KH 3157 Content Page For your safety Proper Use Delivery Contents Component description Technical Data Safety information Product features Operation Connection Disconnecting Select charging mode Reset/deleting settings Switching over between modes 1, 2 and 3 Mode 1 (14.4 V / 0.8 A) Mode 2 (14.4 V / 3.6 A ) Mode 3 (14.7 V / 3.6 A ) Regenerating / charging empty (used, overcharged) batteries...
KH 3157 TRONIC T4X Delivery Contents Automatic Car Battery Charging Station Check the appliance and all accessories for rechargeable batteries/batteries for damage immediately after unpacking. from 1.2 Ah to 120 Ah Do not put a defective appliance or parts into operation. Please contact the resonsible service department for For your safety a replacement.
KH 3157 Technical Data Safety information Input voltage: 220-240 V ~ 50/60 Hz Danger! Avoid danger to life and Starting current: < 25 A limbs caused by improper use! Input current: max. 0.6 A • Do not operate the appliance with a (Effective value) damaged cable, power cord or plug.
Page 8
KH 3157 • Danger of explosion and fire! Make • When connecting the charging station sure that explosive and flammable to the battery, avoid short-circuiting. substances e.g. petrol or solvents can Connect the minus pole connecting be ignited when using the charging cable only to the minus pole of the station! battery or to the car body.
KH 3157 • Ensure that the mains power socket is • Before connecting the charging at all times freely accessible so that in station, read the information on a case of emergency the appliance battery maintenance in the operating can be quickly separated from the instructions of the battery! power source.
KH 3157 Operation • Connect the "–" pole quick-contact clamp (black) to the "–" pole of the Attention Only install, maintain battery. and service the appliance when it is • Connect the power cord of the disconnected form the mains! battery charging station to the socket oulet with earthing contact of the Tip!
KH 3157 This avoids sparking, which often occurs Mode 1 (14.4 V / 0.8 A) when connecting. Furthermore, this This mode is suitable for charging small device is also controlled by an internal batteries with a capacity below 14 Ah. MCU (Micro-Computer-Unit), which makes it faster, more powerful and more •...
KH 3157 Mode 2 (14.4 V / 3.6 A ) If the procedure runs without any This mode is mainly used for charging problems, the LED display batteries with a large capacity exceeding lights up, the electronic stystem is 14 Ah under normal conditions. active and remains in this condition until the battery is charged to approx.
KH 3157 Disposal Protective function of the device If a unexpected situation should occur, The packaging consists of 100 % environ- such as short circuiting, battery voltage entally compatible materials that can be below 7.5 V, open circuit or reversed disposed of via local recycling facilities.
KH 3157 Service You will find the contact information for the service department responsible for your country in the warranty documents. Importer KOMPERNASS GMBH BURGSTRASSE 21 D-44867 BOCHUM www.kompernass.com We reserve the right to undertake technical modifications in the course of development.
