4. An "Edit The Raid Set Name" dialog box appears. Enter 1 to
15 alphanumeric characters to define a unique identifier for the
RAID Set. The default RAID Set name will always appear as Raid
Set. #.
Controller I/O Port:F3000000h, F2: Select Controller, F10: Reboot System
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
Ethernet Configuration
View System Events
Clear Event Buffer
Hardware Monitor
System information
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw

3.7.2.2 Delete Raid Set

To completely erase and reconfigure a raid set, you must first
delete it and re-create the raid set. To delete a raid set, select
the raid set number that user want to delete in the Select Raid
Set to Delete screen. The Delete Raid Set dialog box appears,
then press Yes key to delete it. Warning, data on RAID set will
be lost if this option is used.
Controller I/O Port:F3000000h, F2: Select Controller, F10: Reboot System
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
Ethernet Configuration
View System Events
Clear Event Buffer
Hardware Monitor
System information
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw

3.7.2.3 Expand Raid Set

Instead of deleting a raid set and recreating it with additional
BIOS CONFIGURATION
Areca Technology Corporation RAID Controller
Raid Set Function
Create Raid Set
Delete Raid Set
Select IDE Drives For Raid Set
Expand Raid Set
Activate Raid Set
[*]Ch01| 80.0GBST380013AS
Create Hot Spare
Edit The Raid Set Name
[ ]Ch04| 80.0GBST380013AS
Delete Hot Spare
[ ]Ch05| 80.0GBST380013AS
R aid Set # 00
Raid Set Information
[ ]Ch08| 80.0GBST380013AS
Areca Technology Corporation RAID Controller
Raid Set Function
Create Raid Set
Delete Raid Set
Select Raid Set To Delete
Expand Raid Set
Activate Raid Set
Raid Set
Create Hot Spare
Raid Set
Delete Hot Spare
Raid Set Information
Are you Sure?
# 00
# 01
Yes
No
