- Page 1 It’s Under Control It’s Under Control ® ® T3-V+ Universal System Controller 70-20085-23 V.0...
- Page 2 T3-V+ Universal System Controller Copyright © 200 Remote Technologies Incorporated All rights reserved.
-
Page 3: Federal Communications Commission Notice
Contains FCC id: mmUrTi1500 Contains FCC id: U9r-W2SW0001 Contains iC (Canada): 3166a-rTi1500 For indoor Use Only 117 612 914 deClaraTiOn OF COnFOrmiTY (dOC) The Declaration of Conformity for this product can be found on the RTI website at: www.rticorp.com/declaration... -
Page 4: Safety Suggestions
T3-V+ Universal System Controller SaFeTY SUGGeSTiOnS read and Follow instructions. Read all safety and operating instructions before operating the unit. retain instructions. Keep the safety and operating instructions for future reference. Heed Warnings. Adhere to all warnings on the unit and in the operating instructions. -
Page 5: Battery Warnings
Failure to follow these directions could result in damage to your remote control that may not be covered by RTI’s warranty. Store lithium batteries in a cool, dry, ventilated area. Follow applicable laws and regulations for transport, shipping, and disposal. -
Page 6: Limited Warranty
T3-V+ Universal System Controller limiTed WarranTY Remote Technologies Incorporated warrants its products for a period of one () year (90 days only for included battery packs) from the date of purchase from Remote Technologies Incorporated or an authorized Remote Technologies Incorporated distributor. This warranty may be enforced by the original purchaser and subsequent owners during the warranty period, so long as the original dated sales receipt or other proof of warranty coverage is presented when warranty service is... -
Page 7: Disclaimer
Microsoft Corporation in the United States and other countries. ZigBee is a registered trademark of the ZigBee Alliance. T3-V+, Integration Designer, and the RTI logo are registered trademarks of Remote Technologies Incorporated. Other brands and their products are trademarks or registered trademarks of... - Page 8 T3-V+ Universal System Controller...
-
Page 9: Table Of Contents
It’s Under Control ® TaBle OF COnTenTS Federal Communications Commission notice ....3 Safety Suggestions ............4 Battery Warnings ............5 limited Warranty ............6 disclaimer ..............7 Table of Contents ............9 Chapter 1 - Welcome ..........11 Features .............. IR Compatibility ............ - Page 10 T3-V+ Universal System Controller...
-
Page 11: Chapter 1 - Welcome
• Optional ‘Voltage’ and ‘Video’ sensing modules to monitor power status of equipment when used with RTI processors. • Capable of two-way RS-232 control when used with RTI control processors. • Non-volatile Flash memory stores your system configuration even when power is not present. -
Page 12: Ir Compatibility
T3-V+ Universal System Controller CHaPTer 1 | WelCOme ir COmPaTiBiliTY The T3-V+ and Integration Designer software are compatible with infrared ® (IR) commands with carrier frequencies between 5kHz and 0kHz, as well as those commands that do not use a carrier. This covers virtually all of the remotes that exist to date. -
Page 13: Chapter 2 - Introduction
It’s Under Control ® CHaPTer 2 | inTrOdUCTiOn imPOrTanT nOTeS Please read these important notes about the T3-V+: The T3-V+ should be placed in an area where it is around normal room temperature (between 0° F to 90° F). If the temperature is too hot, the display appears dim. -
Page 14: Battery And Docking Station
T3-V+ Universal System Controller CHaPTer 2 | inTrOdUCTiOn BaTTerY and dOCKinG STaTiOn The T3-V+ uses a Lithium-Ion rechargeable battery. This battery does not exhibit any type of “Memory Effect” from being charged too often. Since the T3-V+ can safely be charged after each use, a docking station is included for convenience. -
Page 15: Getting Started
It’s Under Control ® CHaPTer 2 | inTrOdUCTiOn GeTTinG STarTed nOTe: The following steps for initial installation including removing the battery door should be performed by an authorized service center or trained installer only. Start by insuring the battery connector is inserted into the mating plug on the T3-V+. -
Page 16: Remote Reference
T3-V+ Universal System Controller CHaPTer 2 | inTrOdUCTiOn remOTe reFerenCe IR TRANSMISSION FrOnT WINDOW LIGHT SENSOR TOUCHSCREEN DISPLAY “HOME” KEYPAD BUTTON CUSTOMIZABLE KEYPAD BUTTONS 3-WAY ROCKER SWITCH KEYPAD BUTTONS... - Page 17 It’s Under Control ® CHaPTer 2 | inTrOdUCTiOn BaCK AUDIO SPEAKER IMAGE REQUIRED LITHIUM-ION BATTERY PACK PROGRAMMING POWER PORT SWITCH DOCKING STATION CONTACTS...
