot be tuned Check the position, direction and connection of the aerial.

  • Page 235: Sound

    Sound Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. No sound is produced Is “Sound mute” active? Press MUTE to switch sound mute on or off.

  • Page 236: 236

    Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Cannot view 3D images Cannot register a 3D Eyewear to the TV Has the 3D Eyewear been switched on and set to 3D mode? ●...

  • Page 237: Hdmi

    HDMI Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Sound is unusual Set the sound setting of the connected equipment to “2ch L.PCM”.

  • Page 238: Network

    Network Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. Cannot connect to the network Check the LAN cable or wireless LAN is connected properly.
  • Page 239 Cannot operate internet content Check the connections and settings. ● Internet service Network connections Internet connection Internet service Network settings The server or connected line may be busy now. ● - 239 -...

  • Page 240: Other

    Other Before requesting service or assistance, please follow these simple guides to solve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. VIERA Link function does not work and an error message appears Check the connections.
  • Page 241 Built-in Camera does not work Ensure the built-in Camera is held up. When the application for camera ● operation is activated, the built-in Camera automatically pops up. Face recognition may not work properly depending on surrounding ● environment or condition (for example, darkened room, etc.). The touch pad controller does not work or cannot be registered Are the batteries installed correctly? ●...

  • Page 242: Care And Cleaning

    Maintenance Care and Cleaning First, remove the mains plug from the socket outlet. ■ Display panel, Cabinet, Pedestal Regular care: Gently wipe the surfaces of the display panel, cabinet, or pedestal using a soft cloth to clean the dirt or fingerprints. For stubborn dirt: First clean the dust on the surface.

  • Page 243: Using Help Menu

    Information Using Help menu 1. Display the menu with MENU 2. Select Help with and press to access 3. Select TV Self Test System Information Device Information with and press to access TV Self Test Makes a diagnosis of picture or sound problems. Follow the on-screen instructions.

  • Page 244: Optional Accessories

    3D Eyewear ■ 3D Eyewear TY-ER3D4ME, TY-ER3D4SE (Rechargeable type) ● – If you need 3D Eyewear additionally, please purchase this optional accessory. – Use Panasonic 3D Eyewear supporting Bluetooth wireless technology. – For more information (English only): http://panasonic.net/viera/eu/ - 244 -...

  • Page 245: Wall-Hanging Bracket

    Wall-hanging bracket ■ Wall-hanging bracket TY-WK4P1RW ● – For 42 / 50 inches model – Tilting angle for the TV: 0 (vertical) to 20 degrees (42 inches model) 0 (vertical) to 10 degrees (50 inches model) TY-WK5P1RW ● – For 55 / 60 inches model –...
  • Page 246 = Warning = Using other wall-hanging brackets, or installing a wall-hanging bracket ● by yourself have the risk of personal injury and product damage. In order to maintain the unit’s performance and safety, be absolutely sure to ask your dealer or a licensed contractor to secure the wall-hanging brackets. Any damage caused by installing without a qualified installer will void your warranty.
  • Page 247 The Bluetooth word mark and logos are registered trademarks owned by ® Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners. SDXC Logo is a trademark of SD-3C, LLC.
  • Page 248 HDAVI Control™ is a trademark of Panasonic Corporation. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &...
  • Page 249 Please refer to the detailed terms and conditions thereof shown in the “Software Licence” menu on this product. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below,...
  • Page 250 Ver.1.01...

This manual is also suitable for:

Tx-pr65vt60Tx-pr55vt60

Table of Contents