-
Page 18: Docking Station Reference
T3-V+ Universal System Controller CHaPTer 2 | inTrOdUCTiOn dOCKinG STaTiOn reFerenCe CHARGE CONTACTS CHARGE LED BaCK 2.5 in. (3 mm) WALL MOUNT HOLES WIRE GUIDE POWER JACK... - Page 19 It’s Under Control ® CHaPTer 2 | inTrOdUCTiOn KeYCaP rePlaCemenT The T3-V+ kit includes a set of extra keycaps. They can be used instead of the keycaps that are pre-installed on the five customizable keypad buttons located just below the touchscreen. IMPORTANT NOTE: Do not attempt to replace any of the other button keycaps on the remote, as they are not designed to be removed.
- Page 20 T3-V+ Universal System Controller CHaPTer 2 | inTrOdUCTiOn...
-
Page 21: Chapter 3 - Operation
® dealers can download the software from: www.rticorp.com/dealers The required USB cable is included with the RTI IR-PRO dealer kit. THe TOUCHSCreen diSPlaY The T3-V+ touchscreen display is organized into a series of pages. Normally each page contains objects (buttons, text, graphics, etc.) that are related in some way. -
Page 22: The Control Panel Page
T3-V+ Universal System Controller CHaPTer 3 | OPeraTiOn THe COnTrOl Panel The Control Panel page can be displayed by first setting the T3-V+ power switch to the off position, and then Pressing and holding the touchscreen while sliding the power switch to the on position. -
Page 23: Backlight Level
It’s Under Control ® CHaPTer 3 | OPeraTiOn BaCKliGHT leVel (ambient light Sensor enabled) If the light sensor is enabled, there are two backlight levels to adjust. Press the left arrow or right arrow buttons to adjust. Press the OK button when finished. -
Page 24: Time Out
T3-V+ Universal System Controller CHaPTer 3 | OPeraTiOn TilT SWiTCH This button displays a window that allows you to adjust the settings for the built-in tilt sensor. The tilt switch is a motion detector that turns the remote on when activated. Press the OK button when finished. On means the tilt switch is active and will wake-up the T3-V+ when it is moved. -
Page 25: Battery
It’s Under Control ® CHaPTer 3 | OPeraTiOn BaTTerY This button displays a window that allows you to adjust the relative amount of time that the low battery icon appears on the display. This setting will determine how much time you have between the appearance of the low battery warning and the battery becoming completely depleted. -
Page 26: Calibrate Touchscreen
T3-V+ Universal System Controller CHaPTer 3 | OPeraTiOn CaliBraTe TOUCHSCreen This button runs a routine that allows you to calibrate the touchscreen. Since it normally should not be necessary to calibrate the touchscreen, this routine is included as a precaution only. Press the Calibrate button to continue. -
Page 27: Network Information
It’s Under Control ® CHaPTer 3 | OPeraTiOn neTWOrK inFOrmaTiOn This button displays a window that allows you to view the wireless networking information. This is for troubleshooting purposes only, all networking configuration must be made in Integration Designer . Press the ®... - Page 28 T3-V+ Universal System Controller...
-
Page 29: Chapter 4 - Specifications
It’s Under Control ® CHaPTer 4 | SPeCiFiCaTiOnS Power 3. VDC, 700 mAh Lithium-Ion Battery Pack Power Management Automatic On/Off (tilt switch) Infrared Control 30 feet (9. meters) @ 0 degrees Range Infrared Frequency 5 kHz - 0 kHz Transmission Range Radio Frequency Up to 00 feet (30.5 meters) Control Range... - Page 30 T3-V+ Universal System Controller...
-
Page 31: Chapter 5 - Troubleshooting
® Make sure you are using the programming cable that was supplied by RTI and that both ends are connected securely. Make sure the PC detects the presence of the T3-V+. If it doesn’t, unplug the USB cable, wait for about ten seconds, and plug it in again. - Page 32 T3-V+ Universal System Controller...
-
Page 33: Chapter 6 - Service And Support
Fax (952) 253-33 info@rticorp.com rTi TeCHniCal SUPPOrT At RTI, customer service and satisfaction is an utmost priority. If you are encountering any problems or have a question about your RTI product, please contact RTI Technical Support for assistance. RTI provides technical support by telephone, fax or e-mail. For the highest quality service, please have the following information ready, or provide it in your fax or e-mail. - Page 34 SerViCe and SUPPOrT Shipment of T3-V+ for Service RTI will pay all labor and material expenses for all repairs covered by this product’s warranty. If necessary repairs are not covered by warranty, or if a unit is examined which is not in need of repair, you may be charged for the repairs or examination.
-
Page 35: Index
Programming the T3-V+ ............... 2 Safety Suggestions ................ Service and Support ..............33 Contacting RTI ................. 33 RTI Technical Support ............... 33 Shipment of T3-V+ for Service ............3 Software Requirements ..............2 Specifications ................29 Troubleshooting ................3... - Page 36 T3-V+ Universal System Controller It’s Under Control ® remote Technologies incorporated 5775 12th avenue east, Suite 180 Shakopee, mn 55379 Tel: 952-253-3100 Fax: 952-253-3131 www.rticorp.com © 200 Remote Technologies Inc. All rights reserved.
